Asus P519 Quick Start Manual

Quick Start Guide
快速使用指南（簡體中文）
Package Contents / 包裝內容物
Specifications / 規格
DPI 1 DPI 2
Resolution / 分辨率
Red / 紅色 Purple / 紫色
100 DPI to 12000 DPI /
400 DPI 800 DPI
100 DPI 至 12000 DPI
* You may customize the DPI settings for DPI 1-4 through Armoury Crate.
* 您可以通過 Armoury Crate 調整 DPI 1-4 的設置。
Mouse features / 鼠標功能
Left-click button / 左鍵
Scroll wheel / 滾輪
Right-click button / 右鍵
DPI button / DPI 按鈕
Forward button / 向前按鈕
Backward button / 向後按鈕
Profile switching / 循環配置文件
Profile / 配置文件
Profile 1 / 配置文件 1
Profile 2 / 配置文件 2
Profile 3 / 配置文件 3
Profile 4 / 配置文件 4
Profile 5 / 配置文件 5
C22330 / 第一版 / 2023 年 9 月
DPI 3 (Default / 默認 ) DPI 4
Blue / 藍色 Green / 綠色
1600 DPI 3200 DPI
USB Type-C® connector / USB Type-C ®
接口
Mouse feet / 鼠標腳墊
USB dongle / USB 無線信號接收器
Pairing button / 配對按鈕
Optical sensor / 光學感應器
Connection mode switch / 連接模式切換開關
Hot Key / 快捷鍵 Lighting effect / 燈效
Static（魔幻青）
Breathing（白光）
+ Reactive（紫色）
Reactive（藍色）
Color cycle （多色循環）
Connecting your gaming mouse
Setting up your gaming mouse as a wired mouse
Connect the bundled USB Type-C® to Type-A cable to your
gaming mouse and a USB port on your computer
Setting up your gaming mouse as a RF wireless mouse
1. Connect the USB dongle to a USB port on your computer.
2. Set the connection switch to the RF 2.4G Wireless mode.
Setting up your gaming mouse as a Bluetooth® wireless
mouse
Set the connection switch to the Bluetooth® mode.
Pairing Bluetooth® mode to additional host devices (max. 3)
1. Set the connection switch to the Bluetooth® mode.
2. Press and hold the Pairing button for 3 seconds until the LED on
your gaming mouse start to blink blue. Once your gaming mouse
has been successfully paired, the LED indicator on your gaming
mouse will light up blue for 3 seconds.
連接您的電競鼠標
將您的電競鼠標設置為有線鼠標
將隨附的 USB Type-C® 轉 Type-A 線的一端連接至電
競鼠標，另一端插入電腦的 USB 接口。
將您的電競鼠標設置為 RF 無線鼠標
1. 將 USB 無線信號接收器插入電腦的 USB 接口。
2. 將連接模式切換至【RF 2.4G 無線模式】。
將您的電競鼠標設置為藍牙無線鼠標
將連接模式切換至【藍牙模式】。
藍牙模式下與其他主機設備配對（最多三個設備）
1. 將連接模式切換至藍牙模式。
2. 長按配對按鈕 3 秒直至電競鼠標的 LED 指示燈變為藍色
閃爍。電競鼠標配對成功後，LED 指示燈將會亮藍色 3
秒。
Safety Guidelines
Keep the device away from liquid, humidity, or moisture. Operate the device only within the specific temperature range of 0°C(32°F) to 40°C(104°F). When the device exceeds
the maximum temperature, unplug or switch off the device to let it cool down.
安全說明
- 此滑鼠只應在溫度不高於 40°C（104°F）的環境下使用。
- 安裝錯誤型號的電池可能會導致爆炸。
本产品为微功率设备，消费者使用时应遵守以下规范，以免造成危害或损伤。
（一） 本产品2.4G微功率模式使用频率为:2400-2483.5MHz,发射功率限值: 10mW(e.i.r.p) ，频率容限：75kHz搭载2.4GHz无线技术，透过USB Dongle配对连接PC，提供低延迟音讯
传输，符合"微功率短距离无线电发射设备目录和技术要求"；
（二） 不得擅自改变使用场景或使用条件、扩大发射频率范围、加大发射功率（包括额外加装射频功率放大器），不得擅自更改发射天线；
（三）不得对其他合法的无线电台（站）产生有害干扰，也不得提出免受有害干扰保护；
（四） 应当承受辐射射频能量的工业、科学及医疗（ISM）应用设备的干扰或其他合法的无线电台（站）干扰；
（五） 如对其他合法的无线电台（站）产生有害干扰时，应立即停止使用，并采取措施消除干扰后方可继续使用；
（六） 在航空器内和依据法律法规、国家有关规定、标准划设的射电天文台、气象雷达站、卫星地球站（含测控、测距、接收、导航站）等军民用无线电台（站）、机场等的
电磁环境保护区域内使用微功率设备，应当遵守电磁环境保护及相关行业主管部门的规定；
（七） 禁止在以机场跑道中心点为圆心、半径5000米的区域内使用各类模型遥控器；
（八）本产品使用时工作温度为0 ~ 45度，工作电压3.4-4.2V。
Notices
Limitation of Liability
Circumstances may arise where because of a default on ASUS' part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the
basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and
tangible personal property; or any other actual and direct damages resulted from omission or failure of performing legal duties under this Warranty Statement, up to the listed
contract price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement.
