Panasonic FD-F4 Series Instruction Manual

INSTRUCTION MANUAL
Pipe-mountable Liquid Level Detection
FD-F4
MJE-FDF4 No.0097-33V
1
MOUNTING
Mount the fiber on a pipe with the attached tying bands and
anti-slip tubes as shown in the figure below.
Make sure that the release lever is retracted (position as
shown in the figure) before mounting.
Fasten two tying bands, as shown, and cut off the excess portions.
Anti-slip tube
Upper side
Lower side
Release lever Tying band
2- 3.2 mounting holes
If other tying bands are to be used, the dimension
the figure below should be 2.5mm or less.
In case of mounting using the two mounting holes, use M3
screws, plain washers, and spring washers.
The tightening torque should be 0.3N m or less.
Please arrange the M3 screws, plain washers, and spring
washers separately.
In case of mounting on the pipe with tying bands, the fiber
position can be easily adjusted with the release lever.
Adjustment Release lever
Unlock the release lever (in
the direction of the arrow).
Press the movable center
holders forward to loosen the
tying bands and adjust the
position.
Lock the release lever to its Press
original place.
Release lever
Notes: 1) Whenever the mounting position is changed, adjust the sensitivi-
ty again.
2) The lever mechanism must be used only to adjust the position,
and not for tightening the tying bands. If tying bands are
tightened while the lever is open, and then the lever is locked,
the fiber may be damaged.
2
CONNECTION TO AMPLIFIER
Put the fiber cable with white stripe into the beam-emitting
side, and the fiber cable without white stripe into the beam-re-
ceiving side. If the connection is wrong, correct detection is
not possible.
With white stripe
Beam-emitting side
Beam-receiving side
Thank you very much for purchasing Panasonic products. Read
this Instruction Manual carefully and thoroughly for the correct
and optimum use of this product. Kindly keep this manual in a
convenient place for quick reference.
WARNING
Never use this product as a sensing device for personnel protection.
In case of using sensing devices for personnel protection, use
products which meet laws and standards, such as OSHA, ANSI or
IEC etc., for personnel protection applicable in each region or country.
3
SENSITIVITY ADJUSTMENT
For the amplifiers, refer to the respective amplifier's Instruction
Manual.
Do not move or bend the fiber cable after the sensitivity setting.
Detection may become unstable.
When using in combination with the FX-301(P), the
FX-301(P)-HS or the FX-305(P)
<In case of 2-level teaching>
Press MODE key to change to the teaching mode
shown in
[MODE indicator/TEACH (yellow)].
Press jog switch in the liquid absent
condition to read incident light
intensity.
Press jog switch in the liquid present
condition to read incident light
intensity.
The threshold value is set at
the mid-value between the
values of step and and
the judgment result in stability
is indicated.
The setting is complete.
Loosen
<In case of limit teaching>
Press MODE key to change to the teaching mode
[MODE indicator/TEACH (yellow)].
Press jog switch in the liquid absent
condition to read incident light
intensity.
Turn jog switch
to '-' side to
High
15%
lower the thresh- OFF
(Note)
old value (High
100%
sensitivity).
ON
Low
0
Note: The approx. 15% amount of shift is the initial value. Refer to the respec-
tive amplifier's Instruction Manual for details of the setting method.
The judgment result in stability is
indicated.
The setting is complete.
Combination with FX-411(P)
Check the incident light intensity
[in the digital display (red)] in the
liquid present condition.
Check the incident light intensity
[in the digital display (red)] in the
liquid absent condition.
Turn the threshold value adjuster
to the threshold value [in the
digital display (green)] that is the
value in between
<Threshold value setting method>
When the threshold value adjuster is turned clockwise, the
MODE key threshold value increases. When the threshold value adjuster is
turned counterclockwise, the threshold value decreases.
Jog switch
(Threshold value)
Press
If there is a sufficient level of margin in the incident light intensity,
Liquid absent
the stability indicator (green) will light up.
Fiber
Combination with FX-311(P)
Press
Pipe
Liquid present
Sensitivity indicator
The operation indicator (orange) lights up depending on the combina-
tion of the sensing condition and the selected operation, as follows.
Press
Sensing condition
: Stable sensing is possible
L-ON (ON when liquid absent)
Light
: Stable sensing is not possible (liquid absent)
D-ON (ON when liquid present)
L-ON (ON when liquid absent)
Dark
(liquid present)
D-ON (ON when liquid present)
The operation selection switch is set to L-ON (ON
when liquid absent).
