Prepare to Install Cisco NCS 1020
This chapter explains how to prepare for the Cisco NCS 1020 installation.
•
•
Package Contents
You can order Cisco NCS 1020 as an assembled chassis (NCS1020-SYS) or as an empty chassis (NCS1020-SA)
along with the components.
The shipped package contains the following:
• Cisco NCS 1020 chassis.
Note
• Accessory kit (NCS1020-19-KIT)―Includes all the hardware necessary for the chassis installation on
Package Contents, on page 1
Unpack and Verify the Cisco NCS 1020 Chassis, on page 2
When you order a spare or ATO chassis, it comes with a torx head screwdriver.
the 19" rack. You can order the accessory kits for ETSI (NCS1020-ETSI-KIT) and 23" ANSI
(NCS1020-23-KIT) racks as required. The following table describes the contents of the accessory kits.
Table 1: Accessory Kit Contents
Accessory Kit
NCS1020-19-KIT
Contents
This kit has the following items for chassis installation on a 19" rack:
• Left bracket (1x)
• Right bracket (1x)
• M4 flat torx head screws to assemble brackets on chassis (38x)
• 12-24 pan head rack mount screws (24x)
• Double hole ground lug (1x)
• M5 pan head screws for ground lug (2x)
• Lock washer for ground lug (2x)
Prepare to Install Cisco NCS 1020
1
