Page 1 Pantone 419C Owner's Manual for Maintenance and Safety OUTLAW 525 IRS This Category "S" (Sport) ATV is a high-performance ATV for off-road use only. It is for sport-type recreational and competitive use by operators with advanced skills and substantial experience. Operation is prohibited for anyone under 16 years of age.
Page 2 WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. A card containing important ATV safety information should be attached to the owner's manual on the next page. If you cannot locate this card, or if it has been removed, please call 1-800-342-3764 for assistance.
Page 3 The text is printed on 100% recycled with 40% post-consumer waste (PCW).
Page 4 S avoid paved surfaces - pavement may GEAR seriously affect handling and control READ OWNER'S MANUAL. FOLLOW ALL INSTRUCTIONS AND WARNINGS. For your nearest Polaris dealer, call 1-800-POLARIS or visit www.polarisindustries.com Polaris Sales Inc., 2100 Hwy 55 Medina, MN 55340 Phone 1-888-704-5290 Part No.
Page 5 Visit us at www.polarisindustries.com...
Page 6 POLARIS, THE WAY OUT and OUTLAW are registered trademarks of POLARIS Industries Inc. Copyright 2010 POLARIS Sales Inc. All information contained within this publication is based on the latest product information at the time of publication. Due to constant improvements in the design and quality of produc- tion components, some minor discrepancies may result between the actual vehicle and the information presented in this publication.
Page 7 Welcome Thank you for purchasing a POLARIS vehicle, and welcome to our world-wide family of POLARIS owners. We proudly produce an exciting line of utility and recreational products. • Snowmobiles • All-terrain vehicles (ATVs) • RANGER utility vehicles ® • Victory Motorcycles ®...
Page 8 Master Service Dealer (MSD) technician. ® Your POLARIS dealer knows your vehicle best and is interested in your total satisfaction. Be sure to return to your dealership for all of your service needs during, and after, the warranty period.
Page 9 Safety ......10 POLARIS Products ... . .170 Features and Controls .
Page 10 Introduction Safety Words and Symbols The following signal words and symbols appear throughout this manual and on your vehicle. Your safety is involved when these words and symbols are used. Become familiar with their meanings before reading the manual. The safety alert symbol indicates a potential personal injury hazard.
Page 11 Failure to follow the warnings and safety precautions contained in this manual can result in severe injury or death. A POLARIS ATV is not a toy and can be hazardous to operate. This vehicle handles differently than other vehicles, such as motorcycles and cars. A collision or rollover can occur quickly, even during routine maneuvers like turning, or driving on hills or over obstacles, if you fail to take proper precautions.
Page 12 Remove the spare key and store it in a safe place. An ignition key can be duplicated only by ordering a POLARIS key blank (using your key number) and mating it with one of your existing keys. The ignition switch must be replaced if all keys are lost.
Page 13 Introduction Vehicle Identification Numbers Vehicle Model Number: _____________________________________________________________________________ Frame Vehicle Identification Number (1): _______________________________________________________________ Engine Serial Number (2): ___________________________________________________________________________ Key Number (on the key): ___________________________________________________________________________...
Page 14 Safety Safety Training ATV safety training is a top priority for If you purchased a used POLARIS ATV in POLARIS. POLARIS strongly encourages the United States, you can enroll in the ATV you and any family members who will be RiderCourse for a fee.
Page 15 Safety Safety Training A POLARIS ATV is an off-road vehicle. Follow the recommended maintenance Familiarize yourself with all laws and program outlined in your owner's manual. regulations concerning the operation of this This program is designed to ensure that all vehicle in your area.
Page 16 The warranty on your POLARIS ATV is terminated if any equipment has been added to the vehicle, or if any modifications have been made to the vehicle, that increase its speed or power.
Page 17 Helmet Wearing a helmet can prevent a severe head injury. When- ever riding a POLARIS vehicle, always wear a helmet that Gloves meets or exceeds established safety standards. Protection Approved helmets in the USA and Canada bear a U.S.
Page 18 Safe Riding Gear Eye Protection Do not depend on eyeglasses or sunglasses for eye protection. Whenever riding a POLARIS vehicle, always wear shatterproof goggles or use a shatterproof helmet face shield. POLARIS recommends wearing approved Personal Protective Equipment (PPE) bearing markings such as VESC 8, V-8, Z87.1, or CE.
Page 19 Safety Safety Warnings WARNING Failure to operate the ATV properly can result in a collision, loss of control, accident or overturn, which may result in serious injury or death. Heed all safety warnings outlined in this section of the owner’s manual.
Page 20 Beginning and inexperienced operators should complete the ATV RiderCourse offered by POLARIS through the SVIA. They should then regularly practice the skills learned in the course and the operating techniques described in the Owner's Manual.
Page 21 Safety Safety Warnings Handling Gasoline Exposure to Exhaust Gasoline is highly flammable and explosive Engine exhaust fumes are poisonous and can under certain conditions. cause loss of consciousness or death in a short time. Never start the engine or let it run in an •...
Page 22 Safety Safety Warnings Failure to Inspect Before Operating Protective Apparel Failure to inspect and verify that the ATV is in Operating this ATV without wearing an approved safe operating condition before operating helmet increases the risk of a serious head injury increases the risk of an accident.
Page 23 Safety Safety Warnings Carrying a Passenger Using Alcohol or Drugs Carrying a passenger greatly reduces the Operating the ATV after consuming alcohol or operator's ability to balance and control the ATV, drugs could adversely affect operator judgment, which may result in an accident or overturn. reaction time, balance and perception.
Page 24 Safety Safety Warnings Operating on Pavement Operating on Public Roads Operating an ATV on paved surfaces (including Operating this ATV on public streets, roads or sidewalks, paths, parking lots and driveways) highways could result in a collision with another may adversely affect the handling of the ATV and vehicle.
Page 25 Safety Safety Warnings Operating at Excessive Speeds Physical Control of the ATV Operating the ATV at excessive speeds Removing a hand from the handlebars or feet increases the operator's risk of losing control. from the footpegs during operation can reduce Always operate at a speed that's appropriate for your ability to control the vehicle or cause loss of the terrain, the visibility and operating conditions,...
Page 26 Safety Safety Warnings Turning Improperly Jumps and Stunts Turning improperly could cause loss of traction, Attempting wheelies, jumps and other stunts loss of control, accident or overturn. Always increases the risk of an accident or overturn. follow proper procedures for turning as described Never attempt wheelies, jumps, or other stunts.
Page 27 Safety Safety Warnings Improper Hill Climbing Operating on Steep Hills Improper hill climbing could cause loss of control Operating on excessively steep hills could cause or overturn. Always follow proper procedures for an overturn. Never operate on hills too steep for climbing hills as described in the owner's the ATV or for your abilities.
Page 28 Safety Safety Warnings Descending Hills Improperly Improperly descending a hill could cause loss of control or overturn. • Always follow proper procedures for traveling down hills as described in the owner's manual. NOTE: A special tech- nique is required when braking while traveling downhill. See page 75.
Page 29 Safety Safety Warnings Crossing Hillsides Driving on a sidehill is not recommended. Improper procedure could cause loss of control or overturn. Avoid crossing the side of any hill unless absolutely necessary. If crossing a hillside is unavoidable, always follow proper procedures as described in the owner's manual.
