Wired Floodlight Camera
FLW2001 / FLW2001B
User Manual
WARNING: Risk of electrical shock and fire. Do not install wired floodlight camera ("Fixture") near
combustible or flammable surfaces. Installation must be performed by a licensed electrician.
•
Always follow local building codes, standards, and regulations.
•
Existing electrical wires are required for Fixture installation.
•
Disconnect power at the fuse or circuit breaker powering the Fixture before installing. Failure to
disconnect power might result in serious injury.
•
Verify supply voltage is correct. Connect Fixture to a 100 VAC~240 VAC 50/60 Hz power source.
•
Properly ground Fixture.
•
Do not connect the Fixture to a dimmer switch or timer.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLW2001 and is the answer not in the manual?

Questions and answers

Related Manuals for Arlo FLW2001

Summary of Contents for Arlo FLW2001

  • Page 1 Wired Floodlight Camera FLW2001 / FLW2001B User Manual WARNING: Risk of electrical shock and fire. Do not install wired floodlight camera (“Fixture”) near combustible or flammable surfaces. Installation must be performed by a licensed electrician. • Always follow local building codes, standards, and regulations.
  • Page 2 Wall-mount your Wired Floodlight Camera ................. 10 Ceiling-mount your Wired Floodlight Camera ................13 Onboard your Wired Floodlight Camera with the Arlo Secure App ......... 16 Wi-Fi setup and connections Find your 2.4 GHz Wi-Fi network name and password .............. 18 Change your Wired Floodlight Camera’s Wi-Fi network ............
  • Page 3 Profile settings ............................ 46 Device access settings ........................48 Device location and plans settings ....................48 Troubleshooting Arlo doesn’t discover your floodlight during setup ..............51 Can’t see video streams in a browser .................... 51 Wi-Fi signal interference ........................52 Contents...
  • Page 4 Get the Arlo Secure App The Arlo Secure App lets you create an Arlo account in the cloud and set up and manage all your Arlo devices. Search for it in your phone’s app store, or go to www.arlo.com/arlosecure, to download or update your Arlo Secure App.
  • Page 5 Wired Floodlight Camera Meet your Wired Floodlight Camera Adjustable Floodlights Pairing Button Camera Mounting Screw Hole Microphone Adjustable Camera Camera Status LED Motion Sensor (Avoid touching or pressing) Speaker Mounting options Wall Mount Ceiling Mount Get to know your Wired Floodlight Camera User Manual...
  • Page 6 Wired Floodlight Camera Meet your Junction Box Junction Box Mounting Screw Hole Cable Clamp Wire Grommet Terminal S-Hook Anchor Block Floodlight Mounting Screw Hole Junction Box Mounting Screw Hole Get to know your Wired Floodlight Camera User Manual...
  • Page 7 30-day video cloud storage, People, Package, Vehicle Detection, and more. 2. This Arlo Secure service may require a paid subscription after the trial period, and some Arlo Secure services may be unavailable in certain regions. For current information on features that need a paid subscription, visit www.arlo.com/arlosecure.
  • Page 8 Arlo account. 2. Once you set up your Arlo account, you can access it from the Arlo Secure App on a smartphone or tablet, or from a computer using a web browser. If you’re using a computer, enter https:// my.arlo.com in the address bar of the browser.
  • Page 9 For the best experience, choose a location with a strong Wi-Fi signal. To monitor motion closer to the floodlight, Arlo recommends mounting your device 8.2 feet (2.5 meters) off the ground, angled towards the ground so that visitors appear in the lower two-thirds of the image.
  • Page 10 When mounting your floodlight and junction box, select a mounting surface that can support the weight of your device. Mounting your floodlight in an unstable location might create a hazardous situation or damage your product, which might not be covered by Arlo’s warranty. Wall-mount your Wired Floodlight Camera 1.
  • Page 11 Wired Floodlight Camera 7. On walls made of wood, pre-drill holes with a 3 mm (1/8-inch) drill bit. Use the Junction Box Mounting Screws from Bag A to secure your Junction Box. 8. On walls made of hard materials (such as stucco, brick, or concrete), pre-drill holes with a 6 mm (15/64-inch) drill bit.
