  • Page 1 Altos BrainSphere T350 F5 User Manual Rev. 1.0...
  • Page 2 Altos Computing Inc. (abbr. Altos) is established in 2017 and it is a subsidiary of Acer Inc. The business model of Altos is to provide the best streamlined and cost-effective integrated solutions thru in-house R&D working with ODM/IHV/ISV on servers, workstations, thin client,...
  • Page 3 Table of Contents SB.RU411.001 Motherboard Layout ................5 Block Diagram ....................7 System component identification……………………………………………….7 Chapter 1 Hardware Installation ................. 8 Installation Precautions ................8 Product Specifications ................... 9 Installing and Removing the CPU and Heat Sink ........12 Installing and Removing Memory ............13 1-4-1 8-Channel Memory Configuration ................
  • Page 4 - 3 - 2-3-1 Processor Configuration ..................57 2-3-2 Common RefCode Configuration ..............60 2-3-3 UPI Configuration ....................62 2-3-4 Memory Configuration ..................63 2-3-5 IIO Configuration ....................66 2-3-6 Advanced Power Management Configuration ............68 2-3-7 PCH Configuration ....................70 2-3-8 Miscellaneous Configuration ................
  • Page 5 - 5 -...
  • Page 6 Item Code Description SW_ID ID Button with LED USB3_MLAN1 Server Management LAN Port (Top)/USB 3.0 Ports (Bottom) 10GLAN1 10GbE LAN Port #1 (MD72-HB2 Supported) 10GLAN2 10GbE LAN Port #2 (MD72-HB2 Supported) LAN1_2 GbE LAN Port #1 (Top)/GbE LAN Port #2 (Bottom) COM1 PJ45 Type Serial Port VGA port...
  • Page 7 Block Diagram System component identification - 7 -...
  • Page 8 Chapter 1 Hardware Installation Installation Precautions The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's manual and follow these procedures: • Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.
  • Page 9 Product Specifications NOTE: We reserve the right to make any changes to the product specifications and product-related information without prior notice.  E-ATX Form Factor  305W x 330D (mm)  3rd Generation Intel® Xeon® Scalable Processors  Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel®...
  • Page 10  Internal I/O 1 x 24-pin ATX main power connector  Connectors 2 x 8-pin ATX 12V power connectors  1 x 6-pin PCIe power connectors  3 x SlimSAS connectors  2 x 7-pin SATA connectors  2 x M.2 slots ...
  • Page 11 Aspeed® AST2600 Management Controller Smart Console remote monitoring (AMI MegaRAC SP-X) Web Interface  Dashboard  JAVA Based Serial Over LAN  HTML5 KVM  Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)  Sensor Reading History Data  FRU Information ...
  • Page 12 Installing and Removing the CPU and Heat Sink Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.
  • Page 13 Installing and Removing Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended to use memory of the same capacity, brand, speed, and chips. • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.
  • Page 14 1-4-2 Installing and Removing a Memory Module Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. Be sure to install DDR4 DIMMs on this motherboard. Follow these instructions to install a DIMM module: Insert the DIMM memory module vertically into the DIMM slot and push it down.
  • Page 15 1-4-4 Processor and Memory Module Matrix Table CPU0 CPU1 Memory Q’ty for each CPU 1 DIMM 2 DIMM 4 DIMM 6 DIMM 8 DIMM NOTE! ⚫ There should be at least one DDR4 DIMM per socket. ⚫ If only one DIMM is populated in a channel, then populate it in the slot furthest away from CPU of that channel. ⚫...
  • Page 16 1-4-6 Intel Optane PMem 200 Series Matrix Configuration DDR4 + PMem Mode Interleave DIMM_P0_F0 DIMM_P0_E0 DIMM_P0_H0 DIMM_P0_G0 DIMM_P0_C0 DIMM_P0_D0 DIMM_P0_A0 DIMM_P0_B0 One - x4 PMem DDR4 PMem DDR4 DDR4 PMem DDR4 PMem AD, MM One - x4 DDR4 PMem DDR4 PMem PMem DDR4...
