User Instructions
Electronic Programmable Room Thermostats
HCS6000 Heat or Cool Thermostats
HCM6000 Heat/Cool Thermostats with manual heat/cool selection
HCW6000 Heat/Cool Thermostats with water temperature based heat/cool selection
HC6000 Heat/Cool Thermostats with auto-changeover for 4-pipe systems
Product Features
•
2 or 4 programmed events each day, set by installer.
•
5/2 day programming, provides different set of
programmes for weekend.
•
AM/PM or 24 hour clock display set by user.
•
Centigrade or Fahrenheit temperature display, set by
user.
•
Factory pre-set programmes which can be edited by
user.
•
Available in battery and 230 volt versions.
•
Available in heat or cool version, selectable at time of
installation.
•
Available in heat/cool versions for use in 2-pipe
change over system.
•
Available in heat/cool versions for 4 pipe systems.
LCD
DISPLAY
Heating Temperature
(Programmable Models Only)
Thermostat Calling for Cool
Thermostat Calling for Heat
Temperature Override - Up
Thermometer Mode Indicator
Temperature Override - Down
Main Display
Time or Temperature
Event Number
Low Battery Indicator
(Battery Models Only)
Day (Non Programmable Models)
Cool Temperature
Night (Non Programmable Models)
Auto Mode
Heat Only Mode
Cool Only Mode
Off Mode
Fan Auto Mode
Fan On Mode
Fan On
(Flashes if Smart Fan is selected)
Keyboard
Locked
Day of week (1 = Monday)
(Three speed fan
versions only)
1
Advertisement
Related Manuals for Danfoss HCS6000
Summary of Contents for Danfoss HCS6000
- Page 1 User Instructions Electronic Programmable Room Thermostats HCS6000 Heat or Cool Thermostats HCM6000 Heat/Cool Thermostats with manual heat/cool selection HCW6000 Heat/Cool Thermostats with water temperature based heat/cool selection HC6000 Heat/Cool Thermostats with auto-changeover for 4-pipe systems Product Features • 2 or 4 programmed events each day, set by installer.
- Page 2 Reminder - If thermostat has been set by building owner or installer for 2 events per day, only 2 events can be programmed. Reminder – With HCS6000 models, the installer will have set the thermostat for either heating only or cooling only. When programming these models. Only the service set by the installer will be available.
- Page 3 LCD DISPLAYS BUTTONS PROG 2. Press PROG to advance to temperature setting. then L L L L L M M M M M 3. Press L or M buttons to adjust heating temperature 4. Press + or – button to select required cooling temperature. OPTIONAL: If heating is not required, “Off”...
- Page 4 LCD DISPLAYS BUTTONS PROG 2. Press PROG to advance to temperature setting. then L L L L L M M M M M 3. Press L or M buttons to adjust heating temperature 4. Press + or – button to select required cooling temperature. OPTIONAL: If heating is not required, “Off”...
- Page 5 ELECTING THE THERMOSTAT OPERATING MODE USING THE BUTTON HCS6000 & HCST6000 models only ! Remember – These thermostats can be set up by the installer to control either a heating or a cooling system. If set for heating, the thermostat will turn on the heating system when the temperature falls to below that set on the thermostat.
- Page 6 LCD DISPLAYS BUTTONS HC6000 & HCT6000 models AUTO HEAT SELECT COOL The operating mode of the thermostat can be changed by pressing the SELECT button. The available modes are as follows: ! Remember – These thermostats are used in 4-pipe system which allow heating or cooling to operate all year round.
- Page 7 BUTTONS LCD DISPLAYS H) S ELECTING EEKEND INTO EEKDAY OVERRIDE Week-end into week day override To temporarily copy weekend programmes into weekdays press both L and M buttons together and hold down for 2 seconds. To cancel the weekend into weekday override press both L and M buttons twice. Advice: L L L L L M M M M M...
- Page 8 LCD DISPLAYS BUTTONS THER FEATURES AND FUNCTIONS J) D ISPLAYING OOM TEMPERATURE To enter thermometer mode to display current room temperature press both SELECT and M buttons and hold for 2 seconds. To return to time display repeat press and hold opera- SELECT M M M M M tion.
- Page 9 Temp. Cool : Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
