- Page 1 User Guide MS-63U1C USB-C Extender Set - up to 50m. USB 3.2 Gen1 PoC, RS-232 pass through Revision: 1.0 - Aug 2024...
- Page 2 Do not disassemble either the Transmitter or Receiver units for any reason. Doing so will void the manufacturer’s warranty. • MSolutions reserves the right to change the specifications of this unit without prior notice. As a result of this, physical representations or graphical elements contained within this user guide may not be accurate.
- Page 3 MS-63U1C USER GUIDE Introduction The MSolutions MS-63U1C is a USB 3.2 Gen 1 USB-C extender allowing for a single USB-C data channel to be extended to distances of up to 50m over a single Cat6A (or above) infrastructure. The extender features RS-232 serial pass-through and bi-directional 12V PoC (Power over Cable) expand the capabilities of this extender kit for a variety of commercial uses..
- Page 4 MS-63U1C USER GUIDE Connectivity Overview - Device Front panel: • Cat6A (or above) Link - connect to Cat cable from receiver • USB-C - connect USB-C peripheral Back panel: • Control - Micro USB for firmware and control (reserved for future use) •...
- Page 5 MS-63U1C USER GUIDE Understanding the LED’s This MSolutions extender set includes status LED indicators on both the Host and Device products to show active connections and to further help integrators diagnose potential problems with the associated cabling. The RJ45 Link connections on both the host and device units have orange and green LED’s.
- Page 6 Power The MS-63U1C uses bi-directional PoC (Power over Cable) to provide power from either the Host or Device unit to the far side of the link over the Cat6A (or above) cable. Please only use the supplied...
- Page 7 MS-63U1C USER GUIDE Specifications Device Host • USB-C connectivity: 1 x USB-C (female • USB-C connectivity: peripheral 1 x USB-C (female) - host • USB control: 1 x Micro USB (female) • USB control: 1 x Micro USB (female) •...
- Page 8 MS-63U1C USER GUIDE Schematic...