  • Page 12 Wired Floodlight Camera 15. Slide the power cable’s BLUE (Neutral) wire into the top of the terminal block marked with N. Tighten with your Flat-head Screwdriver. 16. Reposition cable clamp to now hold the power cable in place. Use your Phillips Screwdriver to replace its screw.
  • Page 13 LED on the front of the camera is solid blue. Remain close to your Floodlight as you onboard it in the Arlo Secure App. If power is controlled by a switch, make sure it’s always on. Your Wired Floodlight Camera must have constant power to stay connected.
  • Page 14 Wired Floodlight Camera 9. Use your Phillips Screwdriver to remove one screw from the cable clamp to release it. Rotate the cable clamp to the side, and set the screw aside for later use. 10. Run the power cable through the opening. Note: Electrical wire colours may vary based on multiple factors.
  • Page 15 You’ll know your Floodlight is receiving power when the LED on the front of the camera is solid blue. Remain close to your Floodlight as you onboard it in the Arlo Secure App. If power is controlled by a switch, make sure it’s always on. Your Wired Floodlight Camera must have constant power to stay connected.
  • Page 16 When your Wired Floodlight Camera is ready to connect, the LED will flash blue. If your device behaves differently, see Arlo doesn’t discover your floodlight during setup on page 14. Choose a 2.4GHz Wi-Fi network. 15. Enter the Wi-Fi password and wait for it to be verified.
  • Page 17 3. Wi-Fi setup and connections When you install and set up your Wired Floodlight Camera, the Arlo Secure App guides you through the process of connecting to your router’s 2.4 GHz Wi-Fi network. Tips for optimal Wi-Fi performance The distance between Wi-Fi devices can affect the Wi-Fi signal: Maximum recommended distance.
  • Page 18 Wired Floodlight Camera Find your 2.4 GHz Wi-Fi network name and password If you’re not sure about how to find the 2.4 GHz Wi-Fi network: • Look on your Wi-Fi router label. Many routers have a label that shows the Wi-Fi network name, which is also called an SSID.
  • Page 19 4. Use your Wired Floodlight Camera When you open the Arlo Secure App, you are presented with your dashboard. Arm Away, Arm Home, and Standby modes to protect your home Tap Play to stream the camera feed Tap a navigation icon to go to...
  • Page 20 Wired Floodlight Camera View your camera feeds 1. Open the Arlo Secure App. 2. Navigate to Devices. 3. Tap Play on your Wired Floodlight Camera feed. The camera feed updates and camera feed icons display. 4. To stop viewing and listening to the live feed, tap Stop Pan and zoom your video feed 1.
  • Page 21 10. Enter a name, and tap Rename. 11. Tap Save. 4. This Arlo Secure service may require a paid subscription after the trial period, and some Arlo Secure services may be unavailable in certain regions. For current information on features that need a paid subscription, visit www.arlo.com/arlosecure.
  • Page 22 Wired Floodlight Camera Change an activity zone 1. Open the Arlo Secure App. 2. Navigate to Devices. 3. Tap Menu 4. Tap Device Settings next to your Wired Floodlight Camera. 5. Tap Activity Zones. 6. Tap the name of a zone to select it.
  • Page 23 4. Tap Call to confirm. 5. This Arlo Secure service may require a paid subscription after the trial period, and some Arlo Secure services may be unavailable in certain regions. For current information on features that need a paid subscription, visit www.arlo.com/arlosecure.
  • Page 24 Recordings are encrypted with your user name and password. You can access your recordings from the Arlo Secure App on your mobile device or by using a web browser to visit https://my.arlo.com. You can download recordings from Feed and save them.
  • Page 25 Wired Floodlight Camera Turn on/ off filter Use the filter to find and view recordings based on criteria that you select. 1. Open the Arlo Secure App. 2. Navigate to Feed. 3. Tap Menu 4. Tap Feed Settings. 5. Tap Devices and make sure your Wired Floodlight Camera is selected.
  • Page 26 Wired Floodlight Camera Revert feed settings 1. Open the Arlo Secure App. 2. Navigate to Feed. 3. Tap Menu 4. Tap Feed Settings. 5. Tap Restore Default Settings. 6. Tap Save. Download recordings 1. Open the Arlo Secure App. 2. Navigate to Feed.
