USER MANUAL
Cobi Cruise
Cobi Cruise comfort wheelchair. The most powerful wheelchair on the
market for use in the rehabilitation of bariatric users.
Cobi Cruise comfort wheelchair is used in care centres and hospitals, in home care and
in private homes for bariatric users in need of a comfort wheelchair with a pressure-
relieving seat.
•
Used in all phases of rehabilitation, from the
bedridden user to the mobile user.
•
Cobi Cruise is equipped with tilt-in-space
and recline functions which are activated
via a controller and operated by both user
and care staff.
bariatric comfort wheelchair
Cobi Rehab and Cobi Rehab suppliers comply with the UN conventions
•
Armrests that can be angled and pushed
away for e.g., transfers or social activities
at a table.
•
Disinfectable and washable in laundry
room at e.g., a depot or a hospital.
on child labour and forced labour as well as ILO 029, C132 and C182.
UP TO 325 KG
Advertisement
Table of Contents
Related Manuals for Cobi Rehab Cruise
Summary of Contents for Cobi Rehab Cruise
- Page 1 Cobi Cruise comfort wheelchair. The most powerful wheelchair on the market for use in the rehabilitation of bariatric users. Cobi Cruise comfort wheelchair is used in care centres and hospitals, in home care and in private homes for bariatric users in need of a comfort wheelchair with a pressure- relieving seat.
-
Page 2: Table Of Contents
8. Possible adjustments ................................11 9. Maintenance and cleaning ..............................12 10. Transport and storage ................................12 11. Recycling and disposal ................................13 12. Warranty ...................................... 13 13. Specifications ..................................... 14 14. Accessories and spare parts ............................... 15 | 04-2022 User Manual Cobi Cruise... -
Page 3: Safety
Cruise comfort wheelchair. Always take care when using the tilt-in-space and recline function to avoid jerky movements. The maximum user weight of the Cobi Cruise comfort wheelchair is 325 The stopping distance on slopes can be significantly longer than on even ground. -
Page 4: Indications
Consult the manual CE-Label located at the frame. See an example of an CE-label below. 2.1 Counter-indications Always monitor and guide users with reduced cognitive function in the user of the electrical functions of the wheelchair. | 04-2022 User Manual Cobi Cruise... -
Page 5: General Comments
3. General comments This user guide contains important information Cobi Rehab reserves the right to change the about the use of Cobi Cruise and the target group product specifications without providing prior for the wheelchair. It also includes a wide range of notice. -
Page 6: Construction
5. Construction Cobi Cruise is constructed from S355 high-tensile steel. The rectangular steel profiles of the chair form the basis for its base frame. The base frame is made up of two mirror-inverted parts (a right and a left part) connected by a centre module. - Page 7 The leg rests may be removed without the use of tools without affecting stability. Do not use the leg rests when getting in and out. The leg rests can be dismantled without using tools. | 04-2022 User Manual Cobi Cruise...
- Page 8 A universal neck support bracket permits the wheelchair. installation of several types of neck supports. 5.7 Anti-tip Cobi Cruise is installed with anti-tip that can be adjusted to suit the terrain. Only remove the Anti- tip when transporting the wheelchair without a user.
-
Page 9: Electric Tilt-In-Space And Recline
5 seconds, after which the various functions can be accessed again. The controller has: • A battery indicator • Tilt-in-space function • Recline function • RESET function | 04-2022 User Manual Cobi Cruise... -
Page 10: Before Use
• Tilt the wheelchair backwards • Slide back one arm rest. Lift user sideways into the chair • Swivel back the footrests • Slide back the arm rest. | 04-2022 User Manual Cobi Cruise... -
Page 11: Possible Adjustments
Adjust the calf rest. support to provide the user with both support The neck support bracket of the Cobi Cruise is and relief of the calves. universal. This allows for the installation of the The angle of the arm rests can be height-adjusted most suitable neck support. -
Page 12: Maintenance And Cleaning
When transporting Cobi Cruise, we strongly recommend adjusting the seat to 0° position as a minimum. If possible, we recommend adjusting the seat to -4° position. We also recommend adjusting the back to 97° or less. -
Page 13: Recycling And Disposal
12. Warranty Cobi Rehab warrants that the Cobi Cruise comfort This warranty does not apply when Cobi Rehab wheelchair is without defects on delivery. If, assesses that the Cobi Cruise comfort wheelchair against all expectations, the wheelchair is subject has been improperly operated. -
Page 14: Specifications
Cushion in foot and lower leg support Foam (CMHR4038), cover durable imitation leather (Temskay Leather), flame-retardant Push bar S355 high-tensile steel Wheel forks Aluminium Footrest tubing Steel Foot plate S355 High-tensile steel Turning radius (Pivot) 100-120 cm | 04-2022 User Manual Cobi Cruise... -
Page 15: Accessories And Spare Parts
Elevation leg rest L 0115-999-007 Cobi Cruise IV-holder with installation bracket(s) 0115-999-090 Neck support Contact us for the choice of neck support For spare parts, please contact Cobi Rehab on telephone +45 7025 2522 or at cobi@cobi.dk | 04-2022 User Manual Cobi Cruise... - Page 16 MANUFACTURER Cobi Rehab Fuglebækvej 1D DK-2770 Kastrup Denmark +45 7025 2522 cobirehab.com | 04-2022 User Manual Cobi Cruise...
