  • Page 1 N e t w o r k CONNECTSERIES U S E R ’ S MA N U A L...

  • Page 2: Table Of Contents

    Loading Channel Speaker Tunings DSP Block Diagram ............................. 32 Glossary ..............................33-35 Power Consumption ..........................36-38 Support ..............................39-40 Sustainability Statement ........................41-42 Declaration of Conformity ......................... 43 Document Revision Date: February 4, 2020 © 2019 LEA Professional. All Rights Reserved.
  • Page 3 So, we are dedicated to providing perfect sound reinforcement through all of our products. We’re deeply proud of our Connect Series amplifiers and we can’t wait for you to get working with them. We truly believe that we’ve produced the best looking, best performing product with the best technology at the best price for you.
  • Page 4 I N T R OD U C I N G T H E WOR L D ’ S F I R S T I OT - E N A B L E D P R OF E S S I ON A L A MP L I F I E R S...

  • Page 5: Introduction

    Analog Devices 96kHZ DSP with up to 48dB/Oct filters, 8 parametric EQ’s, speaker protection limiting, and many more features controlled by a web-based UI. The Network Connect Series also features analog inputs and external I/O control for remote on/off and fault monitoring.

  • Page 6: Specifications

    Analog Input: 3 pin Amphenol Anytek, Output: 2 pin Amphenol Anytek, External IO: 3 pin Amphenol Anytek, Connectors Power in: IEC, Ethernet RJ45 In for Control ***Note: Connect Series 84, Connect Series 164, Connect Series 88, & Connect Series 168 do not have potentiometers on the rear panel The Connect Series’...
  • Page 7 SPECIFICATIONS | ProductData CONTINUED 19” / 482mm 1.72” / 43.7mm 14.2” / 360.7mm Front to back airflow (See previous page for fan noise) © 2019 LEA Professional. All Rights Reserved.

  • Page 8: Warranty

    LEA LLC liability shall be limited to the actual purchase price of any defective unit or units of LEA LLC equipment to which a claim is made, and shall in no event include the Customers’ installation costs, design costs, lost profits or goodwill, or any other direct, indirect, special, incidental or consequential damages.

  • Page 9: Safety Instructions

    13. Do not attempt to service this unit. All servicing operation. must be performed by a qualified LEA service technician. To find a qualified LEA technician, contact CAUTION: Changes or modifications not expressly your local LEA dealer/distributor.

  • Page 11: Front Panel

    Signal Presence – This indicator illuminates when there is -40db of input signal present on that assigned output channel. Channel Ready – Indicates the channel is ready to pass audio. If this indicator is off, the channel may be in standby mode or the amplifier DSP is booting up. © 2019 LEA Professional. All Rights Reserved.
  • Page 13 1 . I E C T y p e I n l e t : 6 . A n a l o g B a l a n c e d I n p u t s : F o r d e t a c h a b l e I E C C H 1 , C H 2 c o n n e c t o r .
  • Page 16 1 . I E C T y p e I n l e t : 5 . C h a n n e l Ou t p u t : F o r d e t a c h a b l e I E C C H 1 , C H 2 , C H 3 , C H 4 , c o n n e c t o r .
  • Page 18 IN THE BOX | AccessoriesKit Each Connect Series amplifier comes with an accessories kit included in the box. This kit provides you with all the essential tools to properly setup your Connect Series amplifier for the first time. Reference your kit checklist below with the part numbers on the following page to ensure you have all items included in your kit.
  • Page 19 Output Connector LEA Part #: CPP10006-1 80/160W Only* Foam Air Filter LEA Part #: MDF10001-1 3-Position Amphenol Anytek Input Connector LEA Part #: CSP10006-1 3-Position Amphenol Anytek Input Connector LEA Part #: CSP10001-1 © 2019 LEA Professional. All Rights Reserved.

  • Page 20: Getting Started

    OutOfTheBox Proper Installation 1. The LEA Connect Series is a standard 1U x 19” rack mountable product. 2. Out of the box, the rack ears will mount directly into a standard rack 3. If you wish to mount this under a table or to the wall, the rack ears can be rotated 90 degrees and gives you the ability to mount the unit to a fixed surface.
  • Page 22 1. Built-in Wi-Fi Access Point (WAP) The built in Wi-Fi access point allows for a point-to-point connection. This means you will only be able to communicate to one Connect Series amplifier at a time. Using WAP 1. Press Wi-Fi button on rear panel to activate Wi-Fi Access Point 2.

  • Page 23: Web App Ui

    Generator, Crossover, Equalizer, Limiter, and Load Monitoring. FIND THE IP ADDRESS DISPLAYED ON THE FRONT PANEL SCREEN. LEA Professional Amp#123 AP: Amp-123 10.8.3.205 ENTER IP ADDRESS IN YOUR DEVICE’S WEB BROWSER SEARCH CONTINUE TO NEXT PAGE… BAR. © 2019 LEA Professional. All Rights Reserved.

