Features:
 DCF Radio control time function
 Perpetual Calendar Up to Year 2099
 Days of week in 8 languages user selectable: English, German, Italian, French, Spanish, Netherlands, Polski
Danish
 Time in 12-hour or 24-hour format.
 Two daily alarms
 Automatic snooze function (OFF or 5~60min)
 Sunrise and sunset time (select city)
 Moon phases and tides
 Humidity: Indoor & Outdoor measurable range: 20%RH ~ 95%RH
 Temperature:
— Indoor temperature measurement ranges: -9.9°C (15°F) to 50°C (122°F)
— Outdoor temperature measurement ranges: -40°C (-40°F) to70°C (158°F)
— Temperature alternatively in °C or °F.
— outdoor thermometer alert.
 Minimum/maximum display for air humidity and temperature
 Display of indoor comfort and mold risk
 Indoor temperature upper and lower limit alert
 Indoor humidity upper and lower limit alert
 Outdoor temperature upper and lower limit alert and frost warning
 Outdoor humidity upper and lower limit alert
 Wireless Outdoor Sensor:
— Wall Mount or Table Stand
— 433.92MHz RF transmitting frequency
— 60 meters transmission range in an open area
—Up to 3 wireless outdoor sensors can be connected. (One Wireless outdoor Sensor Included)
 Atmospheric pressure:
— Atmospheric pressure measurement ranges: 600 hPa/mb to 1100 hPa/mb
— Pressure alternatively in hPa/mb or inHg
—The histogram shows the historical trend of the 24-hour atmospheric pressure
 The weather forecasting function
 Power Supply:
Weather Station:
Battery: 2 x LR03 AAA
Equipment power input: DC 5V 600mA (dedicated power adapter)
WS6236 User Manual
17.72 inHg to 32.50 inHg
and

Advertisement

loading
Need help?

Need help?

Do you have a question about the WS6236 and is the answer not in the manual?

