Model M118A02
Hydraulic pressure sensor, 20k psi, 0.10 pC/psi (long life integral machined diaphragm) M10
threads
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: 716-684-0987
E-mail: info@pcb.com
Web: www.pcb.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amphenol PCB Piezotronics 118 Series
Summary of Contents for Amphenol PCB Piezotronics 118 Series
- Page 1 Model M118A02 Hydraulic pressure sensor, 20k psi, 0.10 pC/psi (long life integral machined diaphragm) M10 threads Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com Web: www.pcb.com...
-
Page 2: Repair And Maintenance
Repair and Maintenance Returning Equipment If factory repair is required, our representatives will PCB guarantees Total Customer Satisfaction through its provide you with a Return Material Authorization (RMA) “Lifetime Warranty Plus” on all Platinum Stock Products number, which we use to reference any information you sold by PCB and through its limited warranties on all other have already provided and expedite the repair process. - Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
- Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
- Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
-
Page 6: Installation
OPERATION MANUAL FOR QUARTZ PRESSURE SENSOR Series 118 & 119 INTRODUCTION INSTALLATION The 118 & 119 Series are acceleration-compensated, With a 3/8-24 (M10x1.0 for metric mount) mounting high pressure sensors primarily developed to measure thread and flush diaphragm design, the 118 & 119 ballistics chamber pressures for R &... -
Page 7: Recessed Mount
OPERATION MANUAL FOR QUARTZ PRESSURE SENSOR Series 118 & 119 PREPARING NEW MOUNTING PORTS Refer to the installation drawing provided in this manual for instructions on mounting hole preparation. For best results, do not deviate from the steps outlined in this drawing. To assist new mounting port preparation, PCB offers the 040B20 Tooling Kit (040B21 for metric mount). -
Page 8: Flush Mount
OPERATION MANUAL FOR QUARTZ PRESSURE SENSOR Series 118 & 119 The natural frequency and approximate fastest Flash temperature effects are usually longer term and pressure step rise time for various length passages is will show up as a baseline shift long after the event to be measured has passed. -
Page 9: Operation
OPERATION MANUAL FOR QUARTZ PRESSURE SENSOR Series 118 & 119 OPERATION 118 & 119 IN-LINE SERIES COAXIAL Most test set-ups will include 118 & 119 Series AMPLIFIER CABLE sensors coupled with charge amplifiers, as shown in Typical Connection figure below. LOW-NOISE CABLE applications where the location of the measurement is a long distance from where the data must be read, an... - Page 10 Model Number Revision: K CHARGE OUTPUT PRESSURE SENSOR 118A02 ECN #: 55114 OPTION AL VERSION S Performance EN GLISH Optional versions have identical specifications and accessories as listed for the standard model except Sensitivity(± 15 %) 0.1 pC/psi 0.014 pC/kPa where noted below.