  • Page 17 Installing the M.2 SSD Module Follow the steps below to install a M.2 SSD module on your motherboard. Step1. Insert the M.2 SSD module into the slot. Step2. Secure it with the screw, tightening as necessary to fasten the M.2 SSD module in place. - 17 - Hardware Installation...
  • Page 18 Back Panel Connectors ❶ VGA Port Connects to a monitor device. ❷ Serial Port (RJ45 Type) Connects to data processing devices. ❸ GbE LAN Port #1 The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. See the section below for a description of the states of the LAN port LEDs.
  • Page 19 LAN and ID Button LEDs 10GbE LAN LED: 10/100/1000 LAN LED: Speed LED Link/Activity LED State Description State Description Yellow On 5Gbps, 2.5Gbps, 1Gps data rate Yellow On 1Gbps data rate Green On 10Gbps data rate Green On 100Mbps data rate 10Mbps data rate 100Mbps data rate LAN Port...
  • Page 20 Internal Connectors CPU1 CPU0 14 18 ATX3 12) PMBUS1 P12V_AUX1 (for CPU0) 13) F_USB1 P12V_AUX2 (for CPU1) 14) FP_1 P12V_AUX3 (for PCIe) 15) BP_1 SSATA5/SSATA4 16) SPI_TPM SSATA_SGP 17) IPMB SW_RAID 18) 10GACT2/10GACT1 (MD72-HB2 Supported) CPU0_FAN1/CPU1_FAN 19) LED_BMC SYS_FAN1 20) BAT 10) SYS_FAN2/3/4 21) CASE_OPEN 11) SYS_FAN5...
  • Page 21 1/2/3/4) ATX3/P12V_AUX1/P12V_AUX2/P12V_AUX3 (2x12 Main Power Connector and 2x4/2x3 12V Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, first make sure the power supply is turned off and all devices are properly installed.
  • Page 22 5) SSATA5/SSATA4 (SATA III 6Gb/s Connectors) The SATA connectors conform to SATA III 6Gb/s standard and are compatible with SATA 3Gb/s standard. Each SATA connector supports a single SATA device. Pin No. Definition 6) SSATA_SGP (SATA SGPIO) Connector Serial General Purpose Input/Output (SGPIO) is a communication method used between a host bus adapter (HBA) and a main board.
  • Page 23 7) SW_RAID (SATA RAID Upgrade Key) Pin No. Definition P_3V3_AUX PCH_SATA_RAID_KEY 8/9/10/11) CPU0_FAN/CPU1_FAN/SYS_FAN1/SYS_FAN2/SYS_FAN3/SYS_FAN4/SYS_FAN5 (CPU Fan/System Fan Headers) The motherboard has one 4-pin CPU fan header (CPU_FAN), and two 4-pin (SYS_FAN) system fan headers. Most fan headers possess a foolproof insertion design. When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is the ground wire).
  • Page 24 12) PMBUS1 (PMBus Connector) The Power Management Bus (PMBus) is a variant of the System Management Bus (SMBus) which is targeted at digital management of power supplies. Pin No. Definition PMBus Clock PMBus Data PMBus Alert 3.3V Sense 13) F_USB1 (Front Panel USB 3.1 Connector) The header conform to USB 3.1 specification.
  • Page 25 14) FP_1 (Front Panel Header) Connect the power switch, reset switch, speaker, chassis intrusion switch/sensor and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables. Pin No.
  • Page 26 16) SPI_TPM (Trusted Platform Module Connector) Trusted Platform Module (TPM) is an international standard for a secure cryptoprocessor, a dedicated microcontroller designed to secure hardware through integrated cryptographic keys. 13 14 Pin No. Definition Pin No. Definition Clock P_3V3_AUX LPC_RST No Pin SPI_MISO IRQ_SPI...
  • Page 27 18) 10GACT2/10GACT1 (10G LAN link/active LED Header) Pin No. Definition 10G LED+ 10G ACT- 19) LED_BMC (BMC Firmware Readiness LED) State Description BMC firmware is initial Blink BMC firmware is ready AC loss - 27 - Hardware Installation...