Questions and answers

Summary of Contents for La Crosse Technology WS6236

  • Page 1 WS6236 User Manual Features:  DCF Radio control time function  Perpetual Calendar Up to Year 2099  Days of week in 8 languages user selectable: English, German, Italian, French, Spanish, Netherlands, Polski Danish  Time in 12-hour or 24-hour format.
  • Page 2 WS6236 User Manual Wireless Outdoor Sensor: Battery:2 x LR03 AAA F.Y.I.: The wireless remote sensor can work at -30°C to +70°C. Please choose the right battery according to the limit temperature of the wireless sensor: Alkaline zinc manganese battery can work at -20°C to +60°C Polymer lithium ion rechargeable battery can work at -40°C to +70°C.
  • Page 3 WS6236 User Manual Minimum Recording Symbol rising trend symbol falling trend symbol : High temperature or : Low temperature or humidity alarm symbol humidity alarm symbol : frost warning symbol Radio Control Time Backlit Light sensing mode Reception Symbol : daylight saving time sign...
  • Page 4 WS6236 User Manual Initial operation:  Open Weather Station battery compartment cover, open Weather Station battery compartment cover, insert 2 x AAA batteries observing polarity [ “+” and “–” marks]  After the weather station is connected to the power supply according to the above two steps, all the icons on the LCD display will light up for 3 seconds, you will hear the buzzer, and check the indoor temperature, humidity and pressure.
  • Page 5 WS6236 User Manual buttons set the DST function to activate(ON) or close(OFF)  Press “ ” to confirm your setting, switch to time zone setting, Now use “▲/ ” and “▼” buttons set a correct time zone (-2 to +2).
  • Page 6 WS6236 User Manual NÉERLANDAIS ZONDAG MAANDAG DINSDAG WOENSDAG DONDERDAG VRIJDAG ZATERDAG DANOIS SONDAG MONDAG TIRSDAG ONSDAG TORSDAG FREDAG LORDAG POLONAIS NIEDZIELA PONIEDZI WTOREK SRODA CZWARTEK PIATEK SOBOTA Month code display Language January February March April June July August September October...
  • Page 7 WS6236 User Manual Setting the daily alarms:  Press “ ” button once to check the alarm time and then Press and hold down“ ” button more than 2 seconds to enter the alarm setting mode, first enter the alarm 1 hour setting. Use the “▲/ ”...
  • Page 8 WS6236 User Manual  Press “ ” button can switch the display time display or ALARM1 time or ALARM2 time, in the alarm1 or alarm2 display mode, press the “▲/ ” button to turn the alarm on or off.  The alarm 1 or alarm 2 turn on, the “...
  • Page 9 WS6236 User Manual  Press the “ ” button once to enter the city selection mode, in the city selection mode, use the “▲/ ” and “▼” buttons to select the correct city according to the three-character code of the city corresponding to the table below...
  • Page 10 WS6236 User Manual Romania Magdeburg Bucharest (RO) Cyprus München Nicosia (CY) Northen Nürnberg Belfast Ireland (NI) United Osnabrück Washington DC States(US) Passau New York Regensburg Los Angeles Rostock Chicago Saarbrücken Houston Stuttgart Phoenix San Antonio Würzburg San Diego Austria(AT) Bregenz...
  • Page 11 WS6236 User Manual Bari Cincinnati Bolzano Lincoln Cagliari Orlando Florence Buffalo Foggia Richmond Genoa Columbia Lecce Little Rock Messina Columbus Milan Grand Rapids Naples Salt Lake City Palermo Providence Parma Manchester(NH) Perugia San Diego Rome Santa Fe San Remo Bismarck...
  • Page 12 WS6236 User Manual Moscow Mendoza Novosibirsk Rosario Kazan Chile Santiago de Chile Volgograd Colombia Bogotá Australia(A U) and New Yekaterinburg Canberra Zealand(NZ Serbia(RS) Belgrade Melbourne Slovakia(S Bratislava Sydney Kosice Wellington Slovenia(SI Ljubliana Adelaide Spain(ES) Alicante Brisbane Andorra Darwin Badajoz Hobart...
  • Page 13 WS6236 User Manual Temperature & Humidity detection:  Indoor temperature measuring range: -9.9°C (+14°F) ~ +50°C (+122°F), LL.L °C(°F) will be displayed if value lower than -9.9°C (+14°F), HH.H °C(°F) will be displayed if value higher than +50°C (+122°F).  Outdoor temperature measuring range: -50°C (-58°F) ~ +70°C (+158°F), LL.L °C(°F) will be displayed if value lower than -50°C (-58°F), HH.H °C(°F) will be displayed if value higher than +70°C (+158°F).
  • Page 14 WS6236 User Manual Maximum/Minimum Temperature/Relative Humidity  To toggle indoor/outdoor maximum, minimum temperature and humidity data, press the “▼” button: Once to show the maximum temperature and humidity values. Twice to sow the minimum temperature and humidity values Three times to return to the current temperature and humidity levels ...
  • Page 15 WS6236 User Manual buttons to set the lower limit alert value  Press “ ” to confirm your setting and to end the setting procedure.  When setting the upper and lower limit alerts for outdoor temperature and outdoor humidity, press the “...
  • Page 16 WS6236 User Manual <35% 35%~44% 45%~65% 66%~80% >80% Humidity range  The moldy risk display reads the indoor humidity to determine moldy risk level. The weather station will display one of 4 indicators: HI (high) ME (medium) LO (low) and no risk (no arrow displayed).
  • Page 17 WS6236 User Manual sunny slightly cloudy cloudy rainy stormy Snowy F.Y.I.:  The Snowy icon will only appear if the outdoor temperature is below -4℃ (+25℉) and the forecast would be rainy or stormy, By default, according to the temperature of CH1, when there is no signal in CH1, it is calculated according to the temperature of CH2.
  • Page 18 WS6236 User Manual  A continuously displayed radio mast icon indicates that the DCF signal was received successfully  The symbol "DST" indicating the time of receipt for daylight saving time.  We recommend a minimum distance of 2.5 meters to all sources of interference, such as televisions or computer monitors ...
  • Page 19 WS6236 User Manual -in the event of a malfunction, -if the device has been damaged in any way. Never use sharp objects to access the inside of the power supply. Do not disassemble the power supply, do not throw it into a fire. Do not attempt to disassemble or modify this product or any of its components. Do not expose the food to high temperatures or direct sunlight.
  • Page 20 WS6236 User Manual •As stated on the gift box and labeled on the product, reading the “User manual” is highly recommended for the benefit of the user. This product must however not be thrown in general rubbish collection points. •The manufacturer and supplier cannot accept any responsibility for any incorrect readings and any consequences that occur should an inaccurate reading take place.
