CONNECT
SERIES
HALF-RACK
Mounting Installation Guide
CS34/CS34D – CS64/CS64D – CS124/CS124D

Advertisement

loading
Need help?

Need help?

Do you have a question about the Connect Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Lea Connect Series

  • Page 1 CONNECT SERIES HALF-RACK Mounting Installation Guide CS34/CS34D – CS64/CS64D – CS124/CS124D...
  • Page 2: What's In The Box

    TV, or under a table or wall mounting with rack ears, this half-rack adapts to your needs. NOTE All hardware is included with purchase of Connect Series Half-Rack. Included in the box are the following mounting hardware accessories:...
  • Page 3 Refer to the diagram below which illustrates the placement of rubber feet. INSTRUCTIONS: Place the Phillips screws (4) into each rubber foot (4). Taking a Phillips screwdriver, tighten each rubber foot into place. - Diagram 1 - Bottom Side Front Panel Half-Rack Mounting Installation Guide | LEA Professional | Pg 3...
  • Page 4 Insert the amplifier into the rack and align the holes in the rack ears with the holes on the rack. Ensure the amplifier is securely mounted to the rack using the appropriate screws (not included). - Diagram 2 - Bottom Side Bottom Side Front Panel Front Panel Half-Rack Mounting Installation Guide | LEA Professional | Pg 4...
  • Page 5 Insert the amplifier into the rack and align the holes in the rack ears with the holes on the rack. Ensure the amplifier is securely mounted to the rack using the appropriate screws (not included). - Diagram 3 - Top Side Front Panel Half-Rack Mounting Installation Guide | LEA Professional | Pg 5...
  • Page 6 Ensure the amplifier is securely mounted to the desired location using the appropriate screws (not included). - Diagram 5 - - Diagram 4 - Wall Table Side Side Front Panel Front Panel Half-Rack Mounting Installation Guide | LEA Professional | Pg 6...
  • Page 7 Attach the TV, Wall, or under-table mount to the back of the amplifier with two T10 Torx screws. Ensure the amplifier is securely mounted to the rack using the appropriate screws (not included). - Diagram 6 - Wall Back Panel Top Side Half-Rack Mounting Installation Guide | LEA Professional | Pg 7...
  • Page 8 Dimensions - Connect Series Half-Rack - Diagram 7 - 311.27mm 12.25in 311.27mm 12.25in 218.10mm 8.59in 218.10mm 8.59in 43.55mm 1.71in 43.55mm 1.71in Half-Rack Mounting Installation Guide | LEA Professional | Pg 8...
