USER GUIDE
The Kamille Power Comfort Wheelchair
A unique Danish designed sensory-stimulating power comfort
wheelchair
The individual fit and extreme comfort help to increase activity level and quality of life.
With electric propulsion (motor) operated with a joystick. Speed up to 5km/h.
Max. user weight 140 kg.
• Asymmetric adjustment of back system and
seat system
• Exceptionally flexible armrest
• Electrically adjustable back and electric tilt in
space as standard
• Crash tested according to ISO 7176-19.
UP TO 140 KG
• Joystick possible for patient, caregiver, or
both
• Swing away legrest as standard
• Specially developed removable, padded
body supports (optional)
• Detachable swing away legrests (optional)
Cobi Rehab and Cobi Rehab's suppliers comply with the UN conventions
on child labour and forced labour as well as ILO 029, C132 and C182.
Advertisement
Related Manuals for Cobi Rehab Kamille
Summary of Contents for Cobi Rehab Kamille
- Page 1 (optional) • Crash tested according to ISO 7176-19. • Detachable swing away legrests (optional) Cobi Rehab and Cobi Rehab's suppliers comply with the UN conventions on child labour and forced labour as well as ILO 029, C132 and C182.
- Page 2 4. Use ........................................5 5. Component overview ................................6 6. Cushion overview ..................................7 7. Adaptation of the Kamille Power Comfort Wheelchair ....................8 8. Electric tilt-in-space and back adjustment ........................14 9. Cleaning and maintenance ..............................15 11. Recycling and disposal ................................16 10.
- Page 3 Patients who are unable to stand or walk must always be lifted in and out of the Kamille Power Comfort Wheelchair. The Kamille Power Comfort Wheelchair has a max. user weight of 140 kg. The stopping distance on slopes can be significantly greater than on level ground.
- Page 4 IPX6 Water resistant 6° max. ground slope Must be disposed of through correct waste management Cobi Rehab catalogue number Serial number Transit tie-down fixing point for passenger transport in a wheelchair by car Approved according to ISO 7176-19 for passenger...
- Page 5 3. General This User Guide contains important information Please contact Cobi Rehab on +45 7025 2522 or on the Kamille Power Comfort Wheelchair’s use at cobi@cobi.dk for more information about the and target group. The user guide also contains a Kamille Power Comfort Wheelchair.
- Page 6 If the power indicator on the joystick's display shows 1-2 bars, the battery must immediately be connected for charging via the back of the joystick and charged to 100%. | 2024-04 User Guide of the Kamille Power Comfort Wheelchair...
- Page 7 8 Foot cushion, split, RL 18 Back extension cushion (additional) Back Seat 7 Full calf cushion (additional) 7RL Split calf cushion 8 Full foot cushion (standard) (additional) 8 RL Split foot cushion (standard) | 2024-04 User Guide of the Kamille Power Comfort Wheelchair...
- Page 8 7. Adaptation of the Kamille Power Comfort Wheelchair The Kamille Power Comfort Wheelchair provides functions are continuously variable, so the patient exceptional support because its design is so doesn’t experience any annoying lurches. flexible that it can support contractures in both...
- Page 9 "fall out of" or "fall over" the body support. Multiple body supports can be placed on each side for more complex needs. The body supports on the Kamille Power Comfort Wheelchair are padded with viscoelastic foam and polystyrene beads. The padded body supports comes in different sizes and with or without hoods.
- Page 10 The armrest padding contains the same type of filling as the other cushions on the Kamille Power Comfort Wheelchair. The padding increases the number of sensory stimuli and minimises the risk of pressure sores.
- Page 11 7.6 Cushion system The Kamille Power Comfort Wheelchair is equipped with a complete and unique cushion system that ensures optimal pressure distribution and near-body positioning. The cushions are filled with a mix of polystyrene beads and foam, which together contribute to increased sensory stimuli.
- Page 12 Remember to retighten the levers after adjustment. Brakes The brakes on the Kamille Power Comfort wheelchair are built into the motor. This means that when the joystick is released, the wheelchair stops. The Kamille Power Comfort wheelchair is not equipped with an emergency stop device, as the wheelchair cannot move on its own.
- Page 13 The electronics are IPX4-rated. This means that control box is connected to the joystick. The plug the Kamille Power Comfort Wheelchair and its for the wheelchair charger is located at the back components can withstand light rain. of the joystick. Read more in the Joystick The Kamille Power Comfort Wheelchair is not section.
- Page 14 8. Electric tilt-in-space and back adjustment The Kamille Power Comfort Wheelchair comes The anti-shear recline function on the Kamille with an electrically adjustable back (recliner) and Power Comfort Wheelchair is unique. The electric tilt-in-space as standard. This provides electrically adjustable back minimises the risk of...
- Page 15 +45 7025 2522. the maintenance that the Kamille Power Comfort In the event of any irregularities in the Kamille Wheelchair needs. Power Comfort Wheelchair, all items in the wear & tear and maintenance overview should be...
- Page 16 Monitor the battery capacity as it will discharge over time. 11. Recycling and disposal A Kamille Power Comfort wheelchair which is no longer in use should be disposed of in an environmentally sound manner. If necessary, contact the local authority for further information on disposal.
- Page 17 Cobi Rehab can carry out such an assessment at After the expected service life, Cobi Rehab any time. cannot guarantee the suitability and safety of the product, as Cobi Rehab has no control over the product’s use and wear.
- Page 18 Steel Wheel forks Aluminium Battery Li-Ion 24V 22.4 Ah Actuators/Control box/joystick LINAK LA23/ Curtiss -Wright R-net PM120/ R-net JSM-LCD Electric wheelchair, including components DS/EN 12183: 2014, according to ISO 7176 | 2024-04 User Guide of the Kamille Power Comfort Wheelchair...
- Page 19 Weighted neck cushion 0350-999-475 Weighted calf cushion blanket 0350-999-477 Table 0100-999-001 Complete cushion set, Kamille Power Comfort Wheelchair, S 0350-999-402 Complete cushion set, Kamille Power Comfort Wheelchair, M 0350-999-404 Complete cushion set, Kamille Power Comfort Wheelchair, L 0350-999-406 Back cushion 1, S...
- Page 20 Skirt guard stretch cover 0350-999-563 Legrest split stretch cover, R 0350-999-565R Legrest split stretch cover, L 0350-999-565L Flex arm support stretch cover, R 0350-999-575R Flex arm support stretch cover, L 0350-999-575V | 2024-04 User Guide of the Kamille Power Comfort Wheelchair...
- Page 21 Back extender black nylon cover, S 0359-999-585 Back extender black nylon cover, M 0359-999-586 Back extender black nylon cover, L 0359-999-587 Legrest black nylon cover, R 0350-999-590R Legrest black nylon cover, L 0350-999-590L | 2024-04 User Guide of the Kamille Power Comfort Wheelchair...
- Page 22 DEALER AND MANUFACTURER Cobi Rehab Fuglebækvej 1D DK-2770 Kastrup Denmark +45 7025 2522 cobirehab.com | 2024-04 User Guide of the Kamille Power Comfort Wheelchair...
