2.6 kW
Split System Air Conditioner
PROTECT YOUR WARRANTY
INSTALLATION MANUAL
This unit must be installed by a
registered, licensed installed as
Model Number EUR-26SPLIT
required by Government regulations.
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 |
tempo.org/support
E209
Advertisement
Related Manuals for Euromatic EUR-26SPLIT
Summary of Contents for Euromatic EUR-26SPLIT
- Page 1 Split System Air Conditioner PROTECT YOUR WARRANTY INSTALLATION MANUAL This unit must be installed by a registered, licensed installed as Model Number EUR-26SPLIT required by Government regulations. After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 2 Contents Page Important Safety Instructions Product Overview Selecting the Installation Place Installation Information for the Installer Other Useful Information Licensed Installer Details After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 3 Important Safety Instructions PROTECT YOUR WARRANTY These installation instructions for the Spilt System Air Conditioner are for use by an appropriately qualified, licensed installer. The appliance must be installed in accordance with all applicable regulations. Do not try to install the appliance on your own; doing so will expose you to danger and void the warranty.
- Page 4 Important Safety Instructions (Cont.) • Test cycle: Carry out a test cycle after installing the air conditioner and record the operating data. Make sure that air cannot enter the refrigerant system and check for refrigerant leaks when moving the air conditioner. • Installation location: The installation location should be in an areas that is well-ventilated.
- Page 5 Important Safety Instructions (Cont.) Important Safety Precautions Concerning Refrigerant R32 WARNING: Combustible & Dangerous This symbol alerts you to take care as the appliance contains a flammable refrigerant: R32 (difluoromethane). Take extra care when installing the unit and when carrying out maintenance. The refrigerant used in this air conditioner, R32, is an odourless hydrocarbon gas with a high level of environmental compatibility, with significantly lower...
- Page 6 Important Safety Instructions (Cont.) Maximum Charge and Minimum Floor Area = (4m ) x LFL = (26m ) x LFL = (130m ) x LFL Where LFL is the lower flammable limit in kg/m , the LFL for R32 is 0.306 kg/m For appliances with a charge amount m < M ≤ m • The maximum charge in a room shall be in accordance with the following: = 2.25 x (LFL)
- Page 7 Important Safety Instructions (Cont.) Site and Operation Safety • No open flames: The sites for installing and maintaining an air conditioner using refrigerant R32 should be free from open fires or welding, smoking, drying ovens or any other heat source higher than 548°C, which easily produces open fire. • Ventilation necessary: The installation site should be in a well-ventilated condition.
- Page 8 Important Safety Instructions (Cont.) Special Tools Required Tool Requirements for use It should be an explosion-proof vacuum pump that Mini vacuum pump can ensure certain precision and its vacuum degree should be lower than 10Pa. It should be a special explosion-proof filling device, Filling device have certain precision and its filling deviation should be less than 5g.
- Page 9 Product Overview • This air conditioner is made up of an indoor and outdoor unit (Fig. 1&2), which are connected through properly insulated copper pipes and an electrical connecting cable (not supplied). • The indoor unit is installed on a wall of the room to be air conditioned (it must not be installed in a laundry or similar room with high humidity levels).
- Page 10 Product Overview (Cont.) Fig. 2 (with the protective cover removed) Scope of Delivery (B) Outdoor Unit: Parts Air inlet Wiring cover Drainage pipe Connection wiring Valve protection cover Gas valve (low pressure valve) Liquid valve (high pressure valve) Air outlet After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
- Page 11 Product Overview (Cont.) Fig. 3 Installation hardware (for illustrative purposes only, not to scale) PLASTICINE (C) Installation Hardware (D) Other inclusions Part (not pictured) 17 Power cable Remote control holder (for wall-mounting) 18 Copper nuts (x4) 2x AAA Batteries 19 Drainage pipe (for remote control) 20 Sealing colloid Instruction manual...
- Page 12 Selecting the Installation Place PROTECT YOUR WARRANTY These installation instructions for the Reverse Cycle Split System Air Conditioner are for use by an appropriately qualified installer. Do not try to install the air conditioner on your own; doing so will expose you to danger and void the warranty.
- Page 13 Selecting the Installation Place (Cont.) Outdoor unit Fig. 5 • Do not install the unit: • Near sources of heat, steam or flammable gas. • Where it is exposed to high winds or excessive dust. • Where people often pass. • Avoid installing the unit where it will be exposed to direct sunlight (otherwise use a protection that will not interfere with the airflow).
- Page 14 Installation Installation of the indoor unit • Before starting installation, decide on the position of the indoor and outdoor units, taking into account the minimum space required around the units. • Install the indoor unit in the room to be air conditioned. Installing the mounting plate Fig.
- Page 15 Installation (Cont.) Refrigerant piping connection • The piping can be run in the three directions, as indicated by the numbers 1 to 3 in Fig. 9. When the piping is run in directions 1 or 3, cut a notch along the groove on the side of the indoor unit with a sharp blade.
- Page 16 Installation (Cont.) • Tighten the connections by using two Fig. 11 torque wrenches and turning them in opposite directions (Fig. 11). • Wrap the joint with the insulation pipe. Note: For R32 refrigerant, the connector must be located outdoors (Fig. 12). Condensed water drainage from the indoor unit The condensed water drainage from the...
