USER MANUAL
INDUCTION HOB
MODEL: LV- ID355
技术要求(版本号:B，2023-06）
，未注直线尺寸公差应符合GB/T1804-v；
70P以下为钉装，70P以上为胶装（特殊要求除外）
;[
多头灶
说明书
K
1
3
4
5
GS图标无高度要求，印刷可见即可
Pa/kPa/MPa
长度:mm/cm/m
时间:s/min/h 重量:kg
16166000A33155
LAVAMAT-MC-ID3592-A2（LV-ID355）-0501
材料: 100g双胶纸
1:1
广东美的生活电器制造有限公司
1
4
5
6
22
PAP
说明书、保修卡类
]
6
A
B
C
D
E
F
G
H

Advertisement

loading
Need help?

Need help?

Do you have a question about the LV-ID355 and is the answer not in the manual?

Questions and answers

Related Manuals for LAVAMAT LV-ID355

Summary of Contents for LAVAMAT LV-ID355

  • Page 1 3.该说明书的装订方式为： 钉装 15.目录及 4.说明书警语及认证标志应满足CE/UL标准，CE：警语部分大写字母高度不低于3mm，CE标志不低于5mm，WEEE标志不低于7mm； 页码 UL：大写字母字高不小于1/12”(2.11mm)，小写字母字高不小于1/16”(1.6mm)，“IMPORTANT SAFEGUARDS”，“SAVE THESE INSTRUCTIONS”等词，其字高不小于3/16”(4.8mm)，IMPORTANT SAFEGUARDS 必须在最前面。 5.产品应符合QMG-J53.021《产品说明书技术条件》的有关要求。 16.商标LOGO 6.有ROHS指令要求的物料应符合美的企业标准QML-J11.006《产品中限制使用有害物质的技术标准》。 16166000A33155 多头灶 LAVAMAT-MC-ID3592-A2（LV-ID355）-0501 说明书 标 记 处 数 更 改 文 件 号 签 字 日 期 材料: 100g双胶纸 制 图 刘灿 审 核 李艳 ---- 古广君...
  • Page 2 USER MANUAL INDUCTION HOB MODEL: LV- ID355 Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and specifications are subject to change without prior notice for product improvement. Consult with your dealer or manufacturer for details. The diagram above is just for reference.
  • Page 4 CONTENTS SAFETY INSTRUCTIONS SPECIFICATIONS PRODUCT OVERVIEW QUICK START GUIDE PRODUCT INSTALLATION OPERATION INSTRUCTIONS CLEANING AND MAINTENANCE TROUBLESHOOTING DISPOSAL AND RECYCLING...
  • Page 5 SAFETY INSTRUCTIONS Intended Use The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation. If you find any damage, please contact the retailer or dealer.
  • Page 6 SAFETY WARNINGS Your safety is important to us. Please read this information before using your cooktop. INSTALLATION Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. •...
  • Page 7 electric shock, for hob surfaces of glass-ceramic or similar material which protect live parts • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot • A steam cleaner is not to be used. •...
  • Page 8 • Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other cooking zones that are on. • Keep handles out of reach of children. • Failure to follow this advice could result in burns and scalds. Cut Hazard •...
  • Page 9 - Staff kitchen areas in shops, offices and other working environments; - Farm houses; - By clients in hotels, motels and other residential type environments; - Bed and breakfast type environments. • WARNING: The appliance and its accessible parts become hot during use. •...
  • Page 10 SPECIFICATIONS Cooking Hob LV- ID355 Cooking Zones 2 Zones Supply Voltage 220-240V~ 50Hz or 60Hz Installed Electric Power 3500W Product Size L×W×H(mm) 288X520X59 Building-in Dimensions A×B (mm) 268X500...
  • Page 11 PRODUCT OVERVIEW Top View Max. 1800/2000 W zone Glass plate Max. 1300/1500 W zone ON/OFF control Control panel Control Panel Keylock control Heating zone Power / Timer Timer ON/OFF Pause selection regulating Boost control control controls controls NOTE All the pictures in this manual are for explanation purpose only. Any discrepancy between the real object and the illustration in the drawing shall be subject to the real subject.
  • Page 12 Working Theory Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up. Iron pot Magnetic circuit Ceramic glass plate...
  • Page 13 QUICK START GUIDE Take care when frying as the oil and fat heat up very quickly, particularly if you’re using PowerBoost. At extremely high temperatures oil and fat will ignite spontaneously and this presents a serious fire risk. Cooking Tips •...
  • Page 14 Heat Settings The settings below are guidelines only. The exact setting will depend on several factors, including your cookware and the amount you are cooking. Experiment with the induction hob to find the settings that best suit you. Heat setting Suitability •...
  • Page 15 PRODUCT INSTALLATION Selection of Installation Equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work surface material (Wood and similar fibrous or hygroscopic material shall not be used as work surface material unless impreg- nated) to avoid the electrical shock and larger deformation caused by the heat radiation from the hotplate.
