- Page 1 CONNECT SERIES TOUCH USER GUIDE...
- Page 2 The other two holes (60mm spacing) are spaced to align with UK or EU single gang light switch/socket back box. The Connect Series Touch will also require a hole in the wall with sufficient size to accommodate the network socket and sufficient depth to accommodate the network cable. Be aware that network cables are variable in their depth requirements –...
- Page 3 The Connect Series Touch only controls volume and source selection for LEA Connect Series Amplifiers. 3rd Party control is not currently supported. • The Connect Series Touch only supports DHCP IP addressing. A DHCP server must be on the network to use the CS Touch. Static IP Addressing will be supported soon. •...
- Page 4 The Connect Series Touch can control large systems, however, there are some limitations. If you are designing a large system with a Connect Series Touch and receive an error message when saving the Connect Series Touch file – you may have reached it’s maximum configuration limit.
- Page 5 An LEA Connect Series Amplifier must be connected to the same network as the CS Touch. • The CS Touch requires PoE power. The LAN port on a Connect Series Amplifier does not provide the necessary PoE power for the CS Touch.
- Page 6 Connect Series Touch devices that are on the network will also populate. RENAME DEVICE AMPLIFIER IP ADDRESS START BUILDING YOUR SYSTEM CONNECT SERIES TOUCH ON NETWORK CONNECT SERIES TOUCH - USER GUIDE | LEA Professional | Pg 6...
- Page 7 Subgroup would then remain at that volume difference when the Volume Group is adjusted up or down. NOTE If you would like to have zone volume offsets, but not give the Connect Series Touch user the ability to adjust that zone’s offset, you can do that in the Volume Group setup.
- Page 8 CREATING A VOLUME GROUP - Click + Add Volume Group During this step, you will name your group and select the amplifier channels you want a single volume control on the Connect Series Touch. The name you assign will show up on the Connect Series Touch as this Name.
- Page 9 The amplifier name and channel name show up in this step. It is highly recommended you name your amplifier and amplifier channels prior to configuring the Connect Series Touch to make this step easier for you. Amplifier name can be edited by clicking on the ‘i’ icon next to the bold ‘Device Name’...
- Page 10 Once you’ve set your Range and Offset. Click ‘Save’ in the upper right corner. Once you click ‘Save’ your Connect Series Touch will now display this Volume Group on the screen.
- Page 11 Setting Up Your System CONGRATULATIONS! You’ve created a Volume Group that can now be adjusted from the Connect Series Touch. MASTER VOLUME GROUP ON CONNECT SERIES TOUCH MASTER VOLUME GROUP CONFIGURATION IN WebUI CONNECT SERIES TOUCH - USER GUIDE | LEA Professional | Pg 11...
- Page 12 CREATING A SOURCE GROUP Click ‘+ Add Source Group’ Name your Source Group. This is the name that will show up on the Connect Series Touch, so make sure the user of the Connect Series Touch will understand what they are selecting.
- Page 13 Connect Series Touch and you can now change State Sources from the touchscreen. STEP 5 1. STATE YOU 2. ADD OR CREATED REMOVE AMP CONNECT SERIES TOUCH - USER GUIDE | LEA Professional | Pg 13...
- Page 14 Setting Up Your System CONGRATULATIONS! You’ve created a Source Group. MASTER SOURCE GROUP ON CONNECT SERIES TOUCH MASTER SOURCE GROUP CONFIGURATION IN WebUI CONNECT SERIES TOUCH - USER GUIDE | LEA Professional | Pg 14...
- Page 15 Click ‘Save’ in the top right corner. This Volume Subgroup will now show up on the Connect Series Touch screen. You have now created a Volume Subgroup that will allow the Connect Series Touch user to be able to adjust volume for that Subgroup.
- Page 16 To adjust the source group, select the source group box, touch the source you want to select OR turn the knob to highlight the source you want to select then select “Recall”. CONNECT SERIES TOUCH - USER GUIDE | LEA Professional | Pg 16...
- Page 17 LED colors will be able to be customized. Rebooting the CS Touch – To reboot the CS Touch, click on the gear icon on the top left corner, click the LEA SharkFin logo, then click ‘OK’. The unit will now reboot. CONNECT...
- Page 18 Future Improvements The Connect Series Touch is a very versatile tool for the AV Integrator’s Toolbox. At LEA Professional, we felt it important to get this tool into the field so that our customers can benefit from the functionality the Connect Series Touch offers. LEA Professional will continue to add features to the Connect Series Touch which will be available with future firmware updated.
