Model 138A02
Tourmaline ICP® underwater blast sensor, 4.71" length, 1000 psi, 5 mV/psi
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: 716-684-0987
E-mail: info@pcb.com
Web: www.pcb.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Amphenol PCB PIEZOTRONICS 138 Series
Summary of Contents for Amphenol PCB PIEZOTRONICS 138 Series
- Page 1 Model 138A02 Tourmaline ICP® underwater blast sensor, 4.71" length, 1000 psi, 5 mV/psi Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
- Page 2 Repair and Maintenance Returning Equipment If factory repair is required, our representatives will PCB guarantees Total Customer Satisfaction through its provide you with a Return Material Authorization (RMA) “Lifetime Warranty Plus” on all Platinum Stock Products number, which we use to reference any information you sold by PCB and through its limited warranties on all other have already provided and expedite the repair process.
- Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
- Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
- Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
- Page 6 OPERATION MANUAL FOR Series 138 Series 138 Standard Length, with Lead Wire Hole for Attaching Weights Series 138 Short Length, One-Piece Molded Closed-End Tube INTRODUCTION Series 138 is used by the military for underwater PCB Series 138 sensors are voltage mode tourmaline explosive testing, commercial use in gasoline tanks sensors designed for operation underwater or in and transformer shock wave applications.
- Page 7 OPERATION MANUAL FOR Series 138 PCB Model 070A03 adaptor can be used to adapt the Some models of the Series 138 feature a tygon tube 10-32 micro jack on the 138 to a BNC jack. A heavier closed at one end with conical-shaped delrin plug. The coaxial cable (eg.
- Page 8 OPERATION MANUAL FOR Series 138 If indicator is in green section of indicator panel, the The steel wire can have a weight attached to it to IC amplifier is producing proper bias (+8 to 14 VDC), submerge the entire assembly. Tape or attach the cable connections are normal and the system is ready coaxial cable loosely to the steel wire at ~one foot to operate.
- Page 9 OPERATION MANUAL FOR Series 138 MAINTENANCE Observe the following precautions when using the sensor: Keep connections clean and dry. 2.) Do not exceed specified maximum range. 3.) Do not subject sensor to temperatures exceeding 100 °F. 4.) Do not apply voltage to sensor without current- limiting diodes or other current protection.
- Page 10 Model Number Revision: F ICP® PRESSURE SENSOR 138A02 ECN #: 55416 OPTION AL VERSION S Performance EN GLISH Optional versions have identical specifications and accessories as listed for the standard model except Measurement Range(for ±5V output) 1,000 psi 6,895 kPa where noted below.
