Install the Cisco NCS 1020 Modules
This chapter contains procedures to install the modules of Cisco NCS 1020.
Note
Note
•
•
•
•
•
•
•
•
•
Install the Controller/Controller Filler
Use this procedure to install the controller into the Cisco NCS 1020 chassis. The chassis can accommodate
up to two controllers.
Note
Attention
In this chapter, "front fan tray" refers to the NCS1010-FAN tray, "rear fan tray" refers to the NCS1020-FAN
tray, and "filler fan tray" refers to the NCS1020-FAN-BLANK tray. Front fan trays and rear fan trays contain
a different set of fan units. Slots for the front fan trays and rear fan trays are not interchangeable.
In this chapter, "Type 1 line card" refers to "NCS 1010 line card" and "Type 2 line card" refers to "NCS 1014
line card".
Install the Controller/Controller Filler, on page 1
Install the Type 1 Line/Filler Card, on page 4
Install the Front Fan Trays, on page 7
Attach the Fiber Management Bracket, on page 9
Install the Type 2 Line/Filler Card, on page 9
Install the Solid State Drive (SSD), on page 11
Install the Power Supply Units (PSUs), on page 13
Install the Rear Fan/Filler Fan Trays, on page 16
Install the Front Door, on page 19
This procedure also applies to controller filler installation.
The following table shows controller assignment for the Type 1 line and filler cards.
Install the Cisco NCS 1020 Modules
1
