A F C M

U n i v e r s a l

I / f c o n v e r t e r

M o d e l N o . A F C M 0 0 0 1

D r a w i n g N o . L P 1 1 0 2

V e r s i o n N o . 1 0 1

R e v i s i o n D a t e 1 9 / 0 6

Need help?

Do you have a question about the AFCM and is the answer not in the manual?

Questions and answers

Summary of Contents for red lion AFCM

Page 1 A F C M U n i v e r s a l I / f c o n v e r t e r M o d e l N o . A F C M 0 0 0 1 D r a w i n g N o .
Page 3 UNIVERSAL I/f CONVERTER AFCM CONTENTS Warning ....................... Symbol identification ................Safety instructions ................. How to dismantle the device ............. Advanced features ................. Application ....................Technical characteristics ..............PGM Display / programmer front ............Mounting / demounting the PGMMOD ........... 10 Applications....................
Page 4 HAZARD OUS General mounting, connection and disconnection of wires. VOLTAGE Troubleshooting the device. Repair of the device must be done by Red Lion Controls only. WARNING The device must be mounted on a DIN rail according to DIN 46277. INSTAL-...
Page 5 Should there be any doubt as to the correct handling of the device, please contact your local distributor or, alternatively, Red Lion Controls www.redlion.net LP1102...
Page 6 When disconnected, the device may be cleaned with a cloth moistened with dis- tilled water. LIABILITY To the extent that the instructions in this manual are not strictly observed, the custom er cannot advance a demand against Red Lion Controls that would otherwise exist according to the concluded sales agreement. LP1102...
Page 7 HOW TO DISMANTLE THE DEVICE First, remember to demount the connectors with hazardous voltages. Picture 1: Detach the device from the DIN rail by lifting the bottom lock. LP1102...
Page 8 • Galvanic separation and conversion of analogue signals to frequency signals. Technical characteristics • When AFCM is used in combination with the PGM display / programmer front, all operational parameters can be modified to suit any application. As the AFCM is designed with electronic hardware switches, it is not necessary to open the device for setting of DIP-switches.
Page 9 Application • Communications interface for modification of operational parameters in AFCM. • Can be moved from one AFCM device to another and download the configuration of the first converter to subsequent converters. • Fixed display for readout of process data and status.
Page 10 MOUNTING / DEMOUNTING THE PGMMOD 1: Insert the tabs of PGMMOD into the holes at the top of the device. 2: Swing PGMMOD into place. Demounting of PGMMOD 3: Push the release button on the bottom of PGMMOD and swing PGMMOD up. PGMMOD00 shown, PGMMODC1 connects and disconnects in the same way.
Page 11 APPLICATIONS Input signals: Volt- Current ten-tio- RTD and lin. R meter Connection, wires Passive Sensor Active Sensor Output signals: Frequency output PNP, +24 V NPN, 24 V Out. Gnd. TTL, 5 V Supply: 21.6...253 VAC 19.2...300 VDC LP1102...
Page 12 Electrical specifications Specifications range ..........-20°C to +60°C Calibration temperature ........20...28°C Relative humidity............. < 95% RH (non-cond.) Protection degree ............ IP20 Mechanical specifications Dimensions (HxBxD) ..........109 x 23.5 x 104 mm Dimensions, with PGMMOD (HxBxD) ....109 x 23.5 x 116 / 131 mm Weight ................
Page 13 Basic values Input Basic Temperature type accuracy coefficient ≤ ±4 µA ≤ ±0.4 µA / °C ≤ ±20 µV ≤ ±2 µV / °C Volt ≤ ±0.2°C ≤ ±0.01°C / °C Pt100 Linear resistance ≤ ±0.1 Ω ≤ ±0.01 Ω / °C ≤...
Page 14 TC input Min. Max. Type value value Standard +400°C +1820°C IEC 60584-1 -100°C +1000°C IEC 60584-1 -100°C +1200°C IEC 60584-1 -180°C +1372°C IEC 60584-1 -200°C +900°C DIN 43710 -180°C +1300°C IEC 60584-1 -50°C +1760°C IEC 60584-1 -50°C +1760°C IEC 60584-1 -200°C +400°C IEC 60584-1...
