Minoston ZW922 User Manual

Wall remote

Advertisement

Quick Links

FCC
Federal Communications Commission (FCC) Statement FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected. Consult the dealer or an experienced radio/TV technician for help. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
IC Caution:
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
DECLARATION DE CONFORMITE D'INDUSTRIE CANADA
Ce périphérique a été testé et reconnu conforme aux limites spécifiées dans RSS-210.
Son utilisation est soumise aux deux conditions suivantes :
(1) il ne doit pas provoquer d'interférences gênantes et
(2) il doit tolérer les interférences re.ues, notamment cellessusceptibles d'en perturber le fonctionnement.
WARRANTY
ZW922User Manual
ZW922 Wall Remote User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZW922 and is the answer not in the manual?

Questions and answers

Summary of Contents for Minoston ZW922

  • Page 1 ZW922User Manual ZW922 Wall Remote User Manual Federal Communications Commission (FCC) Statement FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 ZW922User Manual Minoston Products warrants this product to be free from manufacturing defects for a period of two years from the original date of consumer purchase. This warranty is limited to the repair or replacement of this product only and does not extend to consequential or incidental damage to other products that may be used with this product.
  • Page 3 This product is a battery power ,It's sleep most of the time. ZW922 is a security enabled Z-Wave Plus® device. A security Enabled Z-Wave Plus® Controller must be used in order to fully utilize the product. GENERIC_TYPE: GENERIC_TYPE_WALL_CONTROLLER SPECIFIC_TYPE: SPECIFIC_TYPE_NOT_USED...
  • Page 4 ZW922User Manual Button Function Description Add/Include the device to network: Press the BUTTON 1 6 times, device will blinks BLUE during inclusion if not connected to Z-Wave hub. Device will stays on GREEN for 2 seconds if included successfully, stays on RED for 2 seconds if failed. Remove/Exclude the device to network: Press the BUTTON 2 6 times, device will blinks PURPLE during inclusion if not connected to Z-Wave hub.
  • Page 5 ZW922User Manual Adding Your Device To Hub The device support two methods of inclusion, When using a Z-Wave Plus® certified controller choose Network Wide Inclusion or SmartStart. Network Wide Inclusion To A Z-Wave® Network Refer to your primary controller instructions to process the inclusion / exclusion setup procedure. When prompted by your primary controller, click the Z-Wave button 6-tap times in one second.
  • Page 6 ZW922User Manual Command Class Command Class Name Version Required Security Class Z-Wave Plus Info none Configuration highest granted Association highest granted Multi Channel Association highest granted Association Group Information highest granted Transport Service none Version highest granted Manufacturer Specific highest granted Device Reset Locally highest granted Power Level...
  • Page 7 ZW922User Manual Indicator Command Class The indicator will flashes according the indicator set command received from HUB. Indicator ID Property ID 0x50 (NODE IDENTIFY) 0x03(ON OFF PERIOD) 0x50 (NODE IDENTIFY) 0x04(ON OFF CYCLES) 0x50 (NODE IDENTIFY) 0x05(ONE TIME ON OFF PERIOD) Association Group Name Node Count...
