- Page 1 C L I N I C D ES I G N IMPULSE KL SERIES INSTRUCTIONS FOR USE...
- Page 3 Dear Customers, By purchasing a clinical bed from Malsch care & clinic design ® you have obtained a long-lasting medical device with functions that meet all the requirements of everyday care while maintain- ing the highest standards of safety. We would like to thank you for the trust you have placed in us.
-
Page 4: Table Of Contents
C O N T E N T S Specific function Height adjustment Environmental Sustainability Transfer position Note regarding the Low position/ instructions for use Fall prevention Pictograms / Symbols Comfort sitting position Safety instructions Auto contour Technical Data Trendelenburg-/ Anti-Trendelenburg position Rating Plate Hand controller locking function Symbols on the patient’s hand controller... - Page 5 Bed light Hand controller holder Horizontal hand controller Mattresses Side rail heightening Urine bottle / bag / basket 5th wheel Trouble shooting Product safety Cleaning and disinfection Maintenance Storage Warranty and service Declaration of conformity Certificates...
- Page 6 Room representation Impulse 300 KL / Impulse 400 KL...
-
Page 7: Specific Function
E N V I R O N M E N T A L S U S T A I N A B I L I T Y Betten Malsch GmbH clinical beds are used in hospitals and Betten Malsch GmbH clinical beds are manufactured in ac- care areas. -
Page 8: Note Regarding The Instructions For Use
N O T E R E G A R D I N G T H E P I C T O G R A M S / S Y M B O L S I N S T R U C T I O N S F O R U S E The following instructions and guidelines in this manual are for To help easy orientation in this instruction manual, we some- the nursing staff or other persons and staff tasked with using... -
Page 9: Safety Instructions
S A F E T Y I N S T R U C T I O N S The instruction manual should be read and followed be- be taken to ensure that the patient does not come into fore using the clinical bed. contact with the side rails when adjusting the lying posi- tion, to avoid trapping any part of the body. - Page 10 distances between walls, window benches or other ob- It is important that the following safety instructions are ob- jects must be observed. Safety distances depend on the served to prevent the risk of danger or injury to both patient design and model of the clinical bed and are based on and carer and also avoid any potential damage to the bed: height adjustments and tilting motion.
- Page 11 this can lead to pressure sores. The manufacturer ical products may be carried out be specialist staff of the clinical bed is not liable for this in any way. trained by the manufacturer as these BGV inspec- tions are included in the technical safety checks. Electrically powered clinical beds are medical products and are subject to technical safety checks Electrically operated clinical beds are active medi-...
-
Page 12: Technical Data
T E C H N I C A L D A T A Dimensions: Upper leg adjustment: 43° Trendelenburg: 14° Impulse 300 KL/400 KL 216 x 106 cm Antitrendelenburg: 15° Impulse XL KL 216 x 116 cm incl. wall bumper Maximum load: 250 kg Impulse 300 KL / 400 KL... -
Page 13: Rating Plate
R A T I N G P L A T E Betten Malsch GmbH | Rohbergstraße 9 | D-36208 Wildeck-Obersuhl Tel.: +49 (0)6626 / 915 100 | Fax: +49 (0)6626 / 915 116 Clinical bed Impulse KL 0815 1234567 250 kg... -
Page 14: Symbols On The Patient's Hand Controller
S Y M B O L S O N T H E P A T I E N T ’ S H A N D C O N T R O L L E R Blocking function Back rest Back rest adjustment adjustment down... -
Page 15: Symbols On The Nurse's Control Panel
S Y M B O L S O N T H E N U R S E ’ S C O N T R O L P A N E L ADJUSTMENTS BLOCKING FUNCTIONS CPR (electric) Back rest adjustment block Shock position Leg rest adjustment block (LED red =... -
Page 16: Product Designation
P R O D U C T D E S I G N A T I O N Impulse 300 KL (optional equipment) Impulse 400 KL Impulse XL KL... -
Page 17: Functional Representation
F U N C T I O N A L R E P R E S E N T A T I O N Adjustable back rest Seat section (fixed) Bed panel Adjustable Trapeze bar mount on the back of the frame lower leg rest Adjustable and inside on both... -
Page 18: Description Of Function
D E S C R I P T I O N O F F U N C T I O N Depending on the design and type of clinical bed, the bed can back rest drive is ready for use in every position after travelling be put into the following positions by adjusting the back rest, a short distance. -
Page 19: Transfer Position
Transfer position Comfort sitting position (only with Impulse 400 KL) Use the corresponding button on the hand controller to set the The tranfer position allows an optimum positional mounting comfort sitting position. and dismounting in the seat area of the bed at sitting height. Use the corresponding button on the hand controller and hold (Comfort sitting position operating button) it until the position is reached. -
Page 20: Trendelenburg-/ Anti-Trendelenburg Position