  • Page 16 WARNING: Ensuring Adequate Ventilation Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not blocked. In order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom of the hob.
  • Page 17 Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. Adjusting the Bracket Position Fix the hob on the work surface by screw 4 brackets on the bottom of hob(see picture) after installation.
  • Page 18 Connecting the Hob to the Mains Power Supply This hob must be connected to the mains power supply only by a suitably qualified person. Before connecting the hob to the mains power supply, check that: 1. The domestic wiring system is suitable for the power drawn by the hob. 2.
  • Page 19 OPERATION INSTRUCTIONS Touch Controls • The controls respond to touch, so you don’t need to apply any pressure. • Use the ball of your finger, not its tip. • You will hear a beep each time a touch is registered. •...
  • Page 20 • Do not use cookware with jagged edges or a curved base. • Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Use pans whose diameter is as large as the graphic of the zone selected. Using a pot a slightly wider energy will be used at its maximum efficiency.
  • Page 21 How to Use 1. Start Cooking 2. Place a suitable pan on the cooking zone that you Touch the ON/OFF control for one second. After power on, the buzzer beeps once, all displays show “–” or “– –”, indicating wish to use. that the induction hob has entered the state of standby mode.
  • Page 22 2. Finish Cooking 1. Touching the heating zone selection control that 2. Turn the cooking zone off by scrolling down to “0”. you wish to switch off. Make sure the display shows “0”. POWER DOWN 4. Beware of hot surfaces 3.
  • Page 23 4. Timer Control You can use the timer in two different ways: • You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up. • You can set it to turn one or more cooking zones off after the set time is up. The timer of maximum is 99 min.
  • Page 24 Setting the Timer to Turn One or More Cooking Zones Off Set one zone 1. Touching the heating zone selection control that you want to set the timer for. 2. Set the time by touching the “-” or “+” control of the timer. Hint: Touch the “-”...
  • Page 25 5. Using the Boost Function Activate the boost function 1. Touching the heating zone control. 2. Touching the Boost cantrol. Make sure the display shows “p”. Cancel the Boost function 1. Touching the heating zone control that you wish 2. Turn the cooking zone off by touching the Boost to cancel the boost function.
  • Page 26 7. Default Working Times Auto shut down is a safety protection function for your induction hob. It shut down automatically if ever you forget to turn off your cooking. The default working times for various power levels are shown in the below table: Power level Default working timer (hour) When the pot is removed, the induction hob can stop heating immediately and the hob automatically switch off after...
  • Page 27 CLEANING AND MAINTENANCE What? How? Important! • When the power to the cooktop is switched off, there will be no ‘hot surface’ indication but the cooking zone may still be hot! Take 1. Switch the power to the cooktop off. Everyday soiling on 2.
  • Page 28 TROUBLESHOOTING Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to the service center. Problem Possible causes What to do...
  • Page 29 Failure Display and Inspection The induction hob is equipped with a self diagnostic function. With this test the technician is able to check the function of several components without disassembling or dismounting the hob from the working surface. 1. Failure code occur during customer using & Solution; Failure code Problem Solution...
  • Page 30 2. Specific Failure & Solution Failure Problem Solution A Solution B Check to see if plug is secured tightly in outlet and that outlet is No power supplied. working. The accessorial power board The LED does and the display board connect- Check the connection.
  • Page 31 DISPOSAL AND RECYCLING Important instructions for environment Compliance with the WEEE Directive and Disposing of the Waster Product: This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waster electrical and electronic equipment (WEEE). This symbol indicates that this product shall not be disposed with other household wastes at the end of its service life.