Turn the sensitivity adjuster fully counterclockwise.
MODE key
(Minimum sensitivity)
In the liquid absent condition, slowly
Jog switch
turn the adjuster clockwise and find
the point where the sensor is
switched ON.
Press
Liquid absent
Fiber
In the liquid present condition, slowly turn
the adjuster further clockwise until the
Press sensor goes into the ON state again.
Pipe Once it is switched on, turn the adjuster
counterclockwise a little and find the point
where it is switched OFF.
If the sensor does not go into the
Turn to '-' side
ON state, MAX is the point
Incident light intensity
with liquid absent
The position at the middle of points
Threshold value
optimum sensing position.
Select either L-ON (ON when liquid absent) or D-ON
Turn to '-' side
(ON when liquid present) according to your application.
Notes: 1) In order to protect the mechanism, the sensitivity adjuster idles when
over turned, which may result in a backlash of 1 to 2 divisions.
: Shifting is possible
2) Depending upon the sensing conditions, stable sensing may be possible
: Shifting is not possible at a position which is slightly shifted from the optimum sensitivity point.
3) FX-311(P) incorporates the assist function which is useful for
sensitivity adjustment. For details, refer to the instruction manual
enclosed with FX-311(P).
4
SPECIFICATIONS
Item
Operation selection switch
Applicable amplifiers
Threshold value adjuster
Sensing object
Liquid present
Incident light Applicable pipe diameter
intensity (Note 2)
Repeatability
Fiber cable length
Liquid absent
Ambient temperature
Fiber
Incident light
(Note 3)
intensity
Ambient humidity
Pipe
Material
Accessories
(Threshold value)
and .
Notes: 1)
5
CAUTIONS
Fit the fiber head to the pipe securely, otherwise the operation
may be erroneous.
(Threshold value) (Threshold value)
Take care that no dew condenses on the pipe's sensing
surface or the pipe's inside wall and that no bubble attaches
on the pipe's inside wall, since it can affect the operation. If a
liquid drop flows down across the sensing point or an air
bubble sticks on the wall at the sensing point, the operation
may be erroneous. Make sure that no bubble arises in the
liquid, and that no dew or liquid drop is present on either
surface of the pipe wall.
Sensitivity adjuster Operation selection switch
Neither FD-F4
tion should be avoided at any place where it could come in
direct contact with water or chemicals.
: Lights up : Turn off Do not apply excessive tensile force to the fiber cable.
Operation Operation indicator
Bending radius of the fiber cable must be R10mm or more. If
the bending radius is smaller than the specified value, the
sensing performance may deteriorate.
Take care that the sensor is not directly exposed to fluorescent
lamp from a rapid-starter lamp, a high frequency lighting device
or sunlight etc., as it may affect the sensing performance.
L
ON
D
Liquid absent
Fiber
ON
Pipe
Liquid present
OFF
ON
.
and is the Optimum point
Panasonic Industry Co., Ltd.
1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8506, Japan
https://industry.panasonic.com/
Please visit our website for inquiries and about our sales network.
Panasonic Industry Co., Ltd. 2024
April, 2024
Type Standard For PFA pipe, wall thickness 1mm
Model No. FD-F41 FD-F4
Fiber amplifiers using red light
Liquid (Note 1)
Outer dia 6 to 26mm Outer dia 6 to
transparent pipe transparent pipe
PVC, fluorine resin, PFA (fluorine resin) or
polycarbonate, acrylic, glass, equivalently transparent
wall thickness 1 to 3mm pipe, wall thickness 1mm
1mm or less (for water)
2m free-cut
-40 to +100 (No dew condensation or icing allowed)
Storage: -40 to +100
35 to 85% RH, Storage: 35 to 85% RH
Fiber head: Polyetherimide, Fiber core: Acrylic
Fiber sheath: polyethylene, Tying band: Nylon
Anti-slip tube: Silicone
Tying band: 4 pcs., Anti-slip tube: 2 pcs.
FX-CT2 (Fiber cutter): 1 pc., Fiber attachment: 1 set
Unclear or highly viscous liquid may not be detected stably.
2) Liquid in an opaque pipe cannot be detected correctly.
3) Liquid being detected should also be kept within the rated
ambient temperature range.
is waterproof or chemical-resistant. Installa-
PRINTED IN JAPAN
26mm