Page 30 Safety Safety Warnings Stalling While Climbing a Hill Stalling, rolling backwards or improperly dismounting while climbing a hill could cause an overturn. Always maintain a steady speed when climbing a hill. If all forward speed is lost Keep body weight uphill. Apply the front brakes gradually (right lever).
Page 31 Safety Safety Warnings Operating on Slippery Terrain Failure to use extra caution when operating on excessively rough, slippery or loose terrain could cause loss of traction, loss of control, accident or overturn. Do not operate on excessively rough, slippery or loose terrain until you've learned and practiced the skills necessary to control the ATV on such terrain.
Page 32 Safety Safety Warnings Operating in Unfamiliar Terrain Operating Improperly in Reverse Failure to use extra caution when operating on Improperly operating in reverse could result in a unfamiliar terrain could result in an accident or collision with an obstacle or person. Always overturn.
Page 33 POLARIS Industries Inc. or equivalent See page 79. components designed for use on this ATV and Skidding or Sliding...
Page 34 Safety Safety Warnings Operating Through Deep Water Operating the ATV through deep or fast-flowing water could cause the tires to float, causing loss of control or overturn. Avoid operating through deep or fast-flowing water. If it's unavoidable to enter water that exceeds the height of the footpegs: •...
Page 35 Safety Safety Warnings Poor Visibility Operating the ATV in darkness or inclement weather could result in a collision or accident, especially if operating on a road or street. This ATV is not equipped with highway-approved lights. Operate this vehicle off-road only. Use caution and drive at reduced speeds in conditions of reduced visibility such as fog, rain and darkness.
Page 36 Safety Safety Warnings Operating on Frozen Bodies of Water Operating a Damaged ATV Operating on frozen bodies of water may result in Operating a damaged ATV can result in an serious injury or death if the ATV and/or the accident. After any overturn or accident, have a operator fall through the ice.
Page 37 Safety Safety Warnings Hot Exhaust Systems Unauthorized Use of the ATV Exhaust system components are very hot during Leaving the keys in the ignition can lead to and after use of the vehicle. Hot components can unauthorized use of the vehicle, which could cause burns and fire.
Page 38 If an informational or graphic label becomes illegible or comes off, contact your POLARIS dealer to purchase a replacement. Replacement safety labels are provided Age 16 by POLARIS at no charge. The part Warning number is printed on the label.
Page 39 Safety Safety Labels and Locations General Warning WARNING ALWAYS: Improper ATV use can result in SEVERE • use proper riding techniques to avoid vehicle INJURY OR DEATH. overturns on hills and rough terrain and in turns Always use an approved helmet and protective gear.
Page 40 Safety Safety Labels and Locations Age 16 Warning Discretionary/Sport ATV Warning WARNING WARNING Operating this ATV if you are under the age of 16 • Never operate this ATV on HILLS steeper than ° increases your chance of severe injury or death. 25 degrees .
Page 41 Safety Safety Labels and Locations No Passenger Warning Tire Pressure/Load Warning WARNING WARNING NEVER ride as a passenger. Improper tire pressure or overloading can cause loss of control. Passengers can cause a loss of control, resulting in SEVERE INJURY or DEATH. Loss of control can result in severe injury or death.
Page 42 Features and Controls Engine Main Key Switch Stop Switch Start Button...
Page 43 Start Button Press the start button to engage the starter. Always release the start button promptly when the engine starts. If the starter fails to engage, replace the blown fuse or see your POLARIS dealer. Engine Stop Switch Move the stop switch either left or right to the OFF position to stop the engine quickly.
Page 44 • Hot engine • Reverse gear is selected • Neutral gear is selected If indicator lights fail to operate, check connections. See your POLARIS dealer for inspection of the capacitor and voltage regulator.
Page 45 Features and Controls Lights Headlights Use the headlight switch to turn the lights on and off and to switch the lights from high beam to low beam. The key must be in the ON position and the engine stop switch must be in the RUN position to operate the headlights.
Page 46 Features and Controls Clutch Lever The hydraulic clutch lever is located on the left handlebar. Squeeze the clutch lever toward the handlebar to disengage the clutch. Disengage the clutch before shifting gears. Adjusting Knob The clutch is self-adjusting, but lever position can be changed to fit the operator’s hand.
Page 47 Clutch Oil. Do not use brake fluid. Do not mix Boot clutch fluid with any other hydraulic fluids. See page 170 for the part numbers of POLARIS prod- ucts. 1. Position the vehicle on a level surface. 2. Turn the handlebar until the master cylinder is in a horizontal position.
Page 48 Features and Controls Throttle Lever WARNING Operating an ATV with sticking or improperly operating throttle controls could cause an accident. Never start or operate an ATV that has a sticking or improperly operating throttle. Always contact your dealer for service before operating the vehicle. Failure to check or maintain proper operation of the throttle system can result in an accident if the throttle lever sticks during operation.
Page 49 Features and Controls Throttle Lever The throttle lever is located on the right handlebar. Squeeze the lever toward the handlebar to increase engine speed and vehicle movement. Fuel is injected into the intake passage each time throttle is applied. Do not squeeze the throt- tle lever while starting the engine.
Page 50 Features and Controls Foot Brake The foot brake operates the rear brakes. The brake pedal is located in front of the right-hand footpeg. If the rear wheels slide while using the foot brake, reduce brake pedal pressure to brake the wheels without skidding. Check the brake fluid level frequently for the Foot Brake foot brake system.
Page 51 Features and Controls Hand Brake The hand brake operates the front brakes. The hand Hand Brake (Front Brake) brake is located on the right handlebar. These brakes are hydraulically activated disc type brakes. Squeeze the brake lever toward the handlebar to engage the front brakes.
Page 52 Features and Controls Master Cylinder/Brake Fluid WARNING An over-full master cylinder may cause brake drag or brake lock-up, which could result in an accident. Maintain brake fluid at the recommended level. Do not overfill. Never store or use a partial bottle of brake fluid. Brake fluid is hygroscopic, meaning it rapidly absorbs moisture from the air.
Page 53 Master Cylinder/Brake Fluid Check the brake fluid in the master cylinder before each ride. If the fluid level is low add DOT 4 brake fluid only. Do not overfill. See page 170 for the part numbers of POLARIS products. Hand Brake Fluid Level 1.
Page 54 Features and Controls Parking Brake 1. Place the transmission in first gear. 2. Squeeze and release the brake lever two or three times, then squeeze and hold. 3. Push the parking brake lock inward to engage the lock. Release the brake lever. 4.
Page 55 Features and Controls Parking Brake The parking brake may relax if left on for a long period of time. Always block the wheels to prevent rolling. Always block the wheels on the downhill side of the ATV if leaving it parked on a hill.
Page 56 Features and Controls Manual Shift Shift Pedal The gear shift pedal is located in front of the left-hand footpeg. One full stroke of the pedal shifts the transmission to the next gear in the shifting sequence. The pedal automatically returns to a horizontal position when released.
Page 57 Features and Controls Manual Shift Shifting Gears Always allow a cold engine to warm up 5. Release the brake lever. before shifting gears. 6. Gradually squeeze the throttle lever 1. When starting from a stopped position, while slowly releasing the clutch lever. place the transmission in neutral.