Page 15 PNP output max................ 30 mA ................24 VDC ± 10% ................10 nF typ................ 20 Ω Electromechanical counter ........24 V / 135 mA / 20 ms / ≤ 10 Hz NPN output max............... 150 mA sink max.
Page 16 Configuration of sensor error detection Module: Configuration Sensor error detection: OUT.ERR=NO AFCM Else: Display readout on the PGM Display outside range Display readout below min. / above max. (-1999, 9999): Flashing Input Range readout Limit -1999 Display readout <-1999 9999 Display readout >9999...
Page 17 Test of internal CJC sensor CJ.ER tem perature outside range Checksum test of the configuration in FLASH FL.ER Error in FLASH Communications test PGM / AFCM NO.CO Connection error Check that input signal matches input configuration IN.ER 1) Error levels on input Check that saved configuration in PGM matches module TY.ER...
Page 18 CONNECTIONS Supply: Polarity is reversible. Inputs RTD, 2-wire RTD, 3- / 4-wire Resistance, 2-wire 41 42 43 44 41 42 43 44 41 42 43 44 41 42 43 44 Resistance, Potentiometer 2-wire transmitter Current 3- / 4-wire 41 42 43 44 41 42 43 44 41 42 43 44 41 42 43 44...
Page 19 BLOCK DIAGRAM 2-wire transmitter Current Voltage Potentiometer LP1102...
Page 20 Documentation for routing diagram. In general When configuring the AFCM, you will be guided through all parameters and you can choose the settings which fit the application. For each menu there is a scrolling help text which is automatically shown in line 3 on the display.
Page 21 Signal and sensor error info via display front PGM Sensor error (see limits in the table) is displayed as SE.BR (sensor break) or SE.SH (sensor short). Signals outside the selected range (not sensor error, see table for limits) are displayed as IN.LO indicating low input signal or IN.HI indicating high input signal.
Page 22 Language: In the menu ”lang.setup” you can choose between 7 different language versions of help texts that will appear in the menu. You can choose between UK, DE, FR, IT, ES, SE and DK. Auto diagnosis The unit performs an advanced auto diagnosis of the internal circuits. The following possible errors can be displayed in the front unit PGMMOD00.
Page 23 ROUTING DIAGRAM Power up If no key is activated for 1 minute, the display will return to the default state 1.0 without saving configuration changes. 1 Increase value / choose next parameter 2 Decrease value / choose previous parameter 3 Save the chosen value and proceed to the next menu Hold 3 Back to previous menu / return to menu 1.0 without saving 50.0 12.0...
Page 24 p / m 999.9 50%DC p / h -199.9 25000 25000 25000 prg p 1000 p / d 100.0 25.00 DISP.HI OU.UN f.min f.max CUT.OFF O.TYPE t.PULSE Txt 14 Txt 20 Txt 21 Txt 22 Txt 23 Txt 19 Txt 24 f>500 Hz 50%DC 0.06...
Page 25 4172 4172 26250 -328 -328 OUT.ERR f.ERR RESP OUT.LO OUT.HI Txt 25 Txt 26 Txt 40 Txt 41 Txt 42 31500 To default state 1.0 OUT.ERR f.ERR Txt 25 Txt 26 1.2 = Not valid for these input signals: 0...20 mA and voltage.
Page 26 ROUTING DIAGRAM ADVANCED SETTINGS (ADV.SET) DISP 2.0 In the submenu simulation (SIM) you must press 3 to return to the default state 1.0. PASS SAVE LOAD LANG SAVE SETUP MEMORY Txt 43 Txt 44 f.OUT DISP f.OUT SETUP CONTRA LIGHT TAGNO.
Page 27 SCROLLING HELP TEXT IN DISPLAY LINE 3 [01] Set correct password [19] Select 50% duty cycle output [02] Enter advanced setup menu? Select programmable pulse time [03] Select temperature input [20] Select Hz as output unit Select potentiometer input Select pulses/minute as output unit Select linear resistance input Select pulses/hour as output unit Select current input...
Page 28 Ordering information DESCRIPTION PART NUMBER AFCM0000 Analog to Freq. Converter PGMMOD00 Programming Module Program/Comms Module PGMMODC1 LP1102...