  • Page 28 20) BAT (Battery Socket) The battery provides power to keep the values (such as BIOS configurations, date, and time information) in the CMOS when the computer is turned off. Replace the battery when the battery voltage drops to a low level, or the CMOS values may not be accurate or may be lost.
  • Page 29 Jumper Settings Clear CMOS CLR_CMOS Default Enable 1 2 3 Jumper Name Jumper Setting 1-2 Closed: Normal operation (Default setting) Clear CMOS 2-3 Closed: Clear CMOS data HOST_SMBUS_SEL BIOS defined PMBUS_SEL BIOS defined Stop initial power on S3_MASK Normal [Default] when BMC is not ready DB_PLD CPLD debug mode...
  • Page 30 Chapter 2 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the EFI on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters, loading the operating system etc. The BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.
  • Page 31 ◼ Main This setup page includes all the items of the standard compatible BIOS. ◼ Advanced This setup page includes all the items of AMI BIOS special enhanced features. (ex: Auto detect fan and temperature status, automatically configure hard disk parameters.) ◼...
  • Page 32 The Main Menu Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter other sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the bottom line of the Main Menu.
  • Page 33 Parameter Description BIOS Information Project Name Displays the project name information. Project Version Displays version number of the BIOS setup utility. Build Date and Time Displays the date and time when the BIOS setup utility was created. (Note1) BMC Information (Note1) BMC Firmware Version Displays BMC firmware version information.
  • Page 34 Parameter Description (Note2) Memory Frequency Displays the frequency information of the installed memory. Onboard LAN Information (Note3) LAN# MAC Address Displays LAN MAC address information. CPLD Boot Information Boot Status Displays the CPLD boot status. System Date Sets the date following the weekday-month-day-year format. System Time Sets the system time following the hour-minute-second format.
  • Page 35 Advanced Menu The Advanced Menu displays submenu options for configuring the function of various hardware components. Select a submenu item, then press <Enter> to access the related submenu screen. When Boot Mode Select is set to UEFI (Default) When "Boot Mode Select" is set to Legacy in the Boot > Boot Mode Select section - 35 - BIOS Setup...
  • Page 36 2-2-1 Trusted Computing Parameter Description Configuration Enable/Disable BIOS support for security device. OS will not show security device. TCG EFI protocol and INT1A interface will not be Security Device Support available. Options available: Enable, Disable. Default setting is Enable. BIOS Setup - 36 -...
  • Page 37 2-2-2 Serial Port Console Redirection Parameter Description Console redirection enables the users to manage the system from a COM1 Console remote location. (Note) Redirection Options available: Enabled, Disabled. Default setting is Disabled. Press [Enter] to configure advanced items. Please note that this item is configurable when COM1 Console Redirection is set to Enabled.
  • Page 38 Parameter Description  Parity – A parity bit can be sent with the data bits to detect some transmission errors. – Even: parity bit is 0 if the num of 1's in the data bits is even. – Odd: parity bit is 0 if num of 1's in the data bits is odd. –...
  • Page 39 Parameter Description Legacy Console Redirection Press [Enter] to configure advanced items.  Redirection COM Port – Selects a COM port for Legacy serial redirection. – Default setting is COM1.  Resolution – Selects the number of rows and columns used in Console Redirection for legacy OS support.
  • Page 40 Parameter Description  Flow Control EMS – Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a 'stop' signal can Serial Port for Out-of-Band be sent to stop the data flow. Once the buffers are empty, a 'start' EMS Console Redirection signal can be sent to re-start the flow.
  • Page 41 2-2-3 SIO Configuration Description Parameter Displays the AMI SIO driver version information. AMI SIO Driver Version Super IO Chip Logical Device(s) Configuration Press [Enter] to configure advanced items.  Use This Device – When set to Enabled allows you to configure the serial port settings. When set to Disabled, displays no configuration for the serial port.
  • Page 42 2-2-4 PCI Subsystem Settings Parameter Description PCI Bus Driver Version Displays the PCI Bus Driver version information. When enabled, this setting will initialize the device expansion (Note1) PCI Express Slot # I/O ROM ROM for the related PCI-E slot. Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the onboard LAN controller.