Page 58 Features and Controls Manual Shift Reverse Lock-Out Switch The reverse lock-out switch prevents the operator from shifting into reverse uninten- tionally. The switch must be manually unlocked before shifting into reverse gear. The lock will automatically re-engage when the transmission is shifted out of reverse gear.
Page 59 Features and Controls Manual Shift Deceleration To slow or stop the vehicle, release the throttle lever and apply the brakes smoothly and evenly. As the vehicle slows and engine RPM decreases, disengage the clutch and shift to a lower gear. Be sure the engine RPM has sufficiently decreased before shifting to a lower gear.
Page 60 Do not use fuel with ethanol content greater than 10 percent, such as E-85 fuel. Fuel Filters The fuel pick-ups have internal fuel filters. Do not attempt to clean the fuel filters. See your POLARIS dealer for service if you suspect the fuel filters are plugged.
Page 61 Features and Controls Fuel Valve The fuel valve is located on the right side of the Fuel Valve ATV. It has three positions: OFF: For vehicle storage and when transporting. Turn the fuel valve off whenever the vehicle is stored or parked. ON: For normal operation.
Page 62 Break-In Period The break-in period for your new POLARIS ATV is the first three hours of operation, or the time it takes to use 5-6 gallons (20 liters) of fuel. No single action on your part is as impor- tant as following the procedures for a proper break-in.
Page 63 Operation Break-In Period Perform the following break-in and maintenance procedures carefully. 1. Fill the fuel tank with gasoline. Always 5. Excessive heat build-up during the first exercise extreme caution whenever han- three hours of operation will damage dling gasoline. close-fitted engine parts. Do not allow engine speed to exceed 7000 RPM dur- 2.
Page 64 Operation Pre-Ride Inspection Failure to inspect and verify that the ATV is in safe operating condition before operating increases the risk of an accident. Always inspect the ATV before each use to make sure it's in safe operating condition. Pre-Ride Checklist Page Brake systems / lever travel Ensure proper operation...
Page 65 Inspect, clean, replace as needed Air box sediment tubes Drain deposits when visible Headlamp Check operation, apply POLARIS dielectric grease to the socket when the lamp is replaced Brake light / tail lamp Check operation, adjust brake light switch Riding gear...
Page 66 Operation Safe Operation Practices 1. Complete the recommended safety 6. Use caution and drive at reduced speeds training before operating this vehicle. in conditions of reduced visibility such See page 10. as fog, rain and darkness. Clean head- lights frequently and replace burned out 2.
Page 67 Operation Safe Operation Practices 8. Drive in a manner appropriate for your 12. Never operate a damaged ATV. After skills and operating conditions. Never any overturn or accident, have a quali- operate at excessive speeds. Never fied service dealer inspect the entire attempt wheelies, jumps, or other stunts.
Page 68 Familiarize yourself with all laws and regulations concerning the operation of this off-road vehicle in your area. Respect the environment in which you ride. Find out where the desig- nated riding areas are by contacting your POLARIS dealer, a local riding club or local offi- cials.
Page 69 Operation Trail Etiquette Always practice good etiquette when riding. Allow a safe distance between your vehicle and other vehicles operating in the same area. Communicate to oncoming operators by signaling the number of vehicles in your group. When stopping, move your vehicle to the edge of the trail as far as possible to allow others to pass safely.
Page 70 Operation Starting the Engine The engine can be started when the transmission is in neutral, or while in gear if the clutch is disengaged. If starting a warm engine, do not use the choke. Fuel is injected into the intake passage each time the throttle lever is depressed. Do not depress the throttle lever while starting the engine.
Page 71 Repeat until the engine starts. If the engine does not start, review the engine troubleshooting information beginning on page 172. If all conditions are favorable and the engine still does not start, see your POLARIS dealer for service.
Page 72 Operation Driving Procedure 1. Wear a helmet and eye protection. 2. Sit upright with both feet on the footpegs and both hands on the handlebars. 3. Start the engine and allow it to warm up. 4. Shift the transmission into gear. See page 52. 5.
Page 73 Operation Making Turns Your ATV is equipped with a solid rear axle, which drives both rear wheels equally at all times. The wheel on the outside of the turn travels a greater distance than the inside wheel when turning, and the inside tire slips traction slightly. To turn, steer in the direction of the turn, leaning your upper body to the inside of the turn while supporting your weight on the outer footpeg.
Page 74 Operation Driving on Slippery Surfaces Whenever riding on slippery surfaces such as wet trails or loose gravel, or during freezing weather, follow these precautions: 1. Slow down when entering slippery areas. 2. Maintain a high level of alertness, reading the trail and avoiding quick, sharp turns, which can cause skids.
Page 75 Operation Driving on Slippery Surfaces 4. Never apply the brakes during a skid. Correct a skid by turning the handlebars in the direction of the skid and shifting your body weight forward. Turn in Sideways direction of skid skid...
Page 76 Operation Driving Uphill Braking and handling are greatly affected when operating in hilly terrain. Improper procedure could cause loss of control or overturn. Whenever traveling uphill, follow these precautions: 1. Drive straight uphill. ° 2. Avoid steep hills (25 maximum). 3.
Page 77 Operation Driving Uphill 5. Keep both feet on the footpegs. 6. Shift body weight uphill. 7. Proceed at a steady rate of speed and throttle opening. Opening the throttle suddenly could cause the ATV to flip over backwards. 8. Never back down a hill. WARNING! Aggressively applying the foot brake when backing down a hill may cause rear tipover.
Page 78 Operation Driving on a Sidehill (Sidehilling) Driving on a sidehill is not recommended. Improper procedure could cause loss of control or overturn. Avoid crossing the side of any hill unless absolutely necessary. If crossing a sidehill is unavoidable, follow these precautions: 1.
Page 79 Operation Driving Downhill Whenever descending a hill, follow these precautions: ° 1. Avoid steep hills (25 maximum). 2. Shift body weight uphill. Transfer your weight to the rear of the vehicle. 3. Drive straight downhill. 4. Slow down. Excessive speed when trav- eling downhill can cause loss of control.
Page 80 Operation Turning Around on a Hill If the vehicle stalls while climbing a hill, never back it down the hill! Use the K-turn to turn around: 1. Keep your body weight uphill. 2. Pull in the clutch lever and apply the front and rear brakes. 3.
Page 81 Operation Turning Around on a Hill 7. With the front brakes applied, pull in the clutch lever. Use the brakes to slowly allow the vehicle to roll around to your right until it's pointing across the hill or slightly downward. 8.
Page 82 Operation Parking on a Hill or Incline Avoid parking on a hill or incline if pos- sible. If it's unavoidable, follow these precautions: 1. Turn the engine off. 2. Place the transmission in first gear. 3. Lock the parking brake. 4.
Page 83 Operation Driving Over Obstacles Follow these precautions when operating over obstacles: 1. Always check for obstacles before oper- ating in a new area. 2. Look ahead and learn to read the terrain. Be constantly alert for hazards such as logs, rocks and low hanging branches. 3.