  • Page 27 4. Tap Menu 5. Tap Delete. 6. Tap Delete again to confirm. Donate recordings Donating recordings gives Arlo permission to use and view the content for research and development. 1. Open the Arlo Secure App. 2. Navigate to Feed. 3. Tap a recording.
  • Page 28 Wired Floodlight Camera Manage events 1. Open the Arlo Secure App. 2. Navigate to Feed. 3. Tap Manage events. 4. Select which events to simultaneously perform an action on. 5. Tap Download, Favorite, or Delete. Use your Wired Floodlight Camera...
  • Page 29 Arm Home. Stay protected when at home by keeping certain devices armed. Standby. Disarm certain devices, while keeping specific ones armed. For more information on Modes, Automations, and Alerts, see About Arlo Routines, Modes, Rules, and Automations. Select a mode 1.
  • Page 30 Add a schedule To schedule when your Wired Floodlight Camera is armed: 1. Open the Arlo Secure App. 2. Navigate to Routines. 3. Tap the Plus icon 4. Tap Add Schedule.
  • Page 31 Wired Floodlight Camera Activate your floodlight from dusk to dawn Allow your floodlight to automatically activate from sunset to sunrise: 1. Open the Arlo Secure App. 2. Navigate to Routines. 3. Tap the Plus icon 4. Tap Add Schedule. 5. Specify which days.
  • Page 32 Wired Floodlight Camera Delete a schedule 1. Open the Arlo Secure App. 2. Navigate to Routines. 3. Tap Automations. 4. Slide the schedule to the left, then tap Delete. Add an arrive/leave 1. Open the Arlo Secure App. 2. Navigate to Routines.
  • Page 33 Wired Floodlight Camera Edit Geofence 1. Open the Arlo Secure App. 2. Navigate to Routines. 3. Tap Automations. 4. Tap an Arrive/Leave to modify. 5. Tap Edit Geofence. and choose a Radius. 6. Tap Save. 7. Tap Save again to confirm.
  • Page 34 The Mute Notification status shows the amount of remaining time until notifications resume. Note: If you log out of the Arlo Secure App on your smartphone or mobile device, you will stop receiving push notifications. Extend mute notifications 1. Open the Arlo Secure App.
  • Page 35 Wired Floodlight Camera Change notification tone 1. Open the Arlo Secure App. 2. Navigate to Profile 3. Tap Notifications. 4. Tap Notification Tone. 5. Select from the Notification Tones options. Tap Play to test a tone before selecting it. Allow critical alerts 1.
  • Page 36 6. Change your Settings Use the Arlo Secure App to view and change the settings for your Arlo devices. You can view the product type, firmware version, hardware version, serial number, and the regulatory information of your device. Device settings View device information 1.
  • Page 37 5. In Device Settings select the device. 6. Tap Edit next to the Device Name. Device names are limited to 32 characters. Arlo recommends using a name that reminds you of the camera’s location, such as Garage or Front Door.
  • Page 38 Wired Floodlight Camera Restart the camera from the Arlo Secure App 1. Open the Arlo Secure App. 2. Navigate to Devices. 3. Tap Menu 4. Tap Device Settings next to your Wired Floodlight Camera. 5. In Device Settings select the device.
  • Page 39 Wired Floodlight Camera Rotate camera feed 1. Open the Arlo Secure App. 2. Navigate to Devices. 3. Tap Menu 4. Tap Device Settings next to your Wired Floodlight Camera. 5. Tap Video Settings. 6. Toggle Rotate Image 180° to rotate the orientation of the camera feed.
  • Page 40 The combination of certain artificial light sources and the camera shutter speed might cause flickering in the recorded video. The default setting is Auto, but you can change the flicker adjustment. 1. Open the Arlo Secure App. 2. Navigate to Devices. 3. Tap Menu 4.
  • Page 41 Define your floodlight's brightness, duration, sensitivity, and behavior upon activation of your Wired Floodlight Camera. For more information on your floodlight's light settings, see How do I adjust the light settings on my Arlo Wired Floodlight Camera? Customize floodlight brightness 1.