  • Page 43 2-2-5 USB Configuration Parameter Description USB Configuration USB Devices: Displays the USB devices connected to the system. Enable/Disable the XHCI Hand-off support. XHCI Hand-off Options available: Enabled, Disabled. Default setting is Enabled. USB Mass Storage Driver Enable/Disable the USB Mass Storage Driver Support. (Note) Support Options available: Enabled, Disabled.
  • Page 44 2-2-6 Network Stack Configuration Parameter Description Enable/Disable the UEFI network stack. Network Stack Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 PXE feature. Ipv4 PXE Support Options available: Enabled, Disabled. Default setting is Enabled. Enable/Disable the Ipv4 HTTP feature. Ipv4 HTTP Support Options available: Enabled, Disabled.
  • Page 45 2-2-7 Post Report Configuration Parameter Description Post Report Configuration Error Message Report Enable/Disable the POST Error Message support. Post Error Message Options available: Enabled, Disabled. Default setting is Enabled. - 45 - BIOS Setup...
  • Page 46 2-2-8 NVMe Configuration Parameter Description NVMe Configuration Displays the NVMe devices connected to the system. Options available: BIOS Build-In, NVMe Device. Default setting is BIOS NVMe OPROM Select Build-In. Enable/Diable user control NVMe LED. This item is only available NVMe LED Control when the NVMe device direct connect to CPU.
  • Page 47 2-2-9 Chipset Configuration Parameter Description Defines the power state to resume to after a system shutdown that is due to an interruption in AC power. When set to Last State, the system will return to the active power state prior to shutdown. When set to (Note) Restore on AC Power Loss Power Off, the system remains off after power shutdown.
  • Page 48 2-2-10 Tls Auth Configuration Parameter Description Press [Enter] for configuration of advanced items.  Enroll Cert – Press [Enter] to enroll a certificate • Enroll Cert Using File • Cert GUID Server CA Configuration Input digit character in 1111111-2222-3333-4444-1234567890ab format. –...
  • Page 49 2-2-11 iSCSI Configuration Parameter Description Press [Enter] configure advanced items.  Attempt Priority – Options available: Host Attempt, Redfish Attempt. Default setting Attempt Priority is Host Attempt.  Commit Changes and Exit Press [Enter] to configure advanced items.  iSCSI Initiator Name –...
  • Page 50 2-2-12 Intel(R) X710 Ethernet Network Connection BIOS Setup - 50 -...
  • Page 51 Description Parameter Press [Enter] to configure advanced items.  Link Speed – Default setting is Auto Negotiated.  Wake On LAN – Enables power on of the system via LAN. Note that configuring Wake on LAN in the operating system does not change the value of NIC Configuration this setting, but does override the behavior of Wake on LAN in OS controlled power states.
  • Page 52 2-2-13 Intel(R) i210 Gigabit Network Connection BIOS Setup - 52 -...
  • Page 53 Description Parameter Press [Enter] to configure advanced items.  Link Speed – Allows for automatic link speed adjustment. – Options available: Auto Negotiated, 10 Mbps Half, 10 Mbps Full, 100 Mbps Half, 100 Mbps Full. Default setting is Auto Negotiated. ...
  • Page 54 2-2-14 VLAN Configuration Parameter Description Press [Enter] to configure advanced items.  Create new VLAN  VLAN ID – Sets VLAN ID for a new VLAN or an existing VLAN. – Press the <+> / <-> keys to increase or decrease the desired values. –...
  • Page 55 2-2-15 Driver Health Parameter Description Driver Health Displays driver health status of the devices/controllers if installed. - 55 - BIOS Setup...
  • Page 56 Chipset Menu Chipset Setup menu displays submenu options for configuring the function of Platform Controller Hub(PCH). Select a submenu item, then press <Enter> to access the related submenu screen. BIOS Setup - 56 -...
  • Page 57 2-3-1 Processor Configuration - 57 - BIOS Setup...