Page 84 Operation Driving Through Water POLARIS does not recommend operating in water deeper than the height of the footpegs. Follow these procedures when operating through water: 1. Determine water depth and current before entering water. 2. Choose a crossing where the water level is lowest and where both banks have gradual inclines.
Page 85 Operation Driving Through Water NOTICE: Serious engine damage can result if the vehicle is not thoroughly inspected after operating in water deeper than the footpeg level. As soon as possible, perform the inspections and maintenance services outlined in the periodic maintenance chart beginning on page 85. Engine oil and all grease fittings need special attention.
Page 86 Operation Driving in Reverse Follow these precautions when operating in reverse: 1. Always check for obstacles or people behind the vehicle. 2. Always avoid backing downhill. 3. Back slowly. 4. Apply the brakes lightly for stopping. 5. Avoid turning at sharp angles. 6.
Page 87 Operation on Public Lands in the U.S.A. Your POLARIS vehicle has a spark arrestor that was tested and qualified to be in accordance with the USFS standard 5100-1c. Federal law requires that this spark arrestor be installed and functional when the vehicle is operated on public lands.
Page 88 The engine and related components must be main- tained at POLARIS specifications to achieve optimal performance. Engine idle speed is the only adjustment POLARIS recommends that the operator perform. Any other adjustments should be performed by an authorized POLARIS dealer.
Page 89 Inspect, clean, lubricate, adjust and replace parts as necessary. When inspection reveals the need for replacement parts, use genuine POLARIS parts available from your POLARIS dealer. Record maintenance and service in the Maintenance Log beginning on page 199.
Page 90 Maintenance Periodic Maintenance Chart The recommended service intervals are based on average riding conditions. Vehicles sub- jected to severe use must be inspected and serviced more frequently. Severe Use Definition • Frequent immersion in mud, water or sand • Racing or race-style high RPM use •...
Page 91 Periodic Maintenance Chart WARNING Improperly performing the procedures marked with a n could result in component failure and cause an accident, which may result in serious injury or death. Always have an authorized POLARIS dealer perform these services. Maintenance Chart Key Perform these operations more often under severe use.
Page 92 Maintenance Periodic Maintenance Chart Item Maintenance Interval Remarks (whichever comes first) Page Hours Calendar Fuel Used Brake systems/brake fluid Tires Wheels/lug nuts Frame fasteners Pre-ride Check each day before operating the Coolant vehicle. Make adjustments as needed. Fuel See the Pre-Ride Checklist. Engine oil Transmission oil Throttle...
Page 93 Check idle speed setting Engine mounting bolts Check torque Valve clearance Check; adjust Perform these procedures more often for vehicles subjected to severe use Emission-Related Service Have an authorized POLARIS dealer perform these services Use POLARIS Premium All Season Grease...
Page 94 Maintenance Periodic Maintenance Chart Item Maintenance Interval Remarks (whichever comes first) Page Hours Calendar Fuel Used in gallons (liters) Brake pad wear Monthly Inspect regularly Rear sprocket bolts Monthly Check torque Battery Monthly Check terminals; clean; test Air filter Weekly Inspect;...
Page 95 78 (300) See your POLARIS dealer Coolant strength 78 (300) Inspect strength seasonally Perform these procedures more often for vehicles subjected to severe use Emission-Related Service Have an authorized POLARIS dealer perform these services Use POLARIS Premium All Season Grease...
Page 96 Maintenance Periodic Maintenance Chart Item Maintenance Interval Remarks (whichever comes first) Hours Calendar Fuel Used in gallons (liters) Upper steering post (1) Inspect; tighten fasteners; grease after wash- ing ATV/driving in water Front A-Arms (2) Inspect; tighten fasteners; grease (also after washing ATV or driving in water) Stabilizer Bar (3) Grease...
Page 97 Inspect; measure; replace as needed Piston pin circlip groove 156 (600) Visual inspection for wear Perform these procedures more often for vehicles subjected to severe use Emission-Related Service Have an authorized POLARIS dealer perform these services Use POLARIS Premium All Season Grease...
Page 98 Maintenance Periodic Maintenance Chart Item Maintenance Interval Remarks (whichever comes first) Hours Calendar Fuel Used in gallons (liters) Compression ring 156 (600) See your dealer or refer to the Dealer Service Manual; measure ring gap and replace if at or Oil scraper ring 156 (600) below service limit...
Page 99 Inspect periodically; adjust when parts are replaced Headlight aim As required Adjust as needed Perform these procedures more often for vehicles subjected to severe use Emission-Related Service Have an authorized POLARIS dealer perform these services Use POLARIS Premium All Season Grease...
Page 100 ATV and motorcycle applications. Do not use POLARIS PS-4 Performance Synthetic 10W-40 Oil. Always use 2W-50. See page 170 for the part numbers of POLARIS products. NOTICE: Mixing brands or using a non-recommended oil may cause serious engine damage. Always use the recommended oil.
Page 101 Maintenance Engine Oil Level Sight Glass Check the oil level before each use of the vehicle. If the engine is cold, the oil level should be visible at the lower edge of the sight glass. If the engine is warm, the oil level should be visible at the center of the sight glass.
Page 102 Maintenance Engine Oil Change Always change the oil at the intervals outlined in the Periodic Maintenance Chart beginning on page 85. Change the oil more frequently on vehicles subjected to severe use. IMPORTANT: Perform the initial break-in oil change after the first three hours of operation. Always change both oil filters and clean the oil screens whenever changing oil.
Page 103 Maintenance Engine Oil Change 1. Position the vehicle on a level surface. 2. Remove the skid plate for better access to the oil drain plug and short screen. 3. Start the engine. Allow it to idle for two to three minutes.
Page 104 Maintenance Engine Oil Change Cleaning the Short Oil Screen Short Oil Screen Plug Front Short Screen O-Rings View from bottom of vehicle...
Page 105 Maintenance Engine Oil Change Cleaning the Short Oil Screen 1. Remove the short oil screen plug at the bottom of the engine. See illustration on preceding page. 2. Remove the short oil screen from the plug. Clean the screen components thoroughly and blow well with compressed air.
Page 106 Maintenance Engine Oil Change Cleaning the Long Oil Screen 1. Remove the long screen plug, located on the side of the engine near the engine number. 2. Remove the oil screen. Clean the screen thoroughly and blow with compressed Plug air.
Page 107 Maintenance Engine Oil Change Cleaning the Long Oil Screen 5. Insert the tool through the opening and into the bore of the opposite engine casing wall. Push the oil screen into the casing as far as possible. Remove the tool. NOTICE: An improperly installed oil screen will function poorly and result in increased engine wear.
Page 108 Maintenance Engine Oil Change Changing Oil Filters 1. Place a drain pan under the engine. 2. Remove the four oil filter cover screws (1). Remove the covers. 3. Using circle clip (snap ring) pliers, pull the oil filter inserts (2) out of the housing. 4.
Page 109 Maintenance Engine Oil Change Changing Oil Filters 6. Grease the filter cover O-rings (3). 7. Reinstall the covers and the screws. Tighten screws to 4.5 ft. lbs. (6 Nm). 8. Remove the oil fill plug (4). Add 1.7 qts. (1.6 l) of the recommended engine oil (see page 96).
