Summary of Contents for Flow Paragliders FUSION LIGHT S
- Page 2 WELCOME “Flow is a term used to describe the complete (body-mind-soul) feeling of being so totally engaged in an activity that there is a sense of complete immersion in the experience. Self-conscious thoughts give way to feeling at one with the activity and the environment, and time is no longer an ever-present consideration.”...
- Page 3 8.2. Frontal Collapse ..............8 Table of Contents 9. Full Stall ..................8 10. Flying without Brakes ..............9 1. General Information ..............1 11. Cravats ..................9 2. Certification ................1 12. SIV ....................9 3. Pilot’s Profile ................2 13.
- Page 4 General Information User manual for Fusion LIGHT S, Fusion LIGHT M and Fusion LIGHT ML This manual offers all the necessary information that will familiarise you with the main characteristics of your new paraglider. Although this manual informs you about your glider, it does not offer the instruction requirements necessary for you to be able to pilot this type of wing. Flying instruction can only be taught at a paragliding school recognized by the flying federation of your country.
- Page 5 GAME CHANGER. Special attention was also given on the handling, especially the turn ability whilst circling in thermals. For us at Flow paragliders we are delighted by how the glider behaves and it is hands down one of the most pleasant gliders we’ve ever...
- Page 6 SPECIFICATIONS Flat Area 22.95 m2 24.45 m2 26.3 m2 PROJECTED AREA 19.56m2 20.89m2 22.47m2 Flat Wingspan 12.07m 12.48m 12.94m PROJECTED SPAN 9.73 m 10.06 m 10.43 m Aspect Ratio 6.35 6.35 6.35 Projected AR 4.86 4.86 4.86 Max Chord 2.38 2.45 2.54 Number of cells 68...
- Page 7 TAKE-OFF, FLIGHT, AND FLYING TECHNIQUES The Flow Fusion LIGHT should be flown as a normal paraglider. However, there are several points listed below which should help you to familiarize with your new paraglider. Fusion LIGHT was designed as a foot launchable solo paraglider and can also be tow-launched. It is the pilot’s responsibility to use suitable harness attachments and release mechanisms and to ensure that they are correctly trained on the equipment and system employed.
- Page 8 Landing Because of the exceptional glide for this type of glider, high caution is recommended in the stages of approaching and landing. The Fusion is a fast glider, any action on the brakes may cause significant reactions. It is therefore recommended to execute the first flights in a familiar environment and under easy conditions.
- Page 9 • B-line Stall Due to the hybrid 3-2 line layout, B–line stall is not an efficient and stable descent manoeuvre on the Fusion, therefore not recommende. • Big Ears : Big ears is a moderate descent method, reaching -3 or -4 m/s, speed reduces slightly between 3 and 5 km/h and piloting becomes limited.
- Page 10 permanently. Use of the speed bar increases the maximum speed of the paraglider by up to 30% of the trim speed. However, it does reduce the angle of attack and therefore there is a risk of a frontal (or asymmetric) collapse. We therefore do not advise to use the speed bar near the ground. C Riser Steering –...
- Page 11 FULL STALL Certain behaviour or weather conditions can cause a full stall. This is a serious deviation from normal flight and can be difficult to manage. If a stall occurs at less than 100 m above the ground, throw your reserve parachute. Main causes of a full stall: •...
- Page 12 All manoeuvres should be carried out under supervision of experienced paragliding instructors, above water and with a rescue boat. ADJUSTMENT OF THE HARNESS For test flights, the pilots used ABS harnesses with the following set-up: SIZE Distance from seat board Distance between hang points FUSION LIGHT S 43cm 44cm FUSION LIGHT M 43cm 46cm...
- Page 13 MAINTENANCE & CHECKS Fusion LIGHT is a lightweight equipment and extra care should be paramount and in its maintenance and as any flying aircraft it should be technically periodically checked to ensure proper airworthiness. Maintenance Tips The life of your paraglider therefore depends largely on the care which you maintain and use it. To maximize life span of your wing, respect the following rules: •...
- Page 14 WARRANTY Flow paragliders’ warranty covers any material defects or any production fault for two years or 250 hours since the date of purchase. The guarantee does not cover: •...
- Page 15 LINE PLAN...
- Page 16 RISER DIAGRAM Size S, M NON-ACCELERATED ACCELERATED 500mm 375mm 495mm 435mm 580mm 515mm 500mm 500mm Difference should not be more than +/- 5mm Size ML NON-ACCELERATED ACCELERATED 500mm 365mm 495mm 430mm 580mm 510mm 500mm 500mm Difference should not be more than +/- 5mm...
- Page 17 OVERALL ILLUSTRATION...
- Page 18 Ronstan - Australia In case of any doubts regarding the information in the manual contact your FLOW PARAGLIDERS dealer. For spare parts or information in how to obtain them get in contact with us directly or with your local dealer.
- Page 19 +/- 10mm. The changes that could appear are a slight shrink on the C’s and/or a slight stretch on the A’s and B’S The consequences of these changes can include a slower trim speed, difficult inflation etc. Dimensions given in the user's manual was checked by the testing laboratory FUSION LIGHT S Brake 7330...
- Page 20 FUSION LIGHT M Brake 7440 7534 7555 7615 7934 7411 7509 7527 7590 7693 7378 7480 7485 7570 7533 7385 7493 7486 7575 7571 7327 7425 7415 7360 7285 7383 7364 7198 7201 7299 7281 7148 7200 7305 7291 7304 7085 7188 7163...
- Page 21 FUSION LIGHT ML Brake 7883 7769 7831 7919 8089 7857 7740 7812 7893 7877 7823 7705 7769 7860 7705 7824 7711 7776 7867 7747 7748 7659 7734 7568 7704 7611 7710 7415 7618 7526 7604 7365 7626 7527 7607 7485 7470 7400 7487...
- Page 22 FUSION LIGHT L Brake 8222 8077 8143 8234 8415 8195 8048 8115 8203 8221 8143 8013 8102 8194 8060 8148 8021 8109 8199 8086 8085 7976 8052 7871 8039 7930 8008 7718 7951 7841 7924 7663 7956 7845 7934 7776 7793 7705 7795...
- Page 23 LINE TYPE (for Fusion S, M and ML) Name Manufacturer Name Manufacturer Name Manufacturer Name Manufacturer Name Manufacturer 8000U-90 8000U-90 8000U-50 8000U-50 8000U-50 8000U-90 8000U-90 8000U-50 8000U-50 8000U-50 8000U-90 8000U-90 8000U-50 8000U-50 8000U-50 8000U-90 8000U-90 8000U-50 8000U-50 8000U-50 8000U-90 8000U-90 8000U-50 8000U-50 8000U-50...
