HOSPITAL BED INSTRUCTION MANUAL
IMPULSE KL-M

Advertisement

loading
Need help?

Need help?

Do you have a question about the IMPULSE KL-M and is the answer not in the manual?

Questions and answers

Related Manuals for Malsch IMPULSE KL-M

Summary of Contents for Malsch IMPULSE KL-M

  • Page 1 C L I N I C D ES I G N HOSPITAL BED INSTRUCTION MANUAL IMPULSE KL-M...
  • Page 3 Dear Customers, by purchasing a hospital bed from Malsch care & clinic design ® , you have obtained a long-lasting medical device with functions that fulfil all of the requirements of everyday hospital care while maintaining the highest safety standards.
  • Page 4 GS side rail adjustment Technical data EVGS side rail adjustment Rating plate Function illustration Rating plate with UDI IMPULSE KL-M Edition 200-P (Variant for psychiatric wards) Function illustration IMPULSE KL-M Edition 300-P IMPULSE KL-M Edition 200-W (Variant for psychiatric wards)
  • Page 5 Delivery and assembly Troubleshooting Product safety Cleaning and disinfection Maintenance Warranty and service Customer service Declaration of conformity Certificates...
  • Page 6 PRO D U C T R A N G E IMPULSE KL-M Edition 200-W IMPULSE KL-M Edition 300-P IMPULSE KL-M Edition 200-P...
  • Page 7 EN V I RO N M EN TA L SU S TA I N A B I L IT Y Malsch GmbH hospital beds are used in hospitals and medical Malsch GmbH hospital beds are manufactured in accordance environments. These beds are designed exclusively for this pur- with the relevant regulations using state-of-the-art processing pose.
  • Page 8 The instruction manual must be used for this training. This instruction manual has been written for the IMPULSE KL-M hospital bed. The images, graphics and texts it contains may differ from the scope of delivery.
  • Page 9 S A FE T Y I N S T RU C T I O N S The following safety instructions must be observed in order The functionality of the side rails must be checked daily. to prevent risks to both patients and carers, and avoid any They must not bear any vertical loads exceeding 75 kg or damage to the hospital bed: horizontal loads exceeding 50 kg.
  • Page 10 In accordance with IEC 60601-2-52:2009 / AMD1:2015, The bed should be left in the lowest position when the when choosing a mattress, it is important for there to be a patient is unattended to reduce the risk of injury caused by minimum distance of 22 cm between the top of the sleep- falling out of bed.
  • Page 11 Thigh rest Back rest [cm] [cm] ment [cm] max. Trendelenburg adjustment adjustment Total 250 kg IMPULSE KL-M 71° / 6 cm 185 kg patient Edition 200-W 100 x 218 90 x 200 40 to 80 Approx. 120 kg – 43°...
  • Page 12 185 kg 370 kg R 3.1.3 Example illustration of a rating plate without UDI of the IMPULSE KL-M Edition 200 hospital bed R AT I N G PL AT E W IT H U D I Malsch Malsch GmbH | Rohbergstraße 9 | D-36208 Wildeck-Obersuhl Tel.: +49 (0) 6626 915-100 | info@bettenmalsch.de | bettenmalsch.com...
  • Page 13 The rating plate is located on the underside of the sleeping sur- Explanation of the symbols used on the rating plate: face, at the head of the bed on the right. To inspect the rating plate, raise the head rest to the uppermost position. Safe working load Manufacturer’s address Model ID...
  • Page 14 F U N C T I O N I L LU S T R AT I O N IMPULSE KL-M Edition 200-W...
  • Page 15 IMPULSE KL-M Edition 200-W (Version with wood surround) Footboard Adjustable lower leg rest Adjustable thigh rest Static seat section Adjustable back rest Receiving sleeves for IV drip holder and accessories (4 x surrounding the bed) Mattress holder / handle Full-length side rail...
  • Page 16 D E SCR I P T I O N O F F U N C T I O N Back rest Thigh rest The backrest is adjusted us- The thigh rest is adjusted using the relevant operating levers on ing the relevant operating both sides below the sleeping surface frame.
  • Page 17 Height adjustment takes place using a hydraulic cylinder which is operated with a foot pedal. The IMPULSE KL-M Edition 300 hospital bed is equipped with a sleeping surface swivelling mechanism as standard. The height of the sleeping surface can be adjusted by operating the foot pedal (Fig.
  • Page 18 To initiate swivelling into the anti-Trendelenburg position, The brake of the IMPULSE KL-M 300 / 300-P has 3 different the sleeping surface must first be set to its highest position. settings: ( Height adjustment - Fig. A). Swivelling can then be initiated by...
  • Page 19 Removable head / foot boards As standard, the Impulse KL-M hospital bed has head/foot boards that can be removed without the use of tools. These boards can be released and removed by pulling them upwards after releasing the snap lock mounted on the bed frame (green lever).
  • Page 20 DS side rail adjustment Full-length side rails Side rail groove (B) In the starting position, the side rails are located on top of one another next to the sleeping surface frame. Raising function: Lift the upper side rail by the side rail groove (B) until you hear both safety buttons (A) snap into place.
  • Page 21 DS side rail dimensions When using the ABS/metal lattice sleeping surface When using the comfort sleeping surface...
