- Page 1 Scan QR Code for WiFi Setup EPA58023W Portable Air INSTRUCTIONS Conditioner Important: Retain these instructions for future use. 04785A 09/24...
- Page 2 24 MONTH WARRANTY The warranty is not transferable to a subsequent This warranty does not apply to any defect, deterioration, purchaser if the appliance is sold by the original purchaser loss, injury or damage occasioned by or as a result of during the warranty period.
- Page 3 INSTALLATION - GENERAL INFORMATION INDOOR USE ONLY • Avoid splashing any type of liquid onto this appliance • Closely supervise any children and pets when the appliance is in use. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision...
- Page 4 GENERAL INFORMATION 1. The appliance shall be stored so as to prevent 6. Where electrical components are being mechanical damage from occurring changed, they shall be fit for the purpose and to the correct specification. At all times 2. Every working procedure (Such as below) that affects the manufacturer’s maintenance and service safety means shall only be carried out by competent guidelines shall be followed. If in doubt, consult the persons.
- Page 5 10. Under no circumstances shall potential sources - Cylinders shall be kept in an appropriate of ignition be used in the searching for or position according to the instructions. detection of refrigerant leaks. A halide torch (or - Ensure that the refrigerating system is any other detector using a naked flame) shall earthed prior to charging the system with not be used. refrigerant. - Label the system when charging is The following leak detection methods are deemed complete (if not already labelled). acceptable for all refrigerant systems. Electronic leak detectors may be used to detect - Extreme care shall be taken not to overfill refrigerant leaks but, in the case of flammable the refrigerating system. refrigerants, the sensitivity can be inadequate, or Prior to recharging the system, it shall be pressure- can need re-calibration. (Detection equipment shall tested with the appropriate purging gas. The system be calibrated in a refrigerant-free area.) Ensure that shall be leak-tested on completion of charging but the detector is not a potential source of ignition and prior to commissioning. A follow up leak test shall be is suitable for the refrigerant used. Leak detection carried out prior to leaving the site.
- Page 6 GENERAL INFORMATION Disposal 10) When the cylinders have been filled correctly and the process completed, make sure that the The environment and personal safety must be cylinders and the equipment are removed from considered when disposing of this appliance. Please site promptly and all isolation valves on the ensure the appliance is taken to a recycle center for equipment are closed off. safe recycling. DO NOT dispose of the appliance in land fill as the insulation and refrigerant gas 11) Recovered refrigerant shall not be charged into contained in these appliances are flammable. another refrigerating system unless it has been cleaned and checked. 14. When removing refrigerant from a system, either for servicing or decommissioning, it is required to follow good practice so that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge is available. All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be complete with pressure-relief valve and associated shut-off valves in good working order. Empty recovery cylinders are evacuated and, if possible, cooled before recovery occurs. The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of the flammable refrigerant. Consult manufacturer if in doubt. In addition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak-free disconnect couplings and in good condition.
- Page 7 INSTALLATION General Information • Do not turn on the appliance if you have discovered • Any person who is involved with working on or damage to the appliance, cord or plug, if the appliance breaking into a refrigerant circuit should hold a is malfunctioning or if there are signs of any other current valid certificate from an industry-accredited defect.
- Page 8 PARTS FRONT BACK Control panel 6. Air filter (air inlet) 2. Air vent 7. Exhaust air outlet 3. Caster 8. Drainage 4. Carry handle 9. Power cord storage 5. Air filter (air inlet) ACCESSORIES 14. Drain tube for continuous drainage 10.
- Page 9 INSTALLATION This portable appliance can be moved from room to room as required. Before using your appliance, the exhaust pipe and window spacer kit must be installed to allow the condensed heat to escape outside to the open air. Using the included window spacer kit, follow the instructions below for the correct installation.
- Page 10 EXHAUST PIPE WINDOW MOUNTING Fig. 1 • Only use the exhaust pipe and fittings provided. Connect the exhaust pipe to the back of the appliance and then to the flat adapter which was previously installed in the window spacer kit. •...
- Page 11 CARBON FILTER INSTALLATION This appliance is supplied with active carbon filters. The activated carbon is charcoal that has been treated with oxygen to open up millions of tiny pores between the carbon atoms. It is used to get rid of unwanted odors (smoke, fumes, and animal odor).
- Page 12 CONTROL PANEL 1. WiFi button A. Timer operation indicator 2. Timer button B. WiFi indicator 3. Speed (ventilation) button C. High ventilation indicator 4. Temperature up button D. Low ventilation indicator 5. ON/OFF (power) button E. Display window 6. Temperature down button F.
- Page 13 TURNING ON/OFF Note; At the default setpoint of 24˚C, the appliance starts 1. Touch the ON/OFF button and the appliance will cooling at 28˚C (setpoint + 4˚C). When the temperature start in AUTO (automatic) mode. reaches 26˚C (setpoint + 2˚C), it will then switch back to 2.
- Page 14 SETTINGS Setting mode/function Touch the MODE button to select the required operating 4. Please note, the sleep mode is not available while the appliance is operating in ventilation, dehumidification mode: Cooling or Fan (Ventilation). or auto modes. Sleep mode is only available in the The corresponding indicator of your selected mode will cooling mode.
- Page 15 AIR FLOW Adjust the air flow direction by manually moving the outer vent louvers ‘Up’ or ‘Down’ . IMPORTANT! 1. To extend the life of the compressor, it is recommended to wait at least 3 minutes before turning the appliance back On, once it has been turned Off.
- Page 16 DRAINAGE During normal operation of this appliance, moisture from Should you prefer to use the appliance without having to the air will be collected in the internal water tank and will empty the tank every so often, proceed as follows: require emptying periodically.
- Page 17 MAINTENANCE For personal safety, always unplug the appliance from mains power prior to cleaning. To maximize the efficiency of this appliance, ensure that it is cleaned regularly following these simple steps. Cleaning the housing Use a soft cloth, dampened with water only to wipe down the outer case.
- Page 18 FAULT CHECK LIST FAULT CAUSE Is the appliance plugged in or turned On? Is there a power failure? The appliance does not turn On. Is the ‘Water Full’ indicator flashing? Empty if required. Is the room temperature below the set temperature? Is the appliance in direct sunlight? Close curtains if necessary.
- Page 19 PARTS SPECIFICATIONS ITEM No EPA58023W Cooling capacity 2.3 kW Power/Ampere consumption* (Cooling) 920W/4.2A Air volume (max. speed) 360m3/h Humidity removal capacity 0.97L/h Power supply 220 - 240V/50Hz Compressor Rotary Refrigerant R290/ 220g Fan speed Timer 24 Hours Working temperature Cooling: 18 ~ 32˚C Exhaust pipe Ø...
