Operation and Maintenance Manual
Corded Remote Pendants & Extension Cord
Models CC131, CC132 & CC010
Document Number: L4609
Document Revision: C
Document Revision Date: January, 2023
Document Language: English EN
To reduce the risk of injury, user must read
and understand this document before use.
Advertisement
Related Manuals for Enerpac CC131
Summary of Contents for Enerpac CC131
- Page 1 Operation and Maintenance Manual Corded Remote Pendants & Extension Cord Models CC131, CC132 & CC010 Document Number: L4609 Document Revision: C Document Revision Date: January, 2023 Document Language: English EN To reduce the risk of injury, user must read and understand this document before use.
- Page 2 When safety and precision matters, elite professionals in industries such as aerospace, infrastructure, manufacturing, mining, oil & gas and power generation rely on Enerpac for quality tools, services and solutions. For additional information, visit www.enerpac.com. WARRANTY Refer to the Enerpac Global Warranty document for terms and conditions of the product warranty.
- Page 3 In the event that Safety Alert Symbols are used in any questions or concerns arise, contact conjunction with certain Signal Words Enerpac or a local Enerpac distributor for that call attention to safety messages clarification. or property damage messages and Save these instructions for future use.
- Page 4 WARNING technician. For repair service, contact Failure to observe and comply with an Enerpac authorized service center the following precautions could result in your area. in death or serious personal injury. Property damage could also occur.
- Page 5 Models CC131 and CC132 with an 8 pin pendant receptacle. Two pendant models are available. Model CC131 features a 10 ft [3 m] cord. Model CC132 features a 20 ft [6 m] cord. The pendants can be easily connected Enerpac declares that the model CC131...
- Page 6 [3 m] [60 mm] • For use with compatible Enerpac products equipped with an 8 pin pendant receptacle. • Total length of pendant and multiple CC010 extension cords must not exceed 100 ft [30 m]. • Pendant wiring and controls rated at 50 volts DC and 100 mA maximum.
- Page 7 6.0 FEATURES Key: 5. Overmolded Hand Grip 1. Pendant Housing 6. Lanyard Loop 2. Controls (See Section 7.0) 7. Product Nameplate 3. Pendant Cord 8. Hanger Magnet 4. Connector with Threaded Collar 9. Threaded Hole (1/4-20 UNC) L4609_c...
- Page 8 Button 2 Button 3 • The pendant is primarily designed for use with Enerpac electric and battery powered pumps. But it can also be used with other compatible Enerpac products. • The pendant contains three momentary contact push buttons. Button names and functions will vary, depending on the connected device and its functions.
- Page 9 8.0 CONNECTION PROCEDURE 1. Remove the dust cap from the receptacle on the pump (or other compatible Enerpac product). 2. Align pins and connect the pendant cord. 3. Hand tighten the threaded collar to secure the connection. L4609_c...
- Page 10 9.0 REPAIR PARTS DIAGRAM Notes: Torque to 8-9 in-lbs [0.9 - 1.1 Nm]. L4609_c...
- Page 11 Part Number Housing, Top DD8525001SR Button Controls DD8531369SR Printed Circuit Board DD8527829SR Cord, 10 ft [3 m] long (Model CC131) DD8785960SR Cord, 20 ft [6 m] long (Model CC132) DD8786960SR Housing, Bottom DD8524001SR Screw, M4 x 10 (included with items 1 and 5)
- Page 12 ENERPAC TOOL gROuP CORP N86 W12500 Westbrook Crossing Menomonee Falls, WI 53051, USA © 2023 Enerpac Tool Group, All Rights Reserved. www.enerpac.com...