  • Page 58 Description Parameter Processor Configuration Press [Enter] to configure advanced items.  CPU Socket 0 Configuration – Core Disable Bitmap(Hex) • Number of Cores to enable. 0 means all cores. FFFFFFF Pre-Socket Configuration means to disable all cores. The maximum value depends on the number of CPUs available.
  • Page 59 Description Parameter Options available: Enable, Disable. Default setting is Disable. Debug Consent Enable/Disable total memory encryption (TME). Total Memory Encryption (TME) Options available: Enabled, Disabled. Default setting is Disabled. - 59 - BIOS Setup...
  • Page 60 2-3-2 Common RefCode Configuration Parameter Description Common RefCode Configuration Selects the MMIO High Base setting. MMIO High Base Options available: 56T, 40T, 32T, 24T, 16T, 4T, 2T, 1T, 512G, 3584T. Default setting is 56T. Selects the allocation size used to assign memory-mapped I/O (MMIO) resources.
  • Page 61 Parameter Description Options available: Disable (All2All), Hemisphere (2-clusters). Default UMA-Based Clustering setting is Hemisphere (2-clusters). - 61 - BIOS Setup...
  • Page 62 2-3-3 UPI Configuration Description Parameter Press [Enter] to configure advanced items.  Uncore Status – Press [Enter] to view the Uncore status.  Link Frequency Select – Selects the UPI link frequency. – Options available: 9.6GT/s, 10.4GT/s, 11.2GT/s, Auto. Default setting is Auto.
  • Page 63 2-3-4 Memory Configuration Description Parameter Integrated Memory Controller (iMC) When set to Enable, the system enforces Plan Of Record restrictions for DDR4 frequency and voltage programming. Enforce POR Options available: POR, Disable. Default setting is Disable. Configures the maximum memory frequency. If Enforce POR is disabled, user will be able to run at higher frequencies than the Memory Frequency memory support (limited by processor support).
  • Page 64 Description Parameter Enable/Disable Automatic restoring of NVDIMMs. Restore NVDIMMs Options available: Enable, Disable. Default setting is Enable. Controls if NVDIMMs are interleaved together or not. Interleave NVDIMMs Options available: Enable, Disable. Default setting is Enable. Enable/Disable Assert ADR on Reset. Assert ADR on Reset Options available: Enabled, Disabled.
  • Page 65 Description Parameter  Leaky bucket time window based interface – Enable/Disable leaky bucket time window based interface. – Options available: Disabled, Enabled. Default setting is Disabled.  Leaky bucket low bit – Configures leaky bucket low bit (1-63). – Press the <+> / <-> keys to increase or decrease the desired values.
  • Page 66 2-3-5 IIO Configuration Description Parameter IIO Configuration Press [Enter] to configure advanced items.  ® Intel VT for Directed I/O – Enable/Disable the Intel VT for Directed I/O (VT-d) support function by reporting the I/O device assignment to VMM through DMAR ACPI Tables.
  • Page 67 Description Parameter Press [Enter] to configure advanced items.  Intel ® VMD Configuration – Enable/Disable Intel ® VMD technology. – Options available: Enable, Disable. Default setting is Disable. Intel ® VMD technology  (Note) ® Intel VMD for Non-Hotplug NVMe –...
  • Page 68 2-3-6 Advanced Power Management Configuration Description Parameter Advanced Power Management Configuration Press [Enter] to configure advanced items.  SpeedStep (Pstates) – Conventional Intel SpeedStep Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. –...
  • Page 69 Description Parameter Press [Enter] to configure advanced items.  Hardware P-States – When this item is disabled, the processor hardware chooses a P-state based on OS Request (Legacy P-States). – In Native mode, the processor hardware chooses a P-state based Hardware PM State Control on OS guidance.
  • Page 70 2-3-7 PCH Configuration Description Parameter PCH Configuration Press [Enter] to configure advanced items.  SATA Controller – Enable/Disable SATA controller. – Options available: Enable, Disable. Default setting is Enable.  Configure SATA as – Configures on chip SATA type. – AHCI Mode: When set to AHCI, the SATA controller enables its AHCI functionality.
