ANTENNAS
Chapter 4 – Antennas
Antenna System Cellular Devices
The antenna system is defined as the UFL connection point from the device through the cable and antenna. Device
performance depends on implementation and antenna system design. Integrating the antenna system is a critical
part of the design process; therefore, it is essential to consider it early so the performance is not compromised.
Requirements for Cellular Antennas with regard to FCC/IC Compliance
The antenna must be the same type, with similar performance and in- and out-of-band radiation patterns as the
listed antenna. The antenna used must stay below the FCC/IC maximum gain.
For our bundles, MultiTech may change antennas over time. The listed antenna(s) is used as a reference or was
shipping when this document was last updated.
This device has been designed to operate with the antennas listed below and having a maximum gain for 850 MHz
of <= 6.4 dBi , for 1700 MHz of <= 6.5 dBi, and for 1900 MHz of <= 3 dBi. Antennas not included in this list or that
have a gain greater than specified are strictly prohibited for use with this device. The required antenna impedance
is 50 ohms.
PTCRB Requirements
There cannot be any alteration to the authorized antenna system. The antenna system must be the same type with
similar in-band and out-of-band radiation patterns and maintain the same specifications.
Antenna Overview
For MTSMC-LAT1 models, we tested with the Laird LTE Antenna.
For MTSMC-LEU1 or MTSMC-LVW2 models, we tested with the Wieson LTE Antenna
EAD Antenna Used with -LAT1 and -LVW2 Models
The cellular radio portion of the device is approved with the following antenna or for alternate antennas meeting
the given specifications.
Manufacturer:
Description:
MultiTech ordering information:
Model
ANLTE3-2HRA
ANLTE3-10HRA
ANLTE3-50HRA
22
Embedded Antenna Systems, Ltd. (EAD)
Dipole Blade Antenna for LTE
Quantity
2
10
50
®
