PRO Series

LCD Monitor

PRO MP245G (3PC1)

PRO MP245PG (3PC1)

User Guide

Need help?

Do you have a question about the PRO MP245G and is the answer not in the manual?

Questions and answers

Summary of Contents for MSI PRO MP245G

Page 1 PRO Series LCD Monitor PRO MP245G (3PC1) PRO MP245PG (3PC1) User Guide...
Page 2 Contents Getting Started ......................3 Package Contents ....................3 Installing the Monitor Stand ................... 4 Adjusting the Monitor ..................... 6 Monitor Overview ....................8 Connecting the Monitor to PC ................11 OSD Setup ........................13 Navi Key ........................ 13 Hot Key ........................14 OSD Menus........................
Page 3 This chapter provides you with the information on hardware setup procedures. While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. Package Contents Monitor PRO MP245G PRO MP245PG Documentation Quick Start Guide Stand...
Page 4 Place the monitor on a soft, protected surface to avoid scratching the display panel. Do not use any sharp objects on the panel. ∙ PRO MP245G 1. Leave the monitor in its protective packaging. 2. Align and gently push the stand bracket towards the monitor groove until it locks in place.
Page 5 PRO MP245PG 1. Leave the monitor in its protective packaging. Align the stand bracket to the monitor groove. 2. Tighten the stand bracket with screws. 3. Connect the base to the stand and tighten the base screw to secure the base. 4.
Page 6 Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities. ⚠ Important Avoid touching the display panel when adjusting the monitor. ∙ Please slightly tilt the monitor backwards before pivoting it. ∙ PRO MP245G -5° 20°...
Page 7 PRO MP245PG -5° 20° 30° 30° 90° 90° 120mm...
Page 8 Monitor Overview PRO MP245G...
Page 9 PRO MP245PG Power Button & Navi Key Power Jack Kensington Lock DisplayPort Supports 1920x1080@100Hz as specified in DisplayPort 1.2.
Page 10 HDMI™ Connector Supports 1920x1080@100Hz as specified in HDMI™ 1.4b. ⚠ Important To ensure optimal performance and compatibility, please use only HDMI™ cables certified with the official HDMI™ logo when connecting this monitor. For more information, please visit https://www.hdmi.org/resource/cables. D-Sub Port Line-In Jack For audio playback through the speakers, connect the device’s Line-out jack to this Line-in jack when using the D-Sub port.
Page 11 3. Connect the power cord to the monitor power jack. (Figure A) 4. Plug the power cord into the electrical outlet. (Figure B) 5. Turn on the monitor. (Figure C) 6. Power on the computer and the monitor will auto detect the signal source. PRO MP245G...
Page 12 PRO MP245PG...
Page 13 This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. Navi Key The monitor comes with a Navi Key, a multi-directional control that helps navigate the On-Screen Display (OSD) menu. PRO MP245G...
Page 14 PRO MP245PG Up/ Down/ Left/ Right: ∙ selecting function menus and items ∙ adjusting function values ∙ entering into/exiting from function menus Middle: ∙ launching the On-Screen Display (OSD) ∙ entering submenus ∙ confirming a selection or setting Hot Key ∙...
Page 15 OSD Menus Professional 1st Level Menu 2nd/3rd Level Menu Description Mode ∙ Use Up or Down Button to select and preview mode effects. User ∙ Press the Middle Button to confirm and apply Anti-Blue your mode type. Movie Office Black-White Response Time Normal ∙...
Page 16 1st Level Menu 2nd/3rd Level Menu Description Alarm Clock Location Left Top ∙ After setting the time, press the Middle Button to activate the timer. Right Top ∙ Users have to manually restore their preset Left Bottom Alarm Clock after any AC power loss and reconnection.
Page 17 Image 1st Level Menu 2nd/3rd Level Menu Description Brightness 0-100 ∙ Properly adjust Brightness according to the surrounding lighting. Contrast 0-100 ∙ Properly adjust Contrast to relax your eyes. Sharpness ∙ Sharpness improves clarity and details of images. Image ∙ Image Enhancement enhances image edges Enhancement to improve their acutance.
Page 18 1st Level Menu 2nd/3rd Level Menu Description V.Position 0-100 ∙ Adjust V.Position setting. ∙ For D-Sub only, this setting will be grayed out when detecting other input sources. Input Source 1st Level Menu 2nd Level Menu Description HDMI™ ∙ Users can adjust Input Source in any mode. D-Sub Auto Scan ∙...
Page 19 Settings 1st Level Menu 2nd Level Menu Description Language 繁體中文 ∙ Users have to press the Middle Button to confirm and apply the Language setting. English ∙ Language is an independent setting. Users’ own Français language setting will override the factory. When users set Reset to Yes, Language will not be Deutsch changed.
Page 20 Specifications Monitor PRO MP245G PRO MP245PG Size 23.8 inch Curvature Flat Panel Type Resolution 1920x1080 (FHD) Aspect Ratio 16:9 Brightness Typical SDR: 300 nits Contrast Ratio 1300:1 Refresh Rate 100Hz 1ms (MPRT) Response Time 4ms (GTG) ∙ 1 x HDMI™ Connector ∙...
Page 21 Monitor PRO MP245G PRO MP245PG ∙ Plate Type: 100 x 100 mm ∙ Screw Type: M4 x 10 mm VESA Mounting • Thread Diameter: 4 mm • Thread Pitch: 0.7 mm • Thread Length: 10 mm Dimension (W x H x D) 539.8 x 414.4 x 207.2 mm...
Page 22 Preset Display Modes ⚠ Important All information is subject to change without prior notice. Default Standard Mode Standard Resolution HDMI™ D-Sub 640x480 @60Hz @67Hz @72Hz @75Hz SVGA 800x600 @56Hz @60Hz @72Hz @75Hz 1024x768 @60Hz @70Hz @75Hz SXGA 1280x1024 @60Hz @75Hz WXGA+ 1440x900 @60Hz...
Page 23 Troubleshooting The power LED is off. • Press the monitor power button again. • Check if the monitor power cable is properly connected. No image. • Check if the computer graphics card is properly installed. • Check if the computer and monitor are connected to electrical outlets and are turned on.
Page 24 ∙ Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. ∙ If this device comes with an adapter, use only the MSI provided AC adapter approved for use with this device.
Page 25 ∙ If any of the following situations arises, get the device checked by service personnel: • The power cord or plug is damaged. • Liquid has penetrated into the device. • The device has been exposed to moisture. • The device does not work well or you can not get it working according to the User Guide.
Page 26 TÜV Rheinland Certification TÜV Rheinland Low Blue Light Certification Blue light has been shown to cause eye fatigue and discomfort. MSI now offers monitors with TÜV Rheinland Low Blue Light certification to ensure users’ eye comfort and well-being. Please follow the instructions below to reduce the symptoms from extended exposure to the screen and blue light.
Page 27 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626) 913-0828 www.msi.com...
Page 28 Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products.
Page 29 Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners.