When this button is activated, the back and upper leg sections This function must only be used by specialist are adjusted equally, so that the patient can be brought into an staff and must be locked by specialist staff on upright sitting position. -
Page 21: Braking And Moving
Braking and moving Impulse 300 KL / 400 KL / XL KL The Impulse 300 KL / 400 KL / XL KL model (movable at any height) has a central castor locking mechanism which is operated mechanically by means of a central foot pedal. The foot pedal is located in the middle of the foot area of the moving frame. -
Page 22: Side Rail (Sr) Adjustment
Side rail (SR) adjustment Caution ! When positioning the side protection and raising the side rails, please ensure the In the down position, the side rails are located on the catches lock in properly, and check this. Always sides of the lying surface which helps stop the mattress use both hands to adjust the side rails! from slipping. -
Page 23: Integrated Lying Surface Extension
Integrated lying surface extension (only Impulse 300 KL / 400 KL) The clinical beds Impulse 300 KL/400 KL have an integrated lying surface extension, which allows the lying surface to be extended by 10/20 cm without requiring tools. This is activated without use of any tools by means of two le- vers on the bottom of the foot end of the lying surface in three simple steps: Operate both levers simultaneously and while doing so... -
Page 24: Removable Head / Foot Boards
Removable head / foot boards Impulse KL clinical beds have head / foot boards that can be removed without use of any tools as standard. These can be released and removed from above using the quick connector on the bed frame mounting (green lever). Caution ! Ensure that the head / foot boards are locked before using the bed. -
Page 25: Delivery And Assembly
D E L I V E R Y A N D A S S E M B L Y Assembly bed front / lying surface Betten Malsch GmbH clinical beds are generally delivered fully assembled, or assembled by company technicians or author- The head / foot boards are removed without tools - ised personnel on site. -
Page 26: Accessories (Optional)
A C C E S S O R I E S ( O P T I O N A L ) Trapeze bar The trapeze bar can be inserted either left or right of the head end in the designated mounting sockets on the ly- ing surface frame. -
Page 27: Hand Controller Holder
Hand controller holder Mattresses The additional hand controller Betten Malsch GmbH offer a range of individually made spe- holder allows you to place the cial mattresses for the widest range of applications and de- hand control within reach of the mands on lying surface contours of clinical beds. -
Page 28: Urine Bottle / Bag / Basket
Caution ! Only use original bed accessories Caution ! Ensure that the foot pedal of the cen- from Betten Malsch GmbH. Side rail extensions tral brake is in the central position (castors ro- are aligned to and approved by the required tate freely through 360°). -
Page 30: Trouble Shooting
Betten Inform the Hand controller buttons Malsch GmbH operator, re- or motor is tailer or Betten faulty Malsch GmbH Check all moving Locking the Releasing parts and remove... -
Page 31: Product Safety
P R O D U C T S A F E T Y The product bears the CE marking and thus meets the requirements of German and European safety standards applicable to that product. Standard Comment Medical device in accordance with 93/42/ EEC Medical Device Directive (CE marking) German Medical Products Law (MPG) DIN EN ISO 9001... -
Page 32: Cleaning And Disinfection
EN 12720 are suitable for wipe-down disinfection of the bed. The clinical bed should not be disinfected in inline washing systems. Betten Malsch GmbH recommends the detergents Terralin, Perform and Sagrotan-Med or equivalent detergents for disinfection. The detergents used for disinfection must only be used in accordance with the manufacturer’s instructions. -
Page 33: Maintenance
(temperature, humidity, heat, etc.) must be reported to the relevant person. Only original parts from Betten Malsch GmbH The manufacturer’s transport aid should be should be used. used to transport the beds. -
Page 34: Warranty And Service
A N D S E R V I C E C O N F O R M I T Y By purchasing a clinical bed from Betten Malsch GmbH, you have chosen a premium, high-quality product. The clinical beds have a 24-month warranty beginning from the purchase date. -
Page 35: Certificates
TÜV PROFiCERT procedures for and is certified in accordance with TÜV PROFICERT procedures for and is certified in accordance with TÜV PROFICERT procedures for Betten Malsch GmbH Betten Malsch GmbH Betten Malsch GmbH Rohbergstraße 9 Rohbergstraße 9... - Page 36 Art.-No.: 91300 102101.4 EN, Edition 10/2019, Rev. 1.4 Colours may vary Technical modifications reserved Betten Malsch GmbH | Rohbergstraße 9 | 36208 Wildeck-Obersuhl | GERMANY Phone: +49 (0)6626 / 915 100 | Fax: +49 (0)6626 / 915 116 bettenmalsch.com | info@bettenmalsch.de...
