USER MANUAL EBT470
Thank you for choosing our product.Please read the instructions carefully before
installation and keep it available for future maintenance or reference.
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
WOODBRIDGE
Remote Control Illustration
WATER TEMP
DRYER TEMP
LIGHT
HALF FLUSH
Or Email: help@woodbridgebath.com
www.woodbridgebath.com
R
SEAT TEMP
FULL FLUSH
Advertisement
Related Manuals for Woodbridge EBT470
Summary of Contents for Woodbridge EBT470
- Page 1 USER MANUAL EBT470 WOODBRIDGE Remote Control Illustration WATER TEMP DRYER TEMP SEAT TEMP LIGHT HALF FLUSH FULL FLUSH Thank you for choosing our product.Please read the instructions carefully before installation and keep it available for future maintenance or reference. Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com...
- Page 2 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Content Installation preparation 01. Remote control installation Usage Instruction 01. Remote control illustration 02. Rear/Front cleaning operation 03. Dry operation 04. Water volume adjustment 05. Spray nozzle position adjustment 06. Energy saver 07. Auto function 08. Temperature adjustment 09.
- Page 3 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Installation Preparation Remote control installation Remote control bracket installation (1) Place the remote control bracket upright on the (2) Insert wall anchors onto the holes,align pre-installed area of the wall and mark the location remote control bracket to match with of the two mounting holes on the wall with a marker.
- Page 4 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Installation Preparation Remote control installation Remote control hanger installation （Only for the hanger matching with fixing board and foam gasket.） (1) Clean and dry the pre-installed area of the (2) Remove the adhesive tape on the back remote control rack on the wall.
- Page 5 WOODBRIDGE Usage Instruction Remote control illustration Rear cleaning/massage Water increasing Nozzle moving forward Front cleaning/massage Water reducing Nozzle moving backward Models without drying Drying function do not have this button Auto rear cleaning Auto front cleaning Indicator light(only Stop/Energy saver...
- Page 6 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Usage Instruction Rear/Front cleaning ·Press “Rear cleaning/massage” button, the indicator light is on showing current water temperature level, it starts rear cleaning; Press again “Rear cleaning/massage” button to shift to massage to massage cleaning (nozzle moves forward and backward to expand cleaning area). The cleaning will last for a circle and stop automatically, while it will stop immediately if the user presses “STOP”...
- Page 7 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Usage Instruction Water volume adjustment Under Rear Cleaning or Front Cleaning function,press “+” or “- ” button，the indicator light will be ON showing current water level, adjust water volume by 3 levels Spray nozzle position adjustment Under Rear Cleaning or Front Cleaning function,Presss “∧”...
- Page 8 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Usage Instruction Energy saver Keep pressing “STOP” button for more than 3S to enter energy saving mode, the indicator light will be off and energy saving light will be on. Keep pressing “STOP” button again for more than 3S to exit energy saving mode, the indicator light will be on and energy saving light will be off.
- Page 9 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Usage Instruction Temperature adjustment · Water temperature adjustment Short press the “WATER TEMP” button to adjust the water temperature. The indicator will show the water temperature level if it’s on. When the indicator is off, the water level is 0. Short press this button to adjust water temperature level from 0 to 5 in cycle.
- Page 10 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Usage Instruction Auto lid open/close (Only for toilet with this function) · Press “ ” button to close seat cover. · Press “ ” button to open lid and close seat. · Press “ ” button to open lid and seat.
- Page 11 WOODBRIDGE REMOTE CONTROL ILLUSTRATION Usage Instruction Other Operations User Code · The user code needs to be set to avoid disturbance from remote controls when more than one smart toilets are used in the house. Turn on the toilet for setting while turning off others.Press user code combination buttons (Press “STOP”...
- Page 12 Thank you for using WoodBridge products! Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com www.woodbridgebath.com Update: 20241204...
