USER MANUAL
Cobi Cruise Power
Cobi Cruise Power comfort wheelchair. The most powerful wheelchair on
the market for use in the rehabilitation of bariatric users.
Cobi Cruise Power comfort wheelchair is used in care centres and hospitals, in home
care and in private homes for bariatric users in need of a comfort wheelchair with a
pressure-relieving seat.
•
Used in all phases of rehabilitation, from the
bedridden user to the mobile user.
•
Cobi Cruise Power is equipped with electric
propulsion, tilt-in-space and recline
functions which are activated via a joystick
and operated by both user and care staff.
Scan or click on the code and
find the product at the HMI base.
bariatric comfort wheelchair
•
Armrests that can be angled and pushed
away for e.g., transfers or social activities
at a table.
•
Disinfectable and washable in laundry
room at e.g., a depot or a hospital.
•
Fits through most doorways.
Cobi Rehab and Cobi Rehab suppliers comply with the UN conventions
on child labour and forced labour as well as ILO 029, C132 and C182.
UP TO 325 KG
Advertisement
Table of Contents
Related Manuals for Cobi Rehab Cruise Power
Summary of Contents for Cobi Rehab Cruise Power
- Page 1 Cobi Cruise Power comfort wheelchair is used in care centres and hospitals, in home care and in private homes for bariatric users in need of a comfort wheelchair with a pressure-relieving seat.
-
Page 2: Table Of Contents
11. Transport and storage ................................12 12. Recycling and disposal ................................13 13. Warranty ...................................... 13 14. Specifications .................................... 14 16. Accessories and spare parts ............................... 16 15. Technical data: Charger ................................ 16 | 12-2020 User Manual Cobi Cruise Power... -
Page 3: Safety
325 kg increases the risk of damaging the wheelchair. Read this user manual carefully before using the Cobi Cruise Power comfort wheelchair. Pay particular attention to Safety Instructions marked Cobi Rehab assumes no responsibility for any damage to the product nor for personal injury caused by incorrect installation, incorrect mounting or incorrect use of the Cobi Cruise Power wheelchair. -
Page 4: Indications
Consult the manual CE-Label located at the frame. See an example of CE-Label beneath. 2.1 Counter-indications Always monitor and guide users with reduced cognitive function in the use of the electrical functions of the wheelchair. | 12-2020 User Manual Cobi Cruise Power... -
Page 5: General Comments
3. General comments This user guide contains important information Cobi Rehab reserves the right to change the about the use of Cobi Cruise Power and the product specifications without providing prior target group for the wheelchair. It also includes a notice. -
Page 6: Construction
5. Construction Cobi Cruise Power is constructed from type-S355, high-tensile steel. The rectangular steel profiles of the chair form the basis for its base frame. The base frame is made up of two mirror-inverted parts (a right and a left part) connected by a centre module. - Page 7 The leg rests may be removed without the use of tools without affecting stability. Do not use the leg rests when getting in and out. The leg rests can be dismantled without using tools. | 12-2020 User Manual Cobi Cruise Power...
- Page 8 Risk of tipping when anti-tip is removed. 5.8 Brakes The brake of the Cobi Cruise Power is integrated into the motor. This means that when the joystick is disengaged, the wheelchair stops. 5.9 Actuators The Cobi Cruise Power has three actuators.
-
Page 9: Electric Tilt-In-Space And Recline
When the back and seat are tilted into an unstable function, speed options are restricted. This is indicated by an orange or red turtle being displayed. | 12-2020 User Manual Cobi Cruise Power... -
Page 10: Travel
When driving on sloping ground, drive as straight as The wheelchair can traverse edges and doorsteps possible. of up to 50 mm. Cobi Cruise Power is also built to be able to drive up and down hills and ramps of a 8. Before use... -
Page 11: Possible Adjustments
9.3 Measuring the user Always measure the user when the user is seated. If help is needed in terms of measuring the user, please contact Cobi Rehab on telephone +45 7025 2522 or at cobi@cobi.dk. Risk of crushing or getting caught Be careful not to get the user’s tissue or fingers caught when adjusting the arm rests. -
Page 12: Maintenance And Cleaning
When transporting Cobi Cruise Power, we strongly recommend adjusting the seat to 0° position as a minimum. If at all possible, we recommend adjusting the seat to a -4° position. We also recommend adjusting the back to 97°... -
Page 13: Recycling And Disposal
13. Warranty Cobi Rehab warrants that the Cobi Cruise Power This warranty does not apply when Cobi Rehab comfort wheelchair is without defects on delivery. assesses that the Cobi Cruise Power comfort If, against all expectations, the wheelchair is wheelchair has been improperly operated. -
Page 14: Specifications
Covered in incontinence cover (G469 black), flame-retardant Arm rest cushion Foam (CMHR4250 and RF5060), cover durable imitation leather (Temskay Leather), flame-retardant Cushion in foot and lower leg support Foam (CMHR4038), cover durable imitation leather (Temskay Leather), flame-retardant | 12-2020 User Manual Cobi Cruise Power... - Page 15 Control box Curitss-Wright R-net PM120 Joystick R-net JSM-LCD Electric wheelchair, including components DS/EN 12184: 2014, in accordance with ISO 7176 IP-code IPX4 Risk assessment EN/ISO 14971: 2012 General requirements and test methods EN 12182:2012 | 12-2020 User Manual Cobi Cruise Power...
-
Page 16: Accessories And Spare Parts
0115-999-007 Cobi Cruise IV-holder with installation bracket(s) 0115-999-090 Neck support Contact us for the choice of neck support For spare parts, please contact Cobi Rehab on telephone +45 7025 2522 or at cobi@cobi.dk | 12-2020 User Manual Cobi Cruise Power... - Page 17 MANUFACTURER Cobi Rehab Fuglebækvej 1D DK-2770 Kastrup Danmark +45 7025 2522 cobirehab.com | 12-2020 User Manual Cobi Cruise Power...