Page 110 Always follow the manufacturer's mixing recommendations for the freeze protection required in your area. POLARIS Premium 60/40 is already premixed and ready to use. Do not dilute with water. See page 170 for the part numbers of POLARIS products.
Page 111 Maintenance Engine Cooling System Coolant Level The recovery bottle is located on the right side of the vehicle under the front fender. If the fluid level is vis- ible at the bottom of the side panel, add 6 oz. (175 ml) of coolant.
Page 112 Maintenance Engine Cooling System Radiator Coolant Level Pressure Cap If the recovery bottle has run dry, inspect the level in the radiator and add coolant if necessary. The radiator pressure cap is located on the left side of the vehicle. CAUTION! Escaping steam can cause burns.
Page 113 Maintenance Engine Cooling System Cooling System Bleeding Bleeding the cooling system is required only if the system has been drained for maintenance and/or repair. Always allow the engine to cool sufficiently before removing the radiator pres- sure cap. 1. Remove the pressure cap. 2.
Page 114 Maintenance Air Filter Systems Refer to the illustrations on page 111. 1. Remove the seat. 2. Release the airbox cover clips and remove the cover. 3. Loosen the filter clamp. Remove the air filter from the box. 4. Locate the retaining spring. 5.
Page 115 Maintenance Air Filter Systems Step 3 Step 4 Step 5 Step 6 Step 7...
Page 116 3. Start the engine and allow it to idle for five min- utes, or until operating temperature is reached. 4. Turn the idle adjusting wheel (1) until idle speed reaches 1500-1600 RPM. 5. If idle speed is unsatisfactory after performing this procedure, see your POLARIS dealer for information about jetting changes.
Page 117 Maintenance Carburetor Carburetor Draining Drain the carburetor float bowl at the intervals outlined in the Periodic Maintenance Chart beginning on page 85. Always drain the bowl after exposure to wet conditions. Perform this procedure when the engine is cool. 1. Turn the fuel valve off. 2.
Page 118 Maintenance Carburetor Jetting Carburetor re-jetting can be performed to compensate for altitude and/or temperature changes. If the vehicle is to be operated at various altitudes and temperatures, certain adjust- ments can be made to improve its operation and driveability. Above 6000 feet (1800 m) the engine air/fuel mixture becomes overly rich.
Page 119 Maintenance Lights Headlight Adjustment 1. Position the vehicle on a level surface with the headlight approximately 25 ft. (7.6 m) from a flat wall. 2. Measure the distance from the floor to the center of the headlight and make a mark on the wall at the same height.
Page 120 Maintenance Lights 4. Observe the headlight aim on the wall. The most intense part of the headlight beam should be aimed 2" (5 cm) below the mark placed on the wall. Include rider weight on the seat when measuring. 5. Loosen the pivot screw and adjust the beam to the desired position.
Page 121 Maintenance Lights Headlight Lamp Replacement When servicing a halogen lamp, avoid touching the lamp with bare fingers. Oil from your skin leaves a residue, causing a hot spot that will shorten the life of the lamp. If fingers do touch a lamp, clean it with denatured alcohol. 1.
Page 122 Maintenance Lights Headlight Assembly Replacement 1. Remove the front cover. 2. Remove the wire harness connector from the headlights. 3. Remove the two retaining brackets and the adjuster screw. 4. Remove the headlamp. 5. Install the new headlamp, placing it in the slots on the frame tabs. Secure the headlamp with the retaining brackets.
Page 123 Maintenance Lights Brake Light Adjustment Check the rear brake light for proper operation before Switch each use of the vehicle. Body 1. Turn the ignition key on. 2. Lightly apply and release the foot brake several times. Adjustment A properly operating rear brake light will immedi- ately flash on and off with each movement of the brake pedal.
Page 124 Maintenance Front Cab/Side Panel Removal Front Cover The front cab and side panel assembly is removed in one Screws piece. 1. Remove the seat. 2. Remove the two front cover screws and remove the front cover. 3. Remove the eight side panel screws (four on each side). 4.
Page 125 Maintenance Rear Cab Removal 1. Unlatch and remove the seat. 2. Remove the two lower bolts (1) on the rear fenders of the cab. 3. Remove the two bolts and grommets (2) on the top of the cab. 4. Remove the two bolts (3) at the rear cab-to-front-cab joint.
Page 126 Refer to the specifications section beginning on page 168 for recommended spark plug type and gap NOTICE: Using non-recommended spark plugs can result in serious engine damage. Always use POLARIS-recommended spark plugs. Spark plug condition is indicative of engine operation. The Spark...
Page 127 Maintenance Spark Plugs Normal Plug The normal insulator tip is gray, tan or light brown. There will be few combustion deposits. The electrodes are not burned or eroded. This indicates the proper type and heat range for the engine and the service. The tip should not be white.
Page 128 Maintenance Spark Arrestor Clean-Out WARNING Failure to heed the following warnings while servicing the spark arrestor could result in serious injury or death. The exhaust system can get extremely hot. Do not perform service on the spark arrestor while the system is hot. Allow components to cool sufficiently before proceeding. Remove any combustible materials from the area.
Page 129 Maintenance Spark Arrestor Clean-Out To remove accumulated carbon, clean the spark Reducer arrestor at the intervals recommended in the Peri- odic Maintenance Chart beginning on page 85. Screen 1. Remove the retaining screw and remove the Muffler screen from the end of the muffler. 2.
Page 130 Maintenance Vehicle Immersion If the vehicle tips or overturns in water deeper than the footpeg level, or if the engine stops during or after operating in water, restarting WILL result in serious engine damage. Trans- port the vehicle to your dealer for service before restarting the engine. If this is not possible, follow the vehicle immersion inspection and drying procedures outlined below.
Page 131 Maintenance Vehicle Immersion 1. Turn the fuel valve off. 2. Drain water from the air box and clean the air filter. See page 110. 3. Drain the carburetor bowl. See page 113. 4. Remove the spark plug. See page 122. WARNING! Fluids will be ejected through the spark plug hole and may cause serious injury to face or other body parts.
Page 132 Maintenance Vehicle Immersion 6. Press and hold the starter button for 10 second intervals for about one minute or until water vapor is no longer ejecting from the spark plug hole. 7. Check the oil level. If the level is higher than the pre-ride inspection level, water has entered the crankcase.
Page 133 Maintenance Battery WARNING Improperly connecting or disconnecting battery cables can result in an explosion and cause serious injury or death. When removing the battery, always disconnect the negative (black) cable first. When reinstalling the battery, always connect the negative (black) cable last. The sealed battery is already filled with electrolyte and has been sealed and fully charged at the factory.
Page 134 Maintenance Battery Storage Whenever the vehicle is not used for a period of three months or more, remove the battery from the vehicle, ensure that it's fully charged, and store it out of the sun in a cool, dry place. Check battery voltage each month during storage and recharge as needed to maintain a full charge.
Page 135 Maintenance Battery Installation Always install a fully charged battery. Using a new battery that has not been fully charged can damage the battery and result in a shorter life. It can also hinder vehicle performance. If recharging is necessary, use a .5 amp battery charger. 1.
