USER MANUAL
Eclipse – Bariatric Wheelchair
Manuel wheelchair in timeless design intended for users up to 270 kg.
Also available in a reinforced version for user weight up to 450 kg.
Customization options.
Eclipse Wheelchair is intended users in need of a comfort wheelchair with a pressure-
relieving seat in care centers, hospitals and private homes.
•
Used in rehabilitation of the mobile user.
•
Possible to adjust the seat depth and
inclination as well as the angle of the
backrest in relation to the seat and the seat
height.
Scan the code and find more
information about the product on
the
website.
•
Prolonged armrests make it easier to get
in or out the wheelchair.
•
Disinfectable.
•
Fits through most doorways.
Cobi Rehab and Cobi Rehab suppliers comply with the UN conventions
on child labour and forced labour as well as ILO 029, C132 and C182.
UP TO 270/450 kg
Advertisement
Table of Contents
Related Manuals for Cobi Rehab Eclipse
Summary of Contents for Cobi Rehab Eclipse
- Page 1 Also available in a reinforced version for user weight up to 450 kg. Customization options. Eclipse Wheelchair is intended users in need of a comfort wheelchair with a pressure- relieving seat in care centers, hospitals and private homes. UP TO 270/450 kg •...
-
Page 2: Table Of Contents
8. Cleaning and maintenance ..............................19 9. Transport and storage ................................19 10. Recycling and disposal ................................. 20 11. Warranty ...................................... 20 12. Specifications ..................................... 21 13. Accessories and spare parts .............................. 22 14. Troubleshooting ..................................23 | 2021-07 User manual Eclipse Wheelchair... -
Page 3: Safety
Do not tilt Eclipse Wheelchair without assistance. Never stand on the frame of the Eclipse Wheelchair. Do not stop an Eclipse Wheelchair from moving using the wheel brakes. Lock both wheels when moving to and from the Eclipse Wheelchair. Only use the Eclipse Wheelchair on even surface. - Page 4 Do not lift the Eclipse Wheelchair in the detachable parts (armrests, wheels, backrests, footrests, etc.). Do not remove the anti-tip supports. Do not use the footrests to stand on during entry and exit of the Eclipse Wheelchair. The user must not attempt to reach objects that require the user to move forward in the seat.
-
Page 5: Symbols
2. Symbols Caution! Declaration of conformity, Medical Device Regulation, EU 2017/745 Manufacturer Medical device CE labels on the product is located on frame. See example of label below. | 2021-07 User manual Eclipse Wheelchair... -
Page 6: General Comments
3. General comments This user manual contains important information Cobi Rehab reserves the right to change the about the use of Eclipse Wheelchair and the product specifications without providing prior target group for the wheelchair. It also includes a notice. -
Page 7: Construction
5. Construction Eclipse is a manual fixed frame wheelchair, which is built with a strong steel frame, which provides maximum strength, rigidity, and long durability. It is designed so most of the user's weight rests on the rear wheels. The tires are extra hard and massive, which makes propulsion and steering easy. - Page 8 With attention to technique and practice of The construction of the Eclipse Wheelchair transfer techniques, the user can feel safe and get secures stability and balance.
-
Page 9: Assembly And Adjustment
6. Assembly and adjustment Upon receipt, check that the cardboard box One Eclipse wheelchair back with built-in contains push bar. One Eclipse frame with two rear wheels If leg rests, headrest or Transit Tie-Down System with quick-release axles, and two front... - Page 10 The straps on the back of the back padding can (Eclipse Grow-kit) from Cobi Rehab must be used. be adjusted by either loosening or tightening The Eclipse Grow kit contains a seat plate, a them. backrest and padding as well as five cross frame tubes.
-
Page 11: Illustration Of Adjustment Options
3. Reinstall the hardware and tighten securely. 4. Repeat this procedure for the other footrest and replace padding and/or calf strap, if fitted. Please note that the foot plate pictured is not sold by Cobi Rehab. Fig. 2: Standard Swing-Away Footrest Height Adjustment... - Page 12 3. Re-install the ¼-20 x 1-3/4” socket button head in the eyelet of the linear locking device and securely tighten 4. Repeat the procedure for the other footrest. Fig. 5 Elevating Leg Rest Footrest Height Adjustment. | 2021-07 User manual Eclipse Wheelchair...