- Page 17 Installation (Cont.) • Do not bend the drain hose or leave it protruding or twisted, and do not put the end of it in water. If an extension is connected to the drain hose, ensure that it is lagged when it passes into the indoor unit. • If the piping is installed to the right, the pipes, power cable and drain hose must be lagged and secured onto the rear of the unit with a pipe connection.
- Page 18 Installation (Cont.) After having connected the pipe Fig. 16 according to the instructions, install the connection cables, then the drain pipe (Fig. 16). After connection, lag the pipe, cables and drain pipe with the insulating material. • Arrange the pipes, cables and drain hose as shown in Fig.
- Page 19 Installation (Cont.) Installation of the outdoor unit • The outdoor unit should be installed on a flat, even area on the ground where it can operate free of vibrations. It may also be installed on a solid wall and fastened securely using suitable brackets (not supplied). • Before connecting pipes and cables, decide on the best position on the wall, leaving enough space for easy maintenance.
- Page 20 Installation (Cont.) Electrical connections • Ensure the mains power is switched off, before using a phillips head screwdriver to remove the wiring cover. • Unscrew the cable clamp and remove it (Fig. 19). • For the electrical connections, see the wiring diagram on the back of the cover.
- Page 21 Installation (Cont.) Connecting the pipes Screw the flare nuts to the outdoor unit coupling with the same tightening procedures described for the indoor unit. To avoid leakage, pay attention to the following points: • Tighten the flare nuts using two wrenches, taking care not to damage the pipes (Fig.
- Page 22 Installation (Cont.) Bleeding Air and humidity left inside the refrigerant circuit can cause compressor malfunction. After having connected the indoor and outdoor units, bleed the air and humidity from the refrigerant circuit by using a vacuum pump (Fig. 21). Detailed instructions follow below. • Use a spanner to remove the protective caps from the service port, as well as the low and high pressure valves of the outdoor unit.
- Page 23 Installation (Cont.) • Fully open the low and high pressure valves of the outdoor unit with a hexagonal wrench. • Reinstall the protective caps to the service port, as well as the low and high pressure valves of the outdoor unit. • Reinstall the valve cover.
- Page 24 Installation (Cont.) Complete the following inspections before attempting a test run. Description Inspection method Electrical • Check whether the power supply voltage complies with the safety required specification. inspection • Check whether there are any incorrect or missing connections between the power lines, signal line and earth wires. • Check whether the earth resistance and insulation resistance comply with requirements.
- Page 25 Installation (Cont.) Indoor unit test • Does the ON / OFF button work properly? • Do the HEATING, COOLING and FAN modes operate normally? • Do the TIMER-ON and TIMER-OFF functions operate properly? • Does each indicator light work properly? • Do the flaps for air flow direction operate normally? • Is the condensed water drained regularly? Outdoor unit test...
- Page 26 Information for the Installer Wiring Diagrams Indoor Wiring Diagram Outdoor Wiring Diagram BK(WH) P3(S) GNYE(GN) P01(GND) INDOOR (OPTIONAL PART) UNIT GN(GNYE) BN(BK) (OPTIONAL PART) REACTOR P1(AC-L) P13(L1) POWER BU(WH) P14(L2) P2(AC-N) SUPPLY GNYE(GN) GNYE(GN) P0(GND)/P00 P10-1(U) (OPTIONAL PART) COMP P10-2(V) GNYE (OPTIONAL PART) CN12-2...
- Page 27 Information for the Installer (Cont.) Pipe length and additional refrigerant Inverter models 9K-12K 18K-24K 30-36K capacity (Btu / h) Length of pipe with 5m / 5m / 5m / 5m / 5m / 5m / standard charge 16ft 16ft 16ft 16ft 16ft 16ft...
- Page 28 Information for the Installer (Cont.) Torque parameters Tightening Torque Pound-force foot Kilogram-force Pipe Diameter meter (kgf-m) (N x m) (Ibf-ft) 6.35mm (1/4”) 15–20 11.1 - 14.8 1.5 - 2.0 9.52mm (3/8”) 31–35 22.9 - 25.8 3.2 - 3.6 12mm (1/2”) 45–50 33.2 - 36.9 4.6 - 5.1...
- Page 29 Other Useful Information Technical specifications Model Number EUR-26SPLIT Cooling 2640 W (1000 ~ 4000) Capacity Heating 4050 W (1000 ~ 4800) Cooling 4.3 A (1.3 ~ 6.6) Current Heating 4.6 A (1.3 ~ 7.4) Cooling 6.6 A Rated Current Heating 7.4 A...
- Page 30 Other Useful Information (Cont.) Compliance This appliance has been fully tested and meets all requirements as set out by standards AS/NZS 60335.1 and AS/NZS 60335.2.40 and also AS/NZS 3823.1.1 and AS/NZS 3823.2. The RCM Mark (Regulatory Compliance Mark) indicates that the product complies with the relevant guidelines of the ACMA as well as corresponding government requirements for the safety of electrical devices.
- Page 31 Licensed Installer Details Please ask your licensed installer/electrician to fill in the details below (or in the INSTRUCTION manual) so you have them on record should you need to contact the installer in the future. Proof of professional installation is also required for warranty claims. Please fill in the details below: Name of licensed installer: ..............
- Page 32 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on (AU) 1300 886 649 or (NZ) 0800 836 761 for advice.
