- Page 1 ASSEMBLY INSTRUCTION FORFAR CORNER DESK ITEM CODE 69250 Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt...
- Page 2 PRE-ASSEMBLY PREPARATION Before you start: 1. Choose a clean, level, spacious assed hard surfaces that may damage the product 2. Take care when liꢁ ing. Product should besible to the point of use 3. Ensure that you have all required contents for complete assembly 4.
- Page 3 M7X39mm M15X12mm M8X30mm M5X70mm 14pcs 14pcs 18pcs 4pcs M3.5X14mm 6pcs 8pcs 2pcs 1pcs M3X16mm M4x30mm M3.5x14mm 1pcs 10pcs SIDE PANEL SIDE PANEL MIDDLE PANEL BACK PANEL SHELF DOOR PANEL BOTTOM PANEL TOP PANEL SUPPORT PANEL...
- Page 4 STEP 1: Insert dowel(C)to panel(1)(2)(3)(5)(6). STEP 2: Fix cam pin (A) to panel(1)(2)(6)(9).
- Page 5 STEP 3: Aꢂach panel(1) (2)to panel (3) with cam lock parts. STEP 4:Aꢂach boꢂom panel(4) to the body with screws(D).
- Page 6 STEP 5: Aꢂach panel(5) to the body with cam lock parts. STEP 6:Aꢂach top panel(9) to the body with cam lock parts.
- Page 7 STEP 7: Fix screws(I)to panel (7). STEP 8:Turn over ,and aꢂach door panel(8) with hinges.
- Page 8 ASSEMBLY COMPLETE...
- Page 9 SAFETY BRACKETS INSTRUCTIONS 1. Attach one Mounting Plate to the wall with the Large Screws. Make sure to attach the Mounting Plate into a stud. If mounting into brick or masonry you will need to acquire wall anchors. 2. Attach the second Mounting Plate to the furniture frame with the Short Screws.
- Page 10 To protect your furniture, we suggest the following: • Avoid placing your furniture in direct sunlight. • Do not place furniture directly under windows. • Do not place sharp materials (knife, fork, etc.) directly onto your furniture as sharp material may scrape and damage the finish.