- Page 13 Armrest pad should sit flush against frame. If the pad is cracked or retaining screws are Fig. 7: Adjusting Armrest Height for Dual Post Arms. stripped, replace immediately. | 2021-07 User manual Eclipse Wheelchair...
- Page 14 Adjustment of seat depth After adjusting, always make sure that parts are properly tightened before using the wheelchair. The seat depth on the Eclipse Wheelchair can be adjusted from 16” to 22”, depending on the position of the backrest post receivers. Seat depths 23”...
- Page 15 Reclining Backrest (Not compatible with removeable backrest) The Eclipse Wheelchair is available with the option of a manual reclining backrest that allows for up to 30° of backrest recline. It is not compatible with the backrest extension and is 2.5 cm narrower than the seat width.
- Page 16 Anti-Tip Tubes The anti-tip holders are bolted to the frame. The anti-tip supports have two length adjustment options. Do not operate the Eclipse Wheelchair without anti-tippers installed. Anti-tippers are mandatory for safety and warranty protection. To install the anti-tip tubes 1.
- Page 17 5. If it is too difficult to engage the wheel lock, loosen the ¼-20 bolts and nuts and slide the wheel lock away from the wheel slightly. Tighten the bolts again and test the performance. Fig. 16: Wheel Lock installation. | 2021-07 User manual Eclipse Wheelchair...
- Page 18 After adjusting, always make sure that parts are properly replaced and tightened before using the wheelchair. The seat to floor height on the Eclipse can be adjusted 14” to 18”, and up to 20” with a seat height extension. The front and rear seat heights can be adjusted independently, and the front can be up to 2”...
-
Page 19: Cleaning And Maintenance
Local cleaning and disinfection procedures must always be followed. 9. Transport and storage When Eclipse Wheelchair is not in use store it dry and in temperatures between -10° – 50° C. Eclipse Wheelchair is (without user) suitable for land- and air freight. Eclipse Wheelchair is not foldable. -
Page 20: Recycling And Disposal
Eclipse Wheelchair. 11.1 Unintended event Report any incidents relating to the use of Eclipse Wheelchair to Cobi Rehab. 11.2 After expiry of expected service life After the expected service life, it is important that... -
Page 21: Specifications
Footrest tubes 6061-T6 Aluminium Footplate 6061-T6 Aluminium/nylon with fiberglass Turning radius (Pivot) 1545 mm Foldable Risk assessment EN/ISO 14971: 2012 General requirements and test methods ISO 7176-1, -3, -5, -7, -8, -13, -15 og -22 | 2021-07 User manual Eclipse Wheelchair... -
Page 22: Accessories And Spare Parts
Footrest swing away left 0120-999-008 Footrest swing away right 0120-999-009 Footrest elevation, right 0120-999-006 Footrest elevation, left 0120-999-007 Transit Tie-Down System 0120-999-065 For other spare parts please contact Cobi Rehab +45 7025 2522 or cobi@cobi.dk | 2021-07 User manual Eclipse Wheelchair... -
Page 23: Troubleshooting
Slow turning or driving The front castors vibrate The wheelchair pulls to the right The wheelchair pulls to the left Check that both front wheels touch the ground at the same time The front castors vibrate | 2021-07 User manual Eclipse Wheelchair... - Page 24 Cobi Rehab PDG Product Design Group Inc. Fuglebækvej 1D #103-318 East Kent Avenue South, DK-2770 Kastrup Vancouver Danmark BC V5X 4N6 +45 7025 2522 Tel.: (604) 323-9220 cobirehab.com Fax: (604) 323-9097 E-mail: info@pdgmobility.com www.pdgmobility.com | 2021-07 User manual Eclipse Wheelchair...