  • Page 71 Description Parameter  Port 0/1/2/3/4/5/6/7 – Enable/Disable Port 0/1/2/3/4/5/6/7 device. – Options available: Enable, Disable. Default setting is Enable.  (Note 2) Hot Plug (for Port 0/1/2/3/4/5/6/7) – Enable/Disable HDD Hot-Plug function. PCH SATA Configuration – Options available: Enable, Disable. Default setting is Enable. (continued) ...
  • Page 72 2-3-8 Miscellaneous Configuration Description Parameter Miscellaneous Configuration Selects the active video type. Options available: Auto, Onboard Device, PCIE Device, Specific PCIE Active Video Device. Default setting is Auto. BIOS Setup - 72 -...
  • Page 73 2-3-9 Server ME Configuration Parameter Description General ME Configuration Oper. Firmware Version Displays the operational firmware version. ME Firmware Status #1/#2 Displays ME Firmware status information. Current State Displays ME Firmware current status information. Error Code Displays ME Firmware status error code. Recovery Cause Displays ME Firmware recovery cause.
  • Page 74 2-3-10 Runtime Error Logging Settings Description Parameter Runtime Error Logging Enable/Disable system error logging function. System Errors Options available: Enable, Disable. Default setting is Enable. Enable/Disable software injection error logging function. S/W Error Injection Support Options available: Enable, Disable. Default setting is Disable. Press [Enter] to configure advanced items.
  • Page 75 Description Parameter Press [Enter] to configure advanced items.  PCIE Error – Enable/Disable PCIE error. – Options available: Enable, Disable. Default setting is Disable.  (Note) Uncorrected Error – Enables and escalates Uncorrectable/Recoverable Errors to error pins. – Options available: Enable, Disable. Default setting is Enable. ...
  • Page 76 2-3-11 Power Policy Description Parameter Selects a Power Policy Quick Setting. Options available: Standard, Best Performance, Energy Efficient, Turbo Power Policy Quick Settings Lock. Default setting is Best Performance. Conventional Intel SpeedStep Technology switches both voltage and frequency in tandem between high and low levels in response to processor SpeedStep (Pstates) load.
  • Page 77 Description Parameter The Hyper Threading Technology allows a single processor to execute two or more separate threads concurrently. When hyper-threading is enabled, multi-threaded software applications can execute their threads, Hyper-Threading [ALL] thereby improving performance. Options available: Enabled, Disabled. Default setting is Enabled. Options available: Enabled, Disabled.
  • Page 78 Server Management Menu Parameter Description Enable/Disable FRB-2 timer (POST timer). FRB-2 Timer Options available: Enabled, Disabled. Default setting is Disabled. (Note1) FRB-2 Timer Configures the FRB2 Timer timeout. The value is between 1 to 30 minutes. timeout Default setting is 6 minutes. Configures the FRB2 Timer policy.
  • Page 79 Parameter Description System Event Log Press [Enter] to configure advanced items. View FRU Press [Enter] to view the FRU information. Information BMC VLAN Press [Enter] to configure advanced items. Configuration BMC network Press [Enter] to configure advanced items. Configuration IPv6 BMC Network Press [Enter] to configure advanced items.
  • Page 80 2-4-1 System Event Log Parameter Description Enabling / Disabling Options Change this item to enable or disable all features of System Event SEL Components Logging during boot. Options available: Enabled, Disabled. Default setting is Enabled. Erasing Settings Choose options for erasing SEL. Options available: No, Erase SEL Yes, On next reset,...
  • Page 81 2-4-2 View FRU Information The FRU page is a simple display page for basic system ID information, as well as System product information. Items on this window are non-configurable. (Note) The model name will vary depends on the product you purchased - 81 - BIOS Setup...
  • Page 82 2-4-3 BMC VLAN Configuration Description Parameter BMC VLAN Configuration Select to configure BMC VLAN ID. The valid range is from 0 to 4094. When BMC VLAN ID set to 0, BMC VLAN ID will be disabled. Select to configure BMC VLAN Priority. The valid range is from 0 to 7. BMC VLAN Priority When BMC VLAN ID is set to 0, BMC VLAN Priority will not be selected.
