Minoston MP31ZD Quick Start Manual

MP31ZD
SIZE: 150 x 255 mm
材质：80G 书写纸
拆法：风琴页 65 x 39 mm 成品
单色黑白印刷
正面
Features:
1. Z-Wave on / off + dimmer control.
2. Grounded 3-wire power connection for safety.
3. Remember and restore on/off status after power failure.
4. Built-in Z-Wave Plus signal repeater to extend network range
5. S2 security and 700 Z-Wave chip for reliable wireless communication.
6. Work with all certificated Z-Wave controllers.
Min brightness level setting( Refer to Parameter 11)
1: Press the button 5 times quickly, the LED indicator flashes slowly to enter the setting "Min
brightness" mode. The lamp will adjusts to the min brightness automatically.
2: Hold the button to adjust the brightness of the bulb, select the appropriate brightness to set
the min brightness.
3: Press the button 5 times quickly to confirm it (the min brightness setting is completed).
The LED indicator will flashes 3 times.
Max brightness level setting( Refer to Parameter 12)
1: Press the button 10 times quickly, the LED indicator flashes slowly to enter the setting "Max
brightness" mode. The lamp will adjusts to the max brightness automatically.
2: Hold the button to adjust the brightness of the bulb, select the appropriate brightness to set
the max brightness.
3: Press the button 10 times quickly to confirm it (the max brightness setting is completed).
The LED indicator will flashes 3 times.
Remark: If the setting is not confirmed at Step 3, the setting mode will be exited after 10S.
This product can be included and operated in any Z-Wave network with other Z-Wave certified
devices from other manufacturers and/or other applications. All non-battery operated nodes
within the network will act as repeaters regardless of vendor to increase the reliability of the
network. This Device supports Lifeline (association group 1) supporting 1 node for lifeline
communication. Group 1 must be assigned the Node ID of the primary controller where
unsolicited notifications will be sent.
The Z-Wave controller should set this association automatically after inclusion.
Lifeline association only supports the "Device Reset Locally" function.
Adding Device To Z-Wave Network for QR CODE
Specification
Input: 125VAC 60Hz
Frequency: 908.42 MHz
Loading: 200W Incandescent 100W
Dimmable CFL/LED
Indoor use in dry location
Z-Wave Dimmer Plug
MP31ZD (ZW39M)
LED indicator
Blue: Light status indicator
Blue: ADD / Inclusion
Purple: Remove / Exclusion
Red: Network Failure / Over-temperature
Warning
Program button
Press 1x: Manually
Press 3x: Z-Wave Network configuration
Reset: Press the button twice then hold it
for 10 seconds
Please contact us if you have any questions:
www.minoston.com
ask@minoston.com
Z-WAVE INTEROPERABILITY
Scan here for SmartStar inclusion
Note: DSK Code can be found on the
packaging box.
Do not remove or damage them.
Z-Wave Network Configuration
Adding Device To Z-Wave Network
1. Follow the instructions for your Z-Wave certified controller to add a device to the Z-Wave
network.
2. Once the controller is ready to add your device, press the Manual/ Program button on the
smart plug 3 times quickly. The blue LED will flash quickly.
Auto-add mode: LED will flash within 30 seconds after the first plug.
Now, you have completed control to turn your fixture ON / OFF according to groups,
schedules and interactive automation programmed by your controller. If your Z-Wave certified
controller features remote access, you can control your fixture from your mobile devices.
Again: If you have issues with pairing / including, please move the device as close as possible to
the hub and try again--you can move to your final location when completed.
Note: If the manual button doesn't light up after pressing 3 times, please reset the
device: click the button twice quickly then hold it at least 10 seconds.
This operation could be done when manual control is functional--single press can turn on/off
the lamp.
To Remove The Device
1. Follow the instructions for your Z-Wave certified controller to remove a device from the
Z-Wave network.
2. Once the controller is ready to remove your device, press the manual / program button on
the smart plug 3 times quickly.
To Return The Device To Factory Defaults
Manual: Click the button twice quickly then hold it at least 10 seconds. (Reset successfully, light
will flash once.)
Host reset: Remove it from hub, the device will be restore to factory default.
Association Group
Group 1 supports 1 node ID,Group 2 Supports maximum of 5 node ID's
Association Group 1: Z-Wave Plus Lifeline
Association Group 2: Send Basic Set ON / Off
Over-temperature protection is protection against
overheating of the protected equipment. When the device's
temperature is high, the LED will light up in red and cut
down the power. Please power off the device and use it after
Overloading
Warning
the temperature of the device drops.
Warranty
Our Products warrant this product to be free from manufacturing defects for a period of one
year from the original date of consumer purchase. This warranty is limited to the repair or
replacement of this product only and does not extend to consequential or incidental damage to
other products that may be used with this product. This warranty is in lieu of all other warranti-
es, expressed or implied. Some states do not allow limitations on how long an implied warranty
lasts or permit the exclusion or limitation of incidental or consequential damage, so the above
limitations may not apply to you. This warranty gives you specific rights, and you may also have
other rights which vary from state to state.
Parameter Settings
LED Indicator
This parameter can access you to choose the LED indicator to be on when the plug(light) is
on/off, or LED indicator remains on/off all times.
(LED flashes 3 times when the configuration parameter changed.)
--- Parameter =2, size =1byte, Default =0
Value=0 (default) LED is On when switch (light) is On.
Value=1 --- LED is On when switch (light) is Off.
Value=2 --- LED is always Off.
Value=3 --- LED is always On.
Auto Turn-Off Timer
This parameter can access you to set a timer to make the switch turn off
automatically after the switch turns on.The numberentered as value
corresponds to number of minutes. Operation: Set up on the hub.
(LED flashes 3 times when the configuration parameter changed.)
--- Parameter =4, Size=4，Value: 0– 65535(minutes);
Value=0(default) disable