  • Page 24: Connecting To The Network

    CORRECT PASSWORD IS ENTERED (OR IF GUEST MODE IS SELECTED) YOU WILL BE TAKEN TO THE HOME SCREEN SHOWN ABOVE. NOTE: GUEST MODE IS READ-ONLY AND YOU WILL NOT BE ABLE TO MAKE ANY CHANGES © 2019 LEA Professional. All Rights Reserved.
  • Page 25 State 1 – Normal operation. “Green Menu” No errors or faults reported. screen. State 2 – Amp reporting an event but no faults.. Shortcut to State 3 – The amp is reporting “Amp Info” a fault. screen. © 2019 LEA Professional. All Rights Reserved.
  • Page 26 Pressing the “I” icon or LAN icon brings cord with a leaf icon will activate a popup you to the “Network brings you to the menu with multiple Settings” page. “Green Menu” page. amp info screens. © 2019 LEA Professional. All Rights Reserved.
  • Page 27 CH 1 Attenuation CH 1 Output Mute (always read-only) CH 1 Output Meter CH 1 Output CH 1 Ready Indicator Clip Indicator CH 1 Limiting Meter CH 1 Fault Indicator CH 1 Thermal Indicator © 2019 LEA Professional. All Rights Reserved.
  • Page 28 T H E I C O N S G E T C H A N N E L S E T T I N G S SIGNAL PARAMETRIC LOAD INPUTS SETTINGS GENERATOR CROSSOVER LIMITERS MONITORING © 2019 LEA Professional. All Rights Reserved.
  • Page 29 CLICK THE “i” ICON FROM THE IMPORT/EXPORT” FROM THE AMP’S MAIN SCREEN. POPUP MENU. PRESS “EXPORT AMP SETTINGS” A FILE WILL BE DOWNLOADED TO YOUR MAC, WINDOWS PC, OR ANDROID DEVICE. *IOS download coming soon. © 2019 LEA Professional. All Rights Reserved.
  • Page 30 Number, Power Supply Settings, and Auto Standby Settings. CHANNEL SETTINGS This check box will load the following information for each channel: All settings for - Input Section, Signal Generator, Crossover, Parametric EQ, Limiter and Load Pages. © 2019 LEA Professional. All Rights Reserved.
  • Page 31 YOUR SETTINGS WILL BE DOWNLOADED TO YOUR DEVICE. THE DOWNLOAD FILE WILL CONTAIN ALL CHANNEL INFORMATION FROM THE INPUT PAGE, SETTINGS PAGE, SIGNAL GENERATOR PAGE, CROSSOVER PAGE, PARAMETRIC EQS PAGE, LIMITERS PAGE, AND LOAD MONITORING PAGE. © 2019 LEA Professional. All Rights Reserved.
  • Page 32 CHANNEL YOU WISH TO SAVE TUNINGS FROM NAVIGATE TO THE CROSSOVER SETTINGS PAGE AND SELECT “IMPORT”. SELECT THE CHANNEL SPEAKER TUNINGS FILE FROM YOUR DEVICE THAT YOU WISH TO IMPORT AND IT WILL AUTOMATICALLY BE LOADED IN. © 2019 LEA Professional. All Rights Reserved.

  • Page 34: Glossary

    LowZ and 70V modes. In 26dB mode, the amplifiers. If you have our Connect Series 704 input sensitivity is 2.0 VRMS and allows you to amplifier with a power rating of 700 watts per achieve full output in 100V mode.
  • Page 35 © 2019 LEA Professional. All Rights Reserved.
  • Page 36 Consequently, this makes the design smaller, more efficient and cheaper for the power level. the type of PFC we are using for LEA products is Active PFC. We chose Active PFC over Passive because, Active PFC has many advantages over Passive PFC, such as: 1st –...

  • Page 37: Power Consumption

    0.39 0.39 Auto Standby (all channels) 0.07 0.07 0.07 0.07 0.07 Heat Power BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr & Watts 1/3 Power BTU/Hr & Watts 1/8 Power © 2019 LEA Professional. All Rights Reserved.
  • Page 38 0.22 0.22 Auto Standby (all channels) 0.01 0.01 0.01 0.01 0.01 Heat Power BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr & Watts 1/3 Power BTU/Hr & Watts 1/8 Power © 2019 LEA Professional. All Rights Reserved.
  • Page 39 1.22 1.22 Auto Standby (all channels) 0.19 0.19 0.19 0.19 0.19 Heat Power BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr Watts BTU/Hr & Watts 1/4 Power BTU/Hr & Watts 1/8 Power © 2019 LEA Professional. All Rights Reserved.

  • Page 40: Support

    General Support System Design Support For support when spec'ing LEA products into We have created a multitude of online resources your system designs, please contact our to help with general support topics concerning technical support team at: your amplifier or LEA Professional.
  • Page 41 For Ordering Support: Email: customercare@leaprofessional.com Phone: 574.345.0473 For Technical Support: Email: techsupport@leaprofessional.com Phone: 574.345.0474 Warranty, Service, Parts, Repair Support: Email: techsupport@leaprofessional.com Phone: 574.345.0474 Sales Support: Email: customercare@leaprofessional.com Phone: 574.345.0473 Application Support: Email: techsupport@leaprofessional.com Phone: 574.345.0474 © 2019 LEA Professional. All Rights Reserved.

  • Page 42: Sustainabilitystatement

    And we strive to Be Thoughtful whenever we approach new opportunities and projects – such as our 100% recyclable Connect Series box design – so that we can make deliberate decisions that support our sustainability goals.
  • Page 43 Their facilities undergo strict sustainability practices that have earned them ISO Certifications for Environmental Management Systems and Energy Management Systems. Their proactive approach to sustainability is a great fit for manufacturing our Connect Series amplifiers. We regularly audit the manufacturing process to ensure our environmental impact is minimal.

  • Page 44: Declaration Of Conformity

    Series 702D, Connect Series 704, Connect Series 704D The Connect Series 704D completed all required testing as the representative model for Connect Series models: Connect Series 352, Connect Series 354, Connect Series 702, Connect Series 704, Connect Series 352D, Connect Series 354D, Connect Series 702D, Connect Series 704D...
  • Page 45 2 0 1 9 L E A P R OF E S S I ON A L . A L L R I GH T S R E S E R V E D .
