Video Tutorial:
Tillers – Assembly
Four Blade Hand-Held
Cultivator Tiller - BT-477
User Manual
[Revision 6.0 November 2019]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND
MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in
appearance, assembly, inclusions, specifications, description and packaging.
Advertisement
Related Manuals for Baumr-AG BT-477
Summary of Contents for Baumr-AG BT-477
- Page 1 Video Tutorial: Tillers – Assembly Four Blade Hand-Held Cultivator Tiller - BT-477 User Manual [Revision 6.0 November 2019] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in...
- Page 2 Specifications ............................13 Preface Thanks for buying the Four Blade Hand-Held Cultivator Tiller - BT-477, another high-quality machine from our company! To get the most out of your purchase, please read the manual before using the tiller. We ask you to please read this manual carefully beforehand in order to familiarise yourself with this product and after reading, please store this instructional manual for future reference.
- Page 3 Never operate the tiller without good visibility or light. • Be careful when tilling in hard ground. The tines may catch in the ground and propel the tiller backwards. If this occurs, let go of the handlebars and do not restrain the machine. E&OE © 2019 Baumr-AG...
- Page 4 • When leaving the operating position for any reason: − Shut off the engine. − Wait for all moving parts to stop. E&OE © 2019 Baumr-AG...
- Page 5 Tiller Cultivator Know your Tiller E&OE © 2019 Baumr-AG...
- Page 6 Tri-wing nuts (for handles) Handle Frame Cable ties Upper Handle Bottle (for fuel and 2 stroke mixing) Twin Wheel axle Multi Tool (With 17/19mm hex and Phillips head tip) Blade Pins Allen Keys (5mm and 4mm) E&OE © 2019 Baumr-AG...
- Page 7 Place the motor base upside down (ensuring NO fuel is in the tank – Fig. 1a) and place 1 blade with the spacer facing outwards and align the pin holes (Fig. 1b). Figure 1a Figure 1b Step 2: Place a second blade with the spacer facing in and align the pin holes (Fig. 2). Figure 2 E&OE © 2019 Baumr-AG...
- Page 8 Step 3: Insert blade pins (Fig. 3a), then split pin (Fig. 3b) and bend legs (Fig. 3c). Figure 3a Figure 3b Figure 3c Step 4: Do the same for the other side (Fig. 4). Figure 4 E&OE © 2019 Baumr-AG...
- Page 9 Turn motor base so it is standing upright on the wheels and tiller blades (Fig. 6a). Attach handle frame (Fig. 6b) with screws and tri wing nuts. Ensure that the concaved head is on the inside (Fig. 6c) and the tri wing nuts are on the outside (Fig. 6d). Figure 6a Figure 6b E&OE © 2019 Baumr-AG...
- Page 10 If this does happen, please cut cable tie and replace with a newly purchased cable ties. Figure 8a Figure 8b E&OE © 2019 Baumr-AG...
- Page 11 Tiller Cultivator Figure 8c Step 9: This is now complete (Fig. 9). Please refer to our quick start guide. Figure 9 E&OE © 2019 Baumr-AG...
- Page 12 Step 8: Squeeze throttle according to desired need. Step 4: Turn choke to “COLD.” Step 9: When finished, turn ON/OFF switch to OFF. Step 5: Pull starter cord 3-4 times or until engine starts. Click to Watch: Starting a 2-Stroke E&OE © 2019 Baumr-AG...
- Page 13 Clean the spark plug and check the electrode gap periodically. Below are dimensions if it needs replacing. This product comes with a Torch branded spark plug, model L7T. Please see below for cross referenced spark plugs: E&OE © 2019 Baumr-AG...
- Page 14 Every 100 working hours, change the grease in the reduction gearbox. WARNING! Maintenance procedures that are not reported in this manual must only be carried out by an authorised service personnel. Only use original spare parts. E&OE © 2019 Baumr-AG...
- Page 15 Tiller Scope (total width 300mm of tiller teeth) Tilling Depth 150mm (adjustable) Engine Type 2 Stroke Displacement 65cc 9,000RPM Starting System Recoil (pull cord start) Fuel Type Regular Unleaded 95 +RON Fuel-Oil Ratio 25:1 Fuel Volume 1.2L E&OE © 2019 Baumr-AG...
- Page 16 ©2019 Baumr-AG. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,...