  • Page 83 2-4-4 BMC Network Configuration Parameter Description BMC network configuration Lan Channel 1 Selects to configure LAN channel parameters statically or dynamically (DHCP). Do nothing option will not modify any BMC network parameters Configuration Address source during BIOS phase. Options available: Unspecified, Static, DynamicBmcDhcp. Default setting is DynamicBmcDhcp.
  • Page 84 2-4-5 IPv6 BMC Network Configuration Parameter Description IPv6 BMC network configuration IPv6 BMC Lan Channel 1 Enable/Disable IPv6 BMC LAN channel function. When this item is disabled, the system will not modify any BMC network during BIOS IPv6 BMC Lan Option phase.
  • Page 85 Security Menu The Security menu allows you to safeguard and protect the system from unauthorized use by setting up access passwords. There are two types of passwords that you can set: • Administrator Password Entering this password will allow the user to access and change all settings in the Setup Utility. •...
  • Page 86 2-5-1 Secure Boot ® The Secure Boot submenu is applicable when your device is installed the Windows 8 (or above) operating system. Parameter Description System Mode Displays if the system is in User mode or Setup mode. Enable/ Disable the Secure Boot function. Secure Boot Options available: Enabled, Disabled.
  • Page 87 Parameter Description Press [Enter] to configure advanced items. Please note that this item is configurable when Secure Boot Mode is set to Custom.  Factory Key Provision – Allows to provision factory default Secure Boot keys when system is in Setup Mode.
  • Page 88 Parameter Description  Authorized TimeStamps (DBT) – Displays the current status of the Authorized TimeStamps Database. – Press [Enter] to configure a new DBT or load additional DBT from storage devices. – Options available: Update, Append. Key Management  (continued) OsRecovery Signatures –...
  • Page 89 Boot Menu The Boot menu allows you to set the drive priority during system boot-up. BIOS setup will display an error message if the legacy drive(s) specified is not bootable. Parameter Description Boot Configuration Number of seconds to wait for setup activation key. 65535 (0xFFFF) Setup Prompt Timeout means indefinite waiting.
  • Page 90 Parameter Description FIXED BOOT ORDER Priorities Press [Enter] to configure the boot order priority. By default, the server searches for boot devices in the following sequence: Hard drive. Boot Option #1 / #2 / #3 / #4 / #5 CD-COM/DVD drive. USB device.
  • Page 91 Save & Exit Menu The Save & Exit menu displays the various options to quit from the BIOS setup. Highlight any of the exit options then press <Enter>. Parameter Description Save Options Saves changes made and closes the BIOS setup. Save Changes and Exit Options available: Yes, No.
  • Page 92 Parameter Description Loads the default settings for all BIOS setup parameters. Setup Defaults are quite demanding in terms of resources consumption. If you are using low-speed memory chips or other kinds of low-performance components Restore Defaults and you choose to load these settings, the system might not function properly.
  • Page 93 BIOS POST Beep code (AMI standard) 2-8-1 PEI Beep Codes # of Beeps Description Memory not Installed. Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available...
  • Page 94 Notices Information for your safety and comfort Safety instructions Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product. Turning the product off before cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
  • Page 95 Using electrical power ⚫ This product should be operated from the type of power indicated on the marking label. If you are not sure of the type of power available, consult your dealer or local power company. ⚫ Do not allow anything to rest on the power cord. Do not locate this product where people will walk on the cord.
  • Page 96 adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal condition. This server should be located in a restricted access location or an area with similar instruction. Caution: Danger of explosion if battery is incorrectly replaced.
  • Page 97 Regulations and safety notices Laser compliance statement The CD or DVD drive used with this computer is a laser product. The CD or DVD drive's classification label (shown below) is located on the drive. CLASS 1 LASER PRODUCT CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.
  • Page 98 List of applicable countries This device must be used in strict accordance with the regulations and constraints in the country of use. For further information, please contact local office in the country of use. Please see http://ec.europa.eu/enterprise/rtte/implem.htm or the latest country list. Note: The following sections are applicable only to Class A systems FCC notice Class A...
  • Page 99 Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class A digital apparatus complies with Canadian ICES-003.