Page 136 Maintenance Battery Charging (Sealed Battery) On a sealed battery, the sealing strip cannot be removed. Use a voltmeter or multimeter to measure DC voltage. A fully charged battery will register 12.8 V or higher. If the voltage is less than 12.8 volts, recharge the battery. WARNING! An overheated battery could explode, causing severe injury or death.
Page 137 See your POLARIS dealer for inspection of the voltage regulator and generator. When using an automatic charger such as the POLARIS Battery Tender, refer to the manu- facturer's instructions for recharging. When using a constant current charger, use the guide-...
Page 138 Maintenance Battery Charging (Sealed Battery) Always verify battery condition before and 1-2 hours after the end of charging. Charge Time State of Voltage Action (Using constant current Charge charger @ standard amps specified on top of battery) 100% 12.8-13.0 volts None, check at 3 months from None required date of manufacture...
Page 139 Maintenance Tires WARNING Operating your ATV with worn tires, improperly inflated tires, non-standard tires or improperly installed tires will affect vehicle handling and could cause an accident resulting in serious injury or death. Always follow all tire maintenance procedures as outlined in this manual and on the labels on the vehicle. Always use original equipment size and type when replacing tires.
Page 140 Wheel Hub Tightening Front wheel bearing tightness and spindle nut retention are critical component operations. All service must be performed by your authorized POLARIS dealer. Wheel Removal 1. Stop the engine. Place the transmission in gear. Lock the parking brake.
Page 141 Maintenance Wheel Installation 1. Place the transmission in gear. Lock the parking brake. 2. Place the wheel on the wheel hub with the valve stem toward the outside and rotation arrow on the tire pointing toward forward rotation. 3. Install the wheel bolts and finger tighten them. 4.
Page 142 Boot Inspection Before Operating Inspect the boots before operating the vehicle. If a boot is torn, punctured or leaking fluid, see your POLARIS dealer for service or replacement. After Operating Inspect the boots after operating the vehicle. If a boot is bulging or ballooned, perform the boot burping procedure on page 139.
Page 143 Maintenance Boot Burping 1. Using a needle nose pliers or boot clamp removal tool, remove the small boot clamp (1) from the inboard boot. Do not use any tools that may damage the boot. 2. Slide the free end of the boot two inches toward the center of the vehicle and lift the boot away from the shaft to allow excess air to escape (2).
Page 144 Maintenance Clutch System Bleeding Always bleed the clutch system at the intervals out- lined in the Periodic Maintenance Chart beginning on page 85. Always bleed the clutch system any time the clutch lever feels unresponsive. Always use the recommended fluid when bleeding the clutch system.
Page 145 Maintenance Clutch System Bleeding 4. Remove the bleeder screw (2) from the slave cylinder. 5. Press fluid into the system until the fluid runs out of the hole (3) in the master cylinder without producing bubbles. TIP: Extract fluid from the master cylinder during the process to prevent overflowing. 6.
Page 146 Maintenance Throttle Lever Freeplay Periodically check throttle lever freeplay. Maintain freeplay between 1/16" and 1/8" (1.5 - 3 mm). If adjustments are needed, use the procedure on page 143. " 1/16 - 1/8" (1.5 - 3 mm)
Page 147 Improper adjustment of throttle cable freeplay can result in loss of control, which could result in serious injury or death. POLARIS recommends that this procedure be performed by a POLARIS dealer to ensure that it's done correctly. Mechanically knowledgeable persons who perform this procedure must follow the adjustment procedures exactly.
Page 148 Maintenance Brakes Under normal operation, the diaphragm extends into the reservoir as fluid level drops. If the fluid level is low and the diaphragm is not extended, a leak is likely and the diaphragm should be replaced. To ensure proper diaphragm operation, always fill the reservoir as needed whenever the cover is loosened or removed.
Page 149 Maintenance Brakes 1. Always maintain brake fluid at the recommended level. See pages 48-49. 2. Check the brake system for fluid leaks. 3. Check the brakes for excessive travel or spongy feel. 4. Check the friction pads for wear, damage and looseness. 5.
Page 150 WARNING! Severe injury or death can result from improper toe alignment and adjustment. Do not attempt to adjust tie rod alignment. All tie rod adjustments should be performed by an authorized POLARIS dealer. 1. Position the vehicle on a level surface. Ensure the vehicle is at the proper ride height by placing a rider on the vehicle.
Page 151 8. The recommended toe alignment is 0" to 1/16" (0-1.6 mm) toe out. This means that the front measurement should be 0" to 1/16" (0-1.5 mm) greater than the rear mea- surement. 9. If you discover improper alignment, see your POLARIS dealer for service.
Page 152 Maintenance Chain Tension CAUTION! Never adjust or operate the vehicle with the rear drive chain too loose or too tight. Severe damage to the transmission and drive components can result. Check the amount of chain slack by moving the vehicle slightly forward to remove slack at the top side of the chain.
Page 153 Maintenance Chain Tension 3. Tighten the pivot mounting bolts to 30 ft. lbs. (40 Nm). 4. Torque the chain adjusting bolt to 17 ft. lbs. (23 Nm). 5. Check sprocket bolts to make sure the retainer tabs fit tightly against the bolt heads.
Page 154 Improper adjustment of the handlebars or incorrect torquing of the adjuster block tightening bolts can cause limited steering or loosening of the handlebars, resulting in loss of control. Follow the adjustment procedures exactly, or see your POLARIS dealer for service. The handlebars can be adjusted for rider preference.
Page 155 Steering Inspection Check the steering assembly periodically for loose nuts and bolts. If loose nuts and bolts are found, or if you notice any freeplay in the steering post, see your POLARIS dealer for ser- vice before operating the vehicle.
Page 156 Maintenance Front Suspension Suspension Set-Up 1. Position the vehicle on a level surface. 2. Stop the engine. 3. Elevate the front of the vehicle by placing a suitable stand under the frame. The tires should be barely touching the ground and the suspension should be at full rebound.
Page 157 Maintenance Front Suspension Suspension Set-Up 6. Place the transmission in neutral and slowly roll the machine forward and rearward at least ten feet (3 m) without lifting or pushing down on the suspension. 7. Turn the handlebars fully to the left and right. 8.
Page 158 WARNING! Uneven adjustment may cause poor handling of the ATV, which could result in an accident and serious injury or death. Always adjust both the left and right spring preloads equally or have your POLARIS dealer perform the adjustments.
Page 159 Maintenance Front Suspension Spring Preload Adjusting Ring Jam Nut 1. Raise and safely support the front of the vehicle (lower) (upper) off the ground to allow the suspension to fully extend. 2. Loosen the jam nut. 3. Turn the adjusting ring clockwise to increase preload.
Page 160 Maintenance Rear Suspension Suspension Set-Up 1. Position the vehicle on a level surface. 2. Stop the engine. 3. Elevate the rear of the vehicle by placing a suitable stand under the frame. The tires should be barely touching the ground and the suspension should be at full rebound.
Page 161 Maintenance Rear Suspension Suspension Set-Up 5. Remove the stand and have a rider sit comfortably on the seat with hands on the handle- bars. 6. Place the transmission in neutral and slowly roll the machine forward and rearward at least ten feet (3 m) without lifting or pushing down on the suspension. 7.