This limit also applies to ASUS' suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-PARTY CLAIMS AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR
RECORDS OR DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS OR SAVINGS), EVEN
IF ASUS, ITS SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY.
RF Exposure Information (SAR)
This device meets the government's requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government.
The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted
using standard operating positions accepted by the FCC with the EUT transmitting at the specified power level in different channels.
The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information
on this device is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/eot/ea/fccid after searching on FCC ID: EMJMP709 / MSQMPDONGLE1
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with manufacturer's instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION! The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
Accessories that came with this product have been designed and verified for the use in connection with this product. Never use accessories for other products to
prevent the risk of electric shock or fire.
付属品は本製品専用です。本製品を使用の際には、必ず製品パッケージに付属のものをお使いください。また、付属品は絶対他の製品には使用しないでください。製品破損もし
くは、火災や感電の原因となる場合があります。
Compliance Statement of Innovation, Science and Economic Development Canada (ISED)
This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
CAN ICES-003(B)/NMB-003(B)
Déclaration de conformité de Innovation, Sciences et Développement économique Canada (ISED)
Le présent appareil est conforme aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
CAN ICES-003(B)/NMB-003(B)
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below the Innovation, Science and Economic Development Canada (ISED) radio frequency exposure limits. The Wireless
Device should be used in such a manner such that the potential for human contact during normal operation is minimized.
This device has been evaluated for and shown compliant with the ISED Specific Absorption Rate ("SAR") limits when operated in portable exposure conditions.
Informations concernant l'exposition aux fréquences radio (RF)
La puissance de sortie rayonnée du dispositif sans fil est inférieure aux limites d'exposition aux radiofréquences d'Innovation, Sciences et Développement économique Canada
(ISED). Le dispositif sans fil doit être utilisé de manière à minimiser le potentiel de contact humain pendant le fonctionnement normal.
Cet appareil a été évalué et montré conforme aux limites de DAS (Débit d'Absorption Spécifique) de l'ISED lorsqu'il est utilisé dans des conditions d'exposition portables.
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our
products at ASUS REACH website at http://csr.asus.com/english/REACH.htm.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be
able to responsibly recycle our products, batteries, other components as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed
recycling information in different regions.
Proper disposal
DO NOT throw the device in municipal waste. This product has been designed to enable proper reuse of parts and recycling. The symbol of the crossed out wheeled bin
indicates that the product (electrical, electronic equipment and mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT throw the device in fire. DO NOT short circuit the contacts.
DO NOT disassemble the device.
Updating the firmware and customization
1. Connect your gaming mouse to your computer using the
bundled cable, then connect the USB dongle to a USB port.
2. Download and install the Armoury Crate software from
https://rog.asus.com
3. Follow the software instructions to update your gaming mouse
and dongle's firmware.
4. Customize your gaming mouse using Armoury Crate.
Using the DPI On-The-Scroll tuning function
The DPI On-The-Scroll tuning function allows you to customize the
DPI of your gaming mouse without using Armoury Crate.
1. Press and hold the DPI button for 3 seconds until the LED on your
gaming mouse light up.
2. Scroll the scroll wheel forwards or backwards to adjust the DPI.
The LED color hue on your mouse will differ depending on the
DPI adjustment.
3. Press the DPI button once you have finished customizing the DPI
value to save the changes made.
更新固件及個性化
1. 使用隨附的 USB 線將電競鼠標連接至電腦，然後將 USB 接收
器插入 USB 接口。
2. 請至 https://rog.asus.com.cn/ 下載並安裝 Armoury Crate 軟件。
3. 請按照屏幕提示完成固件更新。
4. 使用 Armoury Crate 個性化您的電競鼠標。
使用 DPI On-The-Scroll 調節功能
DPI On-The-Scroll 調節功能可讓您無需使用 Armoury Crate 即可
自定義電競鼠標的 DPI。
1. 長按 DPI 按鈕 3 秒直至電競鼠標的 LED 指示燈亮起。
2. 向前或向後撥動滾輪以調節 DPI。調節後根據 DPI 的不同，滾
輪的 LED 指示燈顏色也會跟著改變。
3. 完成 DPI 數值自定義設置後，請再次按下 DPI 按鈕以保存更
改。
