- Page 1 REMOTE CONTROLLER MANUAL Instruction manual Page 1~26 To obtain the best performance, please read this instruction manual completely. คู ่ ม ื อ การใช ้ ง าน หน ้า 27~54 เพื อได ้รั บ การทํ า งานที ดี ท ี สุ ด โปรดอ่ า นคู ่ ม ื อ อย่ า งละเอี ย ด <...
- Page 2 Names and Functions of Remote Controller ■ This remote controller controls the operation function and timer setting of the room air conditioner. The operating range of the remote controller is about 23 feet. If indoor lighting is controlled electronically, the range of control may be shorter.
- Page 3 How to Install the Batteries in the Remote Controller Remove the cover as shown in the fi gure and take out the old batteries. Push and pull to the direction of arrow Batteries Install the new batteries. The direction of the batteries should match the marks in the case. CAUTION 1.
- Page 4 VARIOUS FUNCTIONS ■ Auto Restart Control If there is a power failure, operation will be automatically restarted when the power is resumed with ● previous operation mode and airfl ow direction. (As the operation is not stopped by remote controller.) If you intend not to continue the operation when the power is resumed, switch off the power supply.
- Page 5 Heat Mode Use the device for heating when the outdoor temperature is under 75.2°F. ● When it is too warm (over 75.2°F), the heating function may not work in order to protect the device. In order to keep reliability of the device, please use this device above -5°F of the outdoor temperature. ●...
- Page 6 Dry Mode Use the device for dehumidifying when the room temperature is over 60°F. When it is under 59°F, the dehumidifying function does not work. Press the Mode Selector button so that the display indicates (Dry). The fan speed is set at Auto. Press (Fan Speed) button to select Silent, Low or Auto fan speed.
- Page 7 Cool Mode Use the device for cooling when the outdoor temperature is -0.4°F to 114.8°F. If indoors humidity is very high (over 80%), some dew may form on the air outlet grille of the indoor unit. Press the Mode Selector Button so that the display indicates (Cool).
- Page 8 Timer Reservation 1. Off Timer Setting The device can be set to turn off at a preset time. Press (Timer OFF) button to select OFF timer. ● Symbol start blinking and 12:00 or previously set time will ● be display on LCD screen. Set up desire Turn off time by pressing Temperature Up/Down ●...
- Page 9 Powerful Operation By pressing (Powerful) button during Auto, Heat, Dry, Cool or Fan operation, the air conditioner performs ● at maximum power. During Powerful operation, cooler or warmer air will be blown out from indoor unit for Cooling or Heating ●...
- Page 10 FrostWash Operation The dust and dirt adhering to indoor heat exchanger which is the cause of the smell. They are washed away by ● freezing and thawing of the heat exchanger. ● FrostWash operation can work when the outdoor temperature is 34°F and 109°F and indoor humidity is 30% to 70%. The process of FrostWash is pressed Operation is started...
- Page 11 Mold Guard Operation ● After the cooling operation is stopped, the fan of the indoor unit is dried by heating or fan mode to suppress the generation of mold inside the indoor unit. – Mold Guard Operation period is about 80 minutes. –...
- Page 12 ECO Operation ■ Energy saving operation by changing set temperature and by limiting the maximum power consumption value. By pressing the (ECO) button during Heating, Automatic Dehumidifying or Cooling operation, the air conditioner performs the “ECO” operation. Press (ECO) button during operation. “...
- Page 13 Silent Operation By pressing the (Silent) button during Auto, Heat, Dry, Cool or Fan operation, the fan speed changes to the silent fan speed ● When (Silent) button is pressed, START “ ” is displayed on the LCD. ● Fan speed changes to silent ●...
- Page 14 GoodSleep Timer Setting By pressing the (GoodSleep) button during Auto, Heat, Dry, Cool or Fan operation, the unit shifts the room temperature and reduces the fan speed. Mode Indication Set Temp.–0.5Hr. –1.0Hr.–2.0Hr.–3.0Hr. 10.0Hr. –11.0Hr.–12.0Hr. GoodSleep (Cancel GoodSleep Timer) Timer During GoodSleep Timer the unit will continue working for the designated number of hours.
- Page 15 Fan Mode User can use the device simply as an air circulator. Press the Mode Selector button so that the display indicates (Fan) . Press the (Fan Speed) button. (Silent) (Low) (Medium) (Super High) (High) START Press the (On/Off) button. Fan operation starts with a beep. Press STOP the button again to stop operation.
- Page 16 My Mode(Programming) Use this mode for personalized comfortable settings. The My Mode can be set by using the remote ● controller. Up to 3 programs can be set. ● Programming of My Mode Default Setting of My Mode My Mode Mode Temperature Fan Speed...
- Page 17 My Mode(Programming) Programming of My Mode On Timer Setting ● Press (On Timer) button to select ON timer. Symbol start blinking on LCD screen. ON Timer time will be display on clock time segment on LCD. ● Press button to set desire ON timer. ●...
- Page 18 My Mode(Start or Stop of My Mode Operation) Start of My Mode Operation Start of My Mode Operation Press (My Mode) button at room air conditioner ● operation. Room air conditioner starts with My Mode 1 registered to remote controller. Press (My Mode) button again in order to change to ●...
- Page 19 Operation Mode Lock The remote controller can be set to fi x the Heat Mode (including Fan Mode), Cool Mode and Dry Mode (including Fan Mode) operations. ■ Method to lock Heat Mode (including Fan Mode) operation. Press (Mode) and buttons simultaneously for about 3 seconds when the remote controller is OFF.
- Page 20 How to Reset Filter Sign on the indoor unit Filter Sign on the indoor unit will show with “ ” lamp by blinking with 1 second on and 4 seconds off. Because cleaning of Air fi lter has not been done for a long time.