Page 162 Maintenance Rear Suspension The rear suspension spring preload and shock compression Adjusting damping may be adjusted to suit different riding conditions Ring Jam Nut and operator weight. (lower) (upper) Spring Preload 1. Raise and safely support the rear of the vehicle off the ground to allow the suspension to fully extend.
Page 163 Maintenance Rear Suspension Compression Damping The compression damping clickers are located on the Compression bottom of the shocks (on the lower clevis). Use a Adjustment screwdriver to make adjustments. To set the shock at the firmest setting, turn the screw clockwise until it stops (fully closed position).
Page 164 Do not allow these types of products to contact the vehicle. Washing the Vehicle The best and safest way to clean your POLARIS vehicle is with a garden hose and a pail of mild soap and water. 1. Use a professional-type washing cloth, cleaning the upper body first and the lower parts last.
Page 165 Maintenance Cleaning Washing the Vehicle Washing Tips • Avoid the use of harsh cleaners, which can scratch the finish. • Do not use a power washer to clean the vehicle. • Do not use medium to heavy duty compounds on the finish. •...
Page 166 If a high pressure water system is used for cleaning (not recommended), exercise extreme caution. The water may damage components and could remove paint and decals. If warning and safety labels are damaged, contact your POLARIS dealer for free replacement. Avoid directing the water stream at the following items: •...
Page 167 Maintenance Polishing POLARIS recommends the use of common household aerosol furniture polish for polishing the finish on your POLARIS vehicle. Follow the instructions on the container. Polishing Tips • Avoid the use of automotive products, some of which can scratch the finish of your vehi- cle.
Page 168 Maintenance Storage Engine Oil Change the oil and both filters. Clean the oil screens. See page 98. Air Filter / Air Box Inspect and clean (or replace) the air filter. Clean the air box. Drain the sediment tube. Fluid Levels Inspect fluid levels.
Page 169 Stabilize the Fuel 1. Fill the fuel tank with fuel. 2. Add POLARIS Carbon Clean Fuel Treatment or POLARIS Fuel Stabilizer. Follow the instructions on the container for the recommended amount. Carbon Clean removes water from fuel systems, stabilizes fuel and removes carbon deposits from pistons, rings, valves and exhaust systems.
Page 170 Maintenance Storage Lubricate Inspect all cables and lubricate all areas of the vehicle as recommended in the Periodic Main- tenance Chart beginning on page 85. Storage Area/Covers 1. Make sure tire pressure is at specification. 2. Be sure the storage area is well ventilated. 3.
Page 171 Maintenance Transporting the ATV Follow these procedures when transporting the vehicle. 1. Stop the engine. 2. Place the transmission in first gear. 3. Lock the parking brake. 4. Remove the key to prevent loss during transporting. 5. Secure the fuel cap, oil cap and seat. 6.
Page 172 Specifications OUTLAW 525 IRS Max. Weight Capacity 215 lbs./97.5 kg Pilot Jet Dry Weight 389 lbs./176 kg Main Jet Fuel Capacity 3.1 gal./11.7 l Needle Jet OBDVS Overall Length 71.5 in./182 cm Needle Clip Overall Width 47.5 in./121 cm Slow Air Jet Overall Height 45 in./114 cm Alternator Output...
Page 173 Specifications OUTLAW 525 IRS Driving System Type Rear Two-Wheel Drive Tire Size - Front 21 x 7R10 Shift Type 5-Speed Manual Shift Tire Size - Rear 20 x 10R10 Primary Ratio 2.516 Tire Pressure - All 4 psi/27.6 KPa Gear Ratio - 1st 2.500 Front Brake Hydraulic Disc, Dual Bore...
Page 174 POLARIS Products Part Number Description Engine Lubricant 2876244 PS-4 PLUS Performance Synthetic 2W-50 4-Cycle Oil (qt.) 2876245 PS-4 PLUS Performance Synthetic 2W-50 4-Cycle Oil (gal.) Grease / Specialized Lubricants 2871312 Grease Gun Kit, Premium All Season (3 oz.) 2871322 Premium All Season Grease (3 oz. cartridge) 2871423 Premium All Season Grease (14 oz.
Page 175 POLARIS Products Part Number Description Coolant 2871323 60/40 Coolant (gal.) 2871534 60/40 Coolant (qt.) Additives / Miscellaneous 2871326 Carbon Clean Plus (12 oz.) 2870652 Fuel Stabilizer (16 oz.) 2872189 DOT4 Brake Fluid (12 oz.) 2876335 Hydraulic Clutch Oil (qt.)
Page 176 Troubleshooting See your POLARIS dealer if you're unable to identify solutions using the following charts. Engine Turns Over, Fails to Start Possible Cause Solution Out of fuel Turn the fuel valve to reserve, refuel Water is present in carburetor or fuel supply...
Page 177 Possible Cause Solution No spark to spark plug Inspect, clean and/or replace spark plugs See your POLARIS dealer Overuse of choke/flooded engine Engage starter 2 times for 5 seconds each, then restart. If engine fails to start, inspect, clean and/or replace spark plugs.
Page 178 Troubleshooting Engine Doesn’t Turn Over Possible Cause Solution Fuseable link See POLARIS dealer for replacement Low battery voltage Recharge battery to 12.8 VDC Loose battery connections Check all connections and tighten Loose solenoid connections Check all connections and tighten Engine Pings or Knocks...
Page 179 Set gap to specs or replace plugs Old or non-recommended fuel Replace with new fuel Exhaust leak Inspect system for leaks; see your POLARIS dealer Incorrectly installed spark plug wire See your POLARIS dealer Incorrect ignition timing See your POLARIS dealer...
Page 180 Solution Fouled or defective spark plug Inspect, clean and/or replace spark plug Worn or defective spark plug wire See your POLARIS dealer Incorrect spark plug gap or heat range Set gap to specs or replace plug Loose ignition connections Check all connections and tighten...
Page 181 Inspect and clean or replace Electronic throttle control malfunction See your POLARIS dealer Incorrect idle adjustment Adjust idle speed or see your POLARIS dealer Clogged idle jet Disassemble carburetor and clean the jets Other mechanical failure See your POLARIS dealer...
Page 182 Add or change fuel, clean the fuel system Low octane fuel Replace with recommended fuel Old or non-recommended fuel Replace with recommended fuel Clogged fuel valve screen See your POLARIS dealer Incorrect jetting See your POLARIS dealer Possible Rich Fuel Mixture Cause Solution Overuse of choke...
Page 183 Solution Worn or dirty needle valve Clean and/or replace needle valve Loose carburetor jets Tighten jets Faulty ignition timing See your POLARIS dealer Engine Uses Excessive Oil Possible Cause Solution Bent engine ventilation hose Install a new hose Excessive oil in system...
Page 184 Clean fuel system and carburetor Clogged, dirty or wet air filter Inspect and clean or replace Electronic throttle control malfunction See your POLARIS dealer Other mechanical failure See your POLARIS dealer Overheated engine Clean radiator screen and core if equipped...
Page 185 Inspect, clean and/or replace spark plugs Fouled or defective spark plug Inspect, clean and/or replace spark plugs Worn or defective spark plug wire See your POLARIS dealer Incorrect spark plug gap or heat range Set gap to specs or replace plugs Loose ignition connections...
