EN User Manual | Oven KODDP71X EOD6P71X EOD6P71Z...
Page 2
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................9 5.
Page 3
be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use.
Page 4
• Always use oven gloves to remove or insert accessories or ovenware. • To remove the shelf supports first pull the front of the shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. •...
Page 5
electrical ratings of the mains power supply. Total power (W) Section of the cable • Always use a correctly installed (mm²) shockproof socket. maximum 1380 3x0.75 • Do not use multi-plug adapters and extension cables. maximum 2300 • Make sure not to cause damage to the maximum 3680 3x1.5 mains plug and to the mains cable.
Page 6
2.5 Pyrolytic cleaning – do not put water directly into the hot appliance. – do not keep moist dishes and food in WARNING! the appliance after you finish the Risk of Injury / Fires / Chemical cooking. Emissions (Fumes) in Pyrolytic Mode. –...
Page 7
• Use only lamps with the same specifications. 2.7 Service • To repair the appliance contact the Authorised Service Centre. 3. INSTALLATION 3.1 Building in WARNING! Refer to Safety chapters. www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG/Electrolux Oven - Column installation ENGLISH...
Page 8
(*mm) min. 550 min. 560 (*mm) min. 550 min. 560 3.2 Securing the oven to the cabinet ENGLISH...
Page 9
4. PRODUCT DESCRIPTION 4.1 General overview Socket for the food sensor Heating element Lamp Cavity embossment Shelf support, removable Shelf positions 4.2 Accessories • Wire shelf For cookware, cake tins, roasts. • Baking tray For cakes and biscuits. Control panel •...
Page 10
5.3 Display A. Timer / Temperature B. Heat-up and residual heat indicator C. Food Sensor (selected models only) D. Door lock (selected models only) E. Hours / minutes F. Demo Mode (selected models only) G. Clock functions 6. BEFORE FIRST USE Set the time before you use the oven.
Page 11
7.2 Setting the function: True Fan Cooking PLUS WARNING! Risk of burns and damage to the appliance. Step 1 Make sure that the oven is cold. Step 2 Fill the cavity embossment with tap wa‐ ter. The maximum capacity of the cavity embossment is 250 ml.
Page 12
Heating func‐ Application Heating func‐ Application tion tion To bake on up to three shelf po‐ To grill thin pieces of food in sitions at the same time and to large quantities and to toast dry food. bread. Fast Grilling Set the temperature 20 - 40 °C lower than for Conventional To roast large meat joints or...
Page 13
Clock function Application To set the oven turn-off time. Use only when a heating function is set. End Time Combination of functions: Duration, End Time. Time Delay To set a countdown time. This function has no effect on the operation of the oven.
Page 14
Step 2 - press repeatedly. - starts to flash. Step 3 Turn the knob for the temperature to set the hour. - press to confirm. Step 4 Turn the knob for the temperature to set the minutes. - press to confirm. At the set end time the signal sounds for 2 min.
Page 15
Step 3 Set the hours. Minute Minder - starts automatically after 5 sec. After 90% of the set time the signal sounds. Step 4 When the set time ends the signal sounds for 2 min. 00:00, - flash. Press any button to stop the signal.
Page 16
When the oven calculates the provisional • three times - the display shows the set oven temperature; if desired, it can be duration time for the first time, the symbol modified within 5 seconds. This info is flashes in the display. When the calculation available only during the heating up ends, the display shows the duration of the phase.
Page 17
To turn off the Child Lock, repeat the step 2. (°C) 10.2 How to use: function lock 30 - 115 12.5 You can turn on the function only when the 120 - 195 oven works. When the function is on the temperature and time settings cannot be 200 - 245 changed accidentally.
Page 18
Cooking meat and fish Cooking times Use a deep pan for very fatty food to prevent Cooking times depend on the type of food, its the oven from stains that can be permanent. consistency, and volume. Leave the meat for approximately 15 minutes Initially, monitor the performance when you before carving so that the juice does not seep cook.
Page 19
(°C) (min) Whole fish, 0.2 kg baking tray or dripping pan 25 - 35 Fish fillet, 0.3 kg pizza pan on wire shelf 25 - 30 Poached meat, 0.25 baking tray or dripping pan 35 - 45 Shashlik, 0.5 kg baking tray or dripping pan 25 - 30 Cookies, 16 pieces...
Page 20
( °C) (min) Apple pie, 2 True Fan Wire shelf 70 - 90 tins Ø20 Cooking Fatless Conventional Wire shelf 40 - 50 Preheat the oven for sponge Cooking 10 min. cake, cake mould Ø26 Fatless True Fan Wire shelf 40 - 50 Preheat the oven for sponge...
Page 21
12.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐ tergent. Use a cleaning solution to clean metal surfaces. Clean stains with a mild detergent. Cleaning Agents Clean the cavity after each use. Fat accumulation or other residue may cause fire. Moisture can condense in the appliance or on the door glass panels.
Page 22
Step 3 Pull the rear end of the shelf support away from the side wall and remove Step 4 Install the shelf supports in the oppo‐ site sequence. The retaining pins on the telescopic runners must point to the front. 12.4 How to use: Pyrolysis CAUTION! Clean the oven with Pyrolysis.
Page 23
- press at the same time to turn off the reminder. 12.6 How to remove and install: Door The oven door has three glass panels. You can remove the oven door and the internal glass panels to clean them. Read the whole "Removing and installing door" instruction before you remove the glass panels.
Page 24
Step 7 Hold the door glass panels by their top edge and carefully pull them out one by one. Start from the top panel. Make sure the glass slides out of the supports completely. Step 8 Clean the glass panels with water and soap. Dry the glass panels carefully. Do not clean the glass panels in the dishwasher.
Page 25
Back lamp Step 1 Turn the glass cover to remove it. Step 2 Clean the glass cover. Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp. Step 4 Install the glass cover. 13. TROUBLESHOOTING WARNING! Error codes Refer to Safety chapters.
Page 26
......... 14. ENERGY EFFICIENCY 14.1 Product Information and Product Information Sheet Supplier's name Electrolux KODDP71X 949499822 Model identification EOD6P71X 949499823 EOD6P71Z 949499826 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conventional mode 0.93 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.69 kWh/cycle...
Page 27
Volume 72 l Type of oven Built-In Oven EOD6P71X 33.4 kg Mass EOD6P71Z 32.5 kg KODDP71X 32.9 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐ ods for measuring performance.