  • Page 42 Wired Floodlight Camera Determine floodlight behavior 1. Open the Arlo Secure App. 2. Navigate to Devices. 3. Tap Menu 4. Tap Device Settings next to your Wired Floodlight Camera. 5. Tap Light Settings. 6. Select from the Behavior options. Audio settings You can adjust the settings to reduce wind noise, turn the microphone off and on, and adjust the speaker.
  • Page 43 Default mode settings Determine the default mode settings your Wired Floodlight Camera automatically responds with upon activation. Adjust motion sensitivity 1. Open the Arlo Secure App. 2. Navigate to Devices. 3. Tap Menu 4. Tap Device Settings next to your Wired Floodlight Camera.
  • Page 44 Wired Floodlight Camera Change audio detection sensitivity 1. Open the Arlo Secure App. 2. Navigate to Devices. 3. Tap Menu 4. Tap Device Settings next to your Wired Floodlight Camera. 5. Select Default Mode Settings. 6. Move the Audio Detection slider to adjust the Wired Floodlight Camera’s sensitivity level for audio detection.
  • Page 45 Tap Check Current Level to see your Wired Floodlight Camera’s current ambient light sensitivity. For more information about ambient light sensitivity, see What is the Ambient Light Sensitivity setting and how does it work for my Arlo device? Customize siren 1. Open the Arlo Secure App.
  • Page 46 Wired Floodlight Camera Profile settings Change profile name or email 1. Open the Arlo Secure App. 2. Navigate to Profile 3. Tap Account Profile and Security. 4. Tap Name, Email. 5. Input the account name/ email address information. 6. Tap Save.
  • Page 47 Wired Floodlight Camera Set up assistant PIN Use voice controls to arm or disarm your Arlo security system. Setting up a 4 digit PIN is mandatory for disarming Arlo devices controlled by a voice assistant. 1. Open the Arlo Secure App.
  • Page 48 5. Input the profile name/ email address information. 6. Select which DEVICES this person can access. 7. Select which Access Rights this person can use. 8. Choose if this person can Access Arlo Emergency Response for Home. 9. Tap Send Invite. Device location and plans settings Add a location 1.
  • Page 49 Wired Floodlight Camera Change the device address 1. Open the Arlo Secure App. 2. Navigate to Profile 3. Under LOCATIONS AND PLANS, select a location. 4. Tap Address. 5. Input the device address information. 6. Tap Save. Edit temperature units 1.
  • Page 50 5. Follow the onscreen directions to activate ARLO INTELLIGENCE. 6. This Arlo Secure service may require a paid subscription after the trial period, and some Arlo Secure services may be unavailable in certain regions. For current information on features that need a paid subscription, visit www.arlo.com/arlosecure.
  • Page 51 Arlo doesn’t discover your floodlight during setup If you’re trying to set up and connect your Arlo floodlight directly to your Wi-Fi router and Arlo doesn’t discover your floodlight, here are some things to check to identify and correct the problem.
  • Page 52 Not receiving push notifications You must be logged in to the Arlo Secure App to receive Arlo alerts on your smartphone or mobile device. Arlo registers your device for push notification when you log in. If you used the logout option instead of simply exiting the app, you must log back in to the app.
  • Page 53 High Efficiency Video Coding (HEVC) is a video compression standard that enables you to download and stream 2K videos with ease. To use HEVC on the Arlo Secure App, you must use a supported device and meet the minimum requirements. Your device must: •...
  • Page 54 For additional regulatory compliance information including EU Declaration of Conformity, visit, http://www.arlo.com/about/regulatory/. Some Arlo products have a regulatory e-label that you can access in the Arlo app or web portal. This is because a printed regulatory label does not fit all of the regulatory information on the Arlo product label.
  • Page 55 FCC ID: 2APLE18300426 IC: 23815-18300426 CAN ICES-003 (B)/NMB-003 (B) Note: If the Arlo Secure App does not show a Regulatory sub-menu for your Arlo product, then the product does not have a regulatory e-label, and you can find all regulatory information on the physical label located on the floodlight base.
  • Page 56 Wired Floodlight Camera RF exposure statements This Transmitter must not be colocated or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body or nearby persons.