  • Page 22 GS side rail adjustment Split side rails Fig. 1 In standby position, the side rails are located next to the sleeping surface and therefore prevent the mattress from slipping. (Fig. 1) The side rails are raised by tilting them upwards. In this central position, they prevent the patient from falling out of bed, and when they are raised at the head end, they also provide stable standing and mobility assistance for the...
  • Page 23 GS side rail dimensions When using the ABS/metal lattice sleeping surface When using the comfort sleeping surface...
  • Page 24 Seitengitterverstellung VGS EVGS side rail adjustment geteilte Seitensicherung mit Einhand-Bedienung Vertically lowerable split side rails with one-handed operation Die Seitengitter befinden sich in Ruheposition seitlich an der Halt Liegefläche und geben dieser Lage der Matratze gegen Verschieben. In the standby position, the side rails are located at the side of the sleeping surface and prevent the mattress from slipping.
  • Page 25 VGS side rail dimensions When using the ABS/metal lattice sleeping surface...
  • Page 26 F U N C T I O N I L LU S T R AT I O N IMPULSE KL-M Edition 200-P...
  • Page 27 IMPULSE KL-M Edition 200-P (Variant for psychiatric wards) The following differences from the standard equipment are a Footboard result of the special adaptations of the bed to the requirements Reinforcement of the HPL panels against kicking through* of psychiatric treatment: Adjustable lower leg rest ▪...
  • Page 28 F U N C T I O N I L LU S T R AT I O N IMPULSE KL-M Edition 300-P...
  • Page 29 IMPULSE KL-M Edition 300-P (Variant for psychiatric wards) The following differences from the standard equipment are a re- Footboard sult of the special adaptations of the bed to the requirements of Reinforcement of the HPL panels to prevent kicking through...
  • Page 30 A D D IT I O N A L S A FE T Y I N S T RU C T I O N S F O R B EDS U S ED I N P S YCH I AT R I C WA R DS Removable accessories such as trapeze bars, IV drip stands and accessories of the DIN standard rail etc.
  • Page 31 DS-P side rail adjustment Full-length, removable side rail Fig. 1 Fig. 2 The full-length, removable side rail is mounted at the sides into the recesses of the head/foot boards and fixed to the frame of the head/foot board with cam levers (Fig. 2). Raising function: Pull up the upper side rail bar (Fig.
  • Page 32 ISO standard rail with restraint grid Caution! Always pay attention to the restraint reg- The IMPULSE Edition 300-P / 400 hospital bed for psychiatric ulations of your workplace, your facility’s internal wards comes with a full length ISO standard standard rail with restraint protocol and the current legal regulations restraint grids at both sides of the bed.
  • Page 33 D EL I V ERY A N D A S S EM B LY Assembly of head/foot board/sleeping surface Malsch GmbH hospital beds are generally delivered fully as- sembled, or are assembled on site by company technicians or authorised staff.
  • Page 34 T RO U B L E S H O OT I N G No lifting Replacing function when Pressure cylin- the pressure activating foot der faulty cylinder pedal Hydraulic Replacing Height adjust- cylinder faulty the hydraulic ment very slow (oil leak) cylinder Check all moving parts and remove...
  • Page 35 PRO D U C T S A FE T Y This product bears the CE seal and therefore meets the requirements of the applicable German and European safety standards. Laws and standards Title Regulation (EU) 2017/745 European Medical Device Regulation MPDG Medical devices implementation act DIN EN ISO 13485...
  • Page 36 Only original replacement parts from Malsch GmbH Caution! Under no circumstances must abrasives, are permitted to be used.Procedure cleaning pads or stainless steel cleaners be used for cleaning.
  • Page 37 2. Level of protection and functionality check of the side rails Check whether the required distances are also complied with During the functionality check, determine whether the side rails under load. Dimensions A and C must be checked with a test can be easily locked in place and ensure that no impermissible tool in accordance with IEC 60601-2-52:2009/AMD:2015.
  • Page 38 S TO R AG E The following steps must be taken when the hospital beds are being put into storage. Move the bed to its lowest position. Remove any accessories such as bed lamps, lifting poles etc. Cover hospital beds in such a way that the head/foot boards and the frame cannot be damaged.
  • Page 40 WA R R A N T Y A N D S ERV I CE D ECL A R AT I O N O F CO N F O R M IT Y By purchasing a hospital bed from Malsch GmbH, you have cho- sen a premium, high-quality product.
  • Page 41 Der Nachweis der regelkonformen Anwendung wurde erbracht. 2023-11-17 bis: 2025-07-10 Der Nachweis der regelkonformen Anwendung wurde erbracht. Der Nachweis der regelkonformen Anwendung wurde erbracht. Malsch GmbH Rohbergstraße 9 36208 Wildeck - Obersuhl / Deutschland Malsch GmbH Malsch GmbH Rohbergstraße 9 Rohbergstraße 9...
  • Page 42 NOTES...
  • Page 43 NOTES...
  • Page 44 EN, Updated 10 / 2024, Rev. 2.0.1 Colours may vary Subject to technical changes Malsch GmbH | Rohbergstraße 9 | 36208 Wildeck-Obersuhl | Germany Tel.: +49 (0) 6626 915 100 | Fax: +49 (0) 6626 915 116 bettenmalsch.com | info@bettenmalsch.de...
