Ceramic Hob
Instruction Manual / Installation Manual
MODEL: LV-C560
Consult with your dealer or manufacturer for details.
技术要求(版本号:B，2023-06）
，未注直线尺寸公差应符合GB/T1804-v；
70P以下为钉装，70P以上为胶装（特殊要求除外）
;[
多头灶
说明书
K
1
3
4
5
GS图标无高度要求，印刷可见即可
Pa/kPa/MPa
长度:mm/cm/m
时间:s/min/h 重量:kg
16166000A33153
LAVAMAT-MC-6F6005R242（LV-C560）-0501
材料: 100g双胶纸
1:1
广东美的生活电器制造有限公司
1
4
5
6
22
PAP
说明书、保修卡类
]
6
A
B
C
D
E
F
G
H
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LAVAMAT LV-C560
Summary of Contents for LAVAMAT LV-C560
- Page 1 3.材质标注 4.颜色标注 5.客户型号 6.产品名称 Ceramic Hob Instruction Manual / Installation Manual 7.产品参数 MODEL: LV-C560 8.电压功率 9.单位符号 10.认证标志 11.回型标志 12.ROHS标志 Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and specifications are subject to change without prior notice for product improvement.
- Page 2 Ceramic Hob Instruction Manual / Installation Manual MODEL: LV-C560 Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and specifications are subject to change without prior notice for product improvement.
- Page 4 CONTENTS SAFETY INSTRUCTIONS SPECIFICATIONS PRODUCT OVERVIEW QUICK START GUIDE PRODUCT INSTALLATION OPERATION INSTRUCTIONS CLEANING AND MAINTENANCE TROUBLESHOOTING DISPOSAL AND RECYCLING...
- Page 5 SAFETY INSTRUCTIONS Intended Use The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation. If you find any damage, please contact the retailer or dealer.
- Page 6 SAFETY WARNINGS Your safety is important to us. Please read this information before using your cooktop. INSTALLATION Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. •...
- Page 7 OPERATION and MAINTENANCE Electrical Shock Hazard • Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician. •...
- Page 8 electronic devices (e.g. computers, MP3 players) near the appliance, as they may be affected by its electromagnetic field. • Never use your appliance for warming or heating the room. • After use, always turn off the cooking zones and the cooktop as described in this manual (i.e.
- Page 9 • WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket. •...
- Page 10 SPECIFICATIONS Cooking Hob LV-C560 Cooking Zones 4 Zones Supply Voltage 220-240V~ 380-415V 3N~ 50Hz or 60Hz Installed Electric Power 5500-6600W Product Size L×W×H(mm) 590X520X51 Building-in Dimensions A×B (mm) 560X480 Weight and Dimensions are approximate. Because we continually strive to improve our products we may change...
- Page 11 PRODUCT OVERVIEW Top View Max. 1200 W zone Max. 1800 W zone Glass plate Max. 1800 W zone Max. 1200 W zone ON / OFF Control panel Control Panel Time regulating controls Keylock control Power regulating controls ON/OFF control NOTE All the pictures in this manual are for explanation purpose only.
- Page 12 Product Information The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. The ceramic cooker hob centers on customers and adopts personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life.
- Page 13 QUICK START GUIDE Take care when frying as the oil and fat heat up very quickly, particularly if you’re using PowerBoost. At extremely high temperatures oil and fat will ignite spontaneously and this presents a serious fire risk. Cooking Tips •...
- Page 14 Heat Settings The settings below are guidelines only. The exact setting will depend on several factors, including your cookware and the amount you are cooking. Experiment with the Ceramic hob to find the settings that best suit you. Heat setting Suitability •...
- Page 15 PRODUCT INSTALLATION Selection Of Installation Equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work surface material (Wood and similar fibrous or hygroscopic material shall not be used as work surface material unless impreg- nated) to avoid the electrical shock and larger deformation caused by the heat radiation from the hotplate.
- Page 16 WARNING: Ensuring Adequate Ventilation Make sure the ceramic hob is well ventilated and that air inlet and outlet are not blocked. In order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 25mm from the bottom of the hob.
- Page 17 Adjust the bracket position to suit for different table top thickness. Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop after installation (see picture). Cautions 1. The ceramic cooker hob must be installed by qualified personnel or technicians. We have professionals at your service.
- Page 18 Connecting The Hob To The Mains Power Supply The power supply should be connected in compliance with the relevant standard, or a single-pole circuit break- er. The method of connection is shown below. 380-415V~ 220-240V~ 380-415V~ 220-240V~ 220-240V~ 220-240V~ 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents.
- Page 19 OPERATION INSTRUCTIONS Touch Controls • The controls respond to touch, so you don’t need to apply any pressure. • Use the ball of your finger, not its tip. • You will hear a beep each time a touch is registered. •...
- Page 20 How to Use 1. Start Cooking After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the ceram- ic hob has entered the stat of standby mode. 1. Touch the ON/OFF control.
- Page 21 Beware of hot Surfaces “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot.
- Page 22 4. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will flash for 5 seconds. 5. Buzzer will beep for 30 seconds and the timer indicator shows “- -” when the setting time finished.
- Page 23 Note: 1. The red dot next to power level indicator will illuminate indicating that zone is selected. 2. If you want to change the time after the timer is set, you have to start from step 1. 5. Over-Temperature Protection A temperature sensor equipped can monitor the temperature inside the ceramic hob.
- Page 24 CLEANING AND MAINTENANCE What? How? Important! • When the power to the cooktop is switched off, there will be no ‘hot surface’ indication but the cooking zone may still be hot! Take 1. Switch the power to the cooktop off. Everyday soiling on 2.
- Page 25 TROUBLESHOOTING Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to the service center. Problem Possible causes What to do...
- Page 26 Failure code Problem Solution Wait for the temperature of ceramic plate return to normal. High temperature of ceramic plate Touch “ON/OFF” button to restart unit. sensor. Temperature sensor of the NTC failure --open circuit. Replace the display board. Temperature sensor of the NTC failure --short circuit Supply voltage is below the rated voltage.
- Page 27 DISPOSAL AND RECYCLING Important instructions for environment Compliance with the WEEE Directive and Disposing of the Waster Product: This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waster electrical and electronic equipment (WEEE). This symbol indicates that this product shall not be disposed with other household wastes at the end of its service life.