Page 186 Drain and replace coolant with recommended coolant Bent cooling hose Shorten or replace hose Defective thermostat or thermoswitch See your POLARIS dealer Blown fan fuse or defective fan Replace fuse and check fan for proper operation or see your POLARIS dealer...
Page 187 Replace the float Clogged, dirty or wet air filter Inspect and clean or replace Faulty exhaust system Check system for damage; see your POLARIS dealer Valve gap is too small Adjust valve gap Faulty ignition timing See your POLARIS dealer...
Page 188 2100 Hwy 55, Medina, MN 55340 U.S.A. Telephone 763-542-0500 April 22, 2010 We, POLARIS Industries Inc., declare that the vehicles listed below conform to the essential health and safety requirements applicable to off-road all-terrain vehicles. APPLICABLE EUROPEAN DIRECTIVES TEST / EVALUATION METHODS...
Page 189 Declaration of Conformity PRODUCT IDENTIFICATION VEHICLE SERIES TRADE NAME MODEL YEARS ___BA50__, ___BG50__ SCRAMBLER 500 2008, 2009, 2010, 2011 ___GJ45__ OUTLAW 450 2008, 2009, 2010, 2011 ___GJ52__, ___GP52__ OUTLAW 525 / 525 S 2008, 2009, 2010, 2011 ___LH46__ SPORTSMAN 400 2008, 2009, 2010, 2011 ___MH50__ SPORTSMAN 500 HO...
Page 190 Authorized to Compile the Technical File: Empowered to Draw up the EC Declaration of Conformity: Ross Clifford, General Manager Lawrence E. Keller, Product Compliance POLARIS Britain Ltd Manager Forge Mills Park, Station Road 7290 East Viking Blvd. Coleshill, Warwickshire B46 1HT...
Page 191 REGISTRATION At the time of sale, the Warranty Registration Form must be completed by your dealer and submitted to POLARIS within ten days. Upon receipt of this registration, POLARIS will record the registration for warranty. No verification of registration will be sent to the purchaser as the copy of the Warranty Registration Form will be the warranty entitlement.
Page 192 LIMITATIONS OF WARRANTIES AND REMEDIES The POLARIS limited warranty excludes any failures that are not caused by a defect in material or workmanship. This warranty does not cover accidental damage, normal wear and tear, abuse or improper handling. This warranty also does not cover any...
Page 193 Warranty WARRANTY COVERAGE AND EXCLUSIONS: LIMITATIONS OF WARRANTIES AND REMEDIES Warranty applies to the product only and does not allow for coverage of personal loss. Some items are considered "consum- able," meaning they are considered part of normal maintenance or part of completing an effective repair. The following items are excluded from warranty coverage in the event of a warranty claim: •...
Page 194 Warranty WARRANTY COVERAGE AND EXCLUSIONS: LIMITATIONS OF WARRANTIES AND REMEDIES This warranty also excludes failures resulting from improper lubrication; improper engine timing; improper fuel; surface imper- fections caused by external stress, heat, cold or contamination; operator error or abuse; improper component alignment, tension, adjustment or altitude compensation;...
Page 195 This warranty does not cover the use of unauthorized lubricants, chemicals, or fuels that are not compatible with the ATV. The exclusive remedy for breach of this warranty shall be, at POLARIS' exclusive option, repair or replacement of any defective materials, or components or products.
Page 196 HOW TO OBTAIN WARRANTY SERVICE If your ATV requires warranty service, you must take it to a POLARIS dealer authorized to repair POLARIS ATVs. When requesting warranty service you must present your copy of the Warranty Registration form to the dealer. (THE COST OF TRANSPORTATION TO AND FROM THE DEALER IS YOUR RESPONSIBILITY).
Page 197 In the country where your vehicle was purchased: Warranty or Service Bulletin repairs must be done by an authorized POLARIS dealer. If you move or are traveling within the country where your vehicle was purchased, Warranty or Service Bulletin repairs may be requested from any authorized POLARIS dealer who sells the same line as your vehicle.
Page 198 If Purchased From A Private Party: If you purchase a POLARIS product from a private citizen outside of the country in which the vehicle was originally purchased, all warranty coverage will be denied. You must nonetheless warranty register your vehicle under your name and address with a local POLARIS dealer in your country to ensure that you receive safety information and notices regarding your vehicle.
Page 199 U.S.A. EPA Emissions Limited Warranty This emissions limited warranty is in addition to the POLARIS standard limited warranty for your vehicle. POLARIS Industries Inc. warrants that at the time it is first purchased, this emissions-certified vehicle is designed, built and equipped so it conforms with applicable U.S.
Page 200 Warranty U.S.A. EPA Emissions Limited Warranty For exhaust emissions, emission-related components include any engine parts related to the following systems: • Air-induction system • Ignition system • Fuel system • Exhaust gas recirculation systems The following parts are also considered emission-related components for exhaust emissions: •...
Page 201 U.S.A. EPA Emissions Limited Warranty The exclusive remedy for breach of this limited warranty shall be, at the exclusive option of POLARIS, repair or replacement of any defective materials, components or products. THE REMEDIES SET FORTH IN THIS LIMITED WARRANTY ARE THE ONLY REMEDIES AVAILABLE TO ANY PERSON FOR BREACH OF THIS WARRANTY.
Page 202 POLARIS recommends that you contact an authorized POLARIS dealer to perform any service that may be necessary for your vehicle. POLARIS also recommends that you use only Pure POLARIS parts. It is a potential violation of the Clean Air Act if a part supplied by an aftermarket parts manufacturer reduces the effectiveness of the vehicle's emission controls.
Page 203 Maintenance Log Present this section of your manual to your dealer each time your vehicle is serviced. This will provide you and future owners with an accurate log of maintenance and services performed. DATE SERVICE TECHNICIAN SERVICE PERFORMED / COMMENTS INTERVAL (HOURS) 3 Hours...
Page 204 Maintenance Log DATE SERVICE TECHNICIAN SERVICE PERFORMED / COMMENTS INTERVAL (HOURS)
Page 205 Maintenance Log DATE SERVICE TECHNICIAN SERVICE PERFORMED / COMMENTS INTERVAL (HOURS)
Page 206 Maintenance Log DATE SERVICE TECHNICIAN SERVICE PERFORMED / COMMENTS INTERVAL (HOURS)
Page 207 Index Age Restrictions ....15 Cab Removal, Front ... 120 Deceleration ....55 Air Filter Systems .
Page 208 Index Fluid Headlight Adjustment ..115 Lights ... . 40-41, 115-119 Brake ....48-49 Headlight Assembly .
Page 209 Age Restrictions ... . 15 Operating Over Obstacles ..29 Polaris Products ... . . 170 Carrying a Passenger ..19 Operating Through Deep Water 30 Polishing .
Page 210 Index Side Panel Removal ... 120 Switches Vehicle Identification Numbers ..8 Sidehilling ....74 Engine Stop Switch .

Polaris OUTLAW 525 IRS 2011 Owner's Manual For Maintenance And Safety

Quick Links

Need help?

Questions and answers

Related Manuals for Polaris OUTLAW 525 IRS 2011

Summary of Contents for Polaris OUTLAW 525 IRS 2011
