Summary of Contents for MSolutions 1Connect MS-63DOC
- Page 1 User Guide 1Connect ™ MS-63DOC USB-C docking extension system – up to 100m Revision: 1.0 - Nov 2024...
- Page 2 Do not disassemble either the Transmitter or Receiver units for any reason. Doing so will void the manufacturer’s warranty. • MSolutions reserves the right to change the specifications of this unit without prior notice. As a result of this, physical representations or graphical elements contained within this user guide may not be accurate.
- Page 3 MS-63DOC USER GUIDE Introduction The MSolutions MS-63DOC Docking Extender is a revolutionary solution that simplifies installation and consolidates all video, audio, and data signals through a single USB-C cable and extends it over a single Cat 6A cable up to 100 meters. More than a simple receiver, the MS-63DOC Device has an internal IP control unit that can manage all the third-party IP devices in the meeting room.
- Page 4 MS-63DOC USER GUIDE Connectivity Overview - Device ① ② ③ ④ ⑤ Front panel: ①+② - HDMI OUT 1,2 – 4K60FPS ③+④ - 1Gbps 2 port TJ45 Ethernet hub ⑤ - RS-232, 3-pin Phoenix connector to connect a serial device/controller ⑥...
- Page 5 MS-63DOC USER GUIDE Connectivity Overview - Host ① ② ③ ④ ⑤ Front panel: ① - HDbaseT out – Link out ② - Power jack 12Vdc/2A ③ - USB-C – USB type C for the main connection to the Host PC (Full feature USB-C) ④...
- Page 6 MS-63DOC USER GUIDE Understanding the LED’s This MSolutions extender set includes status LED indicators on both the Host and Device products to show active connections and to further help integrators diagnose potential problems with the associated cabling. The RJ45 Link connections on both the host and device units have orange and green LED’s.
- Page 7 MS-63DOC USER GUIDE HDMI HDMI The MS-63DOC device has 2 ports of HDMI2.0 that support 4K60FPS resolution. The devices also support extended view for dual display work. Please note that some PCs may require Display Link drivers in order to transmit the video over the single USB-C. For details use the following links: Windows: www.synaptics.com/products/displaylink-graphics/downloads/windows-11.0-m0-public Mac:...
- Page 8 Power The MS-63DOC uses uses two power supplies, one at each end. Please only use the supplied 12V/2A DC PSU supplied with the MSolutions MS-3doc to power the unit. Audio The MS-63DOC device has an analog stereo audio out 3.5mm port. The audio that plays is being transmitted over the same USB-C host connection.
- Page 9 MS-63DOC USER GUIDE To access the web interface, simply open a browser and input the IP address of the MS-63DOC. The first tab when accessing the web interface is the MS-63DOC control system. On this page, the user can See and use the control interface programmed on the MS-63DOC. Example of Control System screen The 2nd tab is the Info page: This page displays all the relevant information on the device, such as: IP address,...
- Page 10 MS-63DOC USER GUIDE In the 3rd tab are the Setup pages: To access this field the default credentials are: User: MSolutions Password: MSolutions The first subtab is the Admin tab. The user can set a new login user and password on this tab.
- Page 11 MS-63DOC USER GUIDE The next subtab is the Logo tab: On this tab, the user can upload their logo. It needs to be up to 200x200 pixels and smaller than 50Kb. Example of Setup screen, Logo tab The Com subtab: On this subtab, the user can change the communication parameters of the MS-63DOC, both IP and serial.
- Page 12 (“Show”), the buttons will appear on the main page under control. Make sure to add the length of the command before the command and end it with FF. You can also download the MSolutions script creator software for easier use. Example of Macro Setting screen...
- Page 13 MS-63DOC USER GUIDE Specifications • USB connectivity Host: 1x USB-C (female) – • Individual unit weight: 300g data & video, 2x USB-A (female) – data • Package dimensions (W x D x H): • USB connectivity Device: 1x USB-C (female) – 163 x 147 x 85mm data, 2x USB-A (female) –...
- Page 14 MS-63DOC USER GUIDE Schematic...
- Page 15 www.m4sol.com...
