MODEL 466248208 • PRODUCT GUIDE
THIS GRILL IS FOR OUTDOOR USE ONLY.
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
1-888-430-7870
.
466248208 • 80065367 • 04-02-08

Advertisement

loading
Need help?

Need help?

Do you have a question about the COMMERCIAL INFRARED 466248208 and is the answer not in the manual?

Questions and answers

Related Manuals for Char-Broil COMMERCIAL INFRARED 466248208

Summary of Contents for Char-Broil COMMERCIAL INFRARED 466248208

  • Page 1 MODEL 466248208 • PRODUCT GUIDE THIS GRILL IS FOR OUTDOOR USE ONLY. CAUTION: WARNING: Read and follow all safety statements, assembly Failure to follow all manufacturer’s instructions could instructions, and use and care directions before result in serious personal injury and/or property attempting to assemble and cook.
  • Page 2 WARNING DANGER CALIFORNIA PROPOSITION 65 If you smell gas: 1. Combustion by-products produced when using this product contain chemicals known to the State of California to cause cancer, birth defects, and other 1. Shut off gas to the appliance. reproductive harm. 2.
  • Page 3 To insure your satisfaction TABLE OF CONTENTS and for follow-up service, For Your Safety ........2 Grill Service Center.
  • Page 4 LP Cylinder USE AND CARE • The LP cylinder used with your grill must meet the following requirements: • Use LP cylinders only with these required measurements: 12" DANGER (30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.) capacity maximum.
  • Page 5 LP Cylinder Exchange Connecting Regulator to the LP Cylinder 1. LP cylinder must be properly secured onto grill. (Refer to • Many retailers that sell grills offer you the option of replacing your empty LP cylinder through an exchange service. Use only assembly section.) those reputable exchange companies that inspect, precision fill, 2.
  • Page 6 Leak Testing Valves, Hose and Regulator 1. Turn all grill control knobs to OFF. 2. Be sure regulator is tightly connected to LP cylinder. 3. Completely open LP cylinder valve by turning hand wheel counterclockwise. If you hear a rushing sound, turn gas off immediately.
  • Page 7 Safety Tips WARNING Before opening LP cylinder valve, check the coupling nut for tightness. When grill is not in use, turn off all control knobs and LP For Safe Use of Your Grill and to Avoid Serious cylinder valve. Injury: Never move grill while in operation or still hot.
  • Page 8 Burner Flame Check WARNING • Remove cooking grates and flame tamers. Light burners, rotate knobs from HIGH to LOW . You should see a smaller flame in LOW position than seen on HIGH. Perform burner Turn controls and gas source or tank OFF when not flame check on sideburner, also.
  • Page 9 Cleaning the Burner Assembly CAUTION Follow these instructions to clean and/or replace parts of burner assembly or if you have trouble igniting grill. 1. Turn gas off at control knobs and LP cylinder. SPIDER ALERT! 2. Remove cooking grates and flame tamers. 3.
  • Page 10 How To Tell If Meat Is Grilled Thoroughly Food Safety • Meat and poultry cooked on a grill often browns very fast on the Food safety is a very important part of enjoying the outdoor outside. Use a meat thermometer to be sure food has reached cooking experience.
  • Page 11 The methods below are suggestions for cleaning stainless steel surfaces. Choose a cleaning method appropriate for your needs. It is recommended that you use a Char-Broil® grill cover to help prolong the life and prevent discoloration of your grill.
  • Page 12 PARTS LIST – Model No. 466248208 Key Qty Description Part # Key Qty Description Part # Quantum Infrared Cooking Grates ..80016756 Bottom Shelf..... 80013297 Warming Rack .
  • Page 13 PARTS DIAGRAM – Model No. 466248208 JJ 2 JJ 3 JJ 1 13 • 466248208...
  • Page 14 ASSEMBLY – Model No. 466248208 Attach the two locking casters at the rear of the bottom shelf and the two fixed casters at the front. Use the provided caster wrench to fully tighten casters. Fixed caster Locking caster Bottom shelf Attach side panels to bottom shelf using three 1/4-20x1/2”...
  • Page 15 Place lower back panel between side panels at rear of bottom shelf. Make sure the slots are positioned as shown (A). Secure lower back panel to side panels using four 1/4-20x1/2” screws, 7mm lock washers, and 7mm flat washers on each side. 1/4-20x1/2”...
  • Page 16 Insert front brace under control panel and between cart side panels. Secure using two 1/4-20x1½” screws, 7mm lock washers, and 7mm flat washers on each side. NOTE: MAKE SURE THAT THE FRONT BRACE IS MOUNTED IN THE MOST DOWNWARD POSITION WHEN ASSEMBLED TO CART.
  • Page 17 Insert tabs on right side shelf into rectangular slots in side of firebox shown (A). Attach rear of shelf using one 1/4-20x3/4” screw, 7mm lock washer, and 7mm flat washer in upper hole shown (B). Use one 1/4-20x1½” screw, 7mm lock washer, and 7mm flat washer in lower hole shown (B).
  • Page 18 Insert tabs on left sideburner shelf assembly into rectangular slots in side of firebox shown (A). Attach rear of shelf using one 1/4-20x3/4” screw, 7mm lock washer, and 7mm flat washer in upper hole shown (B). Use one 1/4-20x1½” screw, 7mm lock washer, and 7mm flat washer in lower hole shown (B).
  • Page 19 A) Insert the Electronic Ignition module into the hole of left fascia, secure with the plastic nut. B) Insert AA battery into ignitor module, negative (—) end first, screw on the ignition button. C) Connect main burner ignitor wire to the terminal on backside of electronic ignition module. Connect one end of side burner ignitor wire to side burner electrode and other end to the back of electronic ignition module.
  • Page 20 Insert sideburner burner into left shelf, making sure burner tube engages sideburner valve (A). Center stud on bottom of burner fits into center hole in burner pan on shelf. See illustration C for proper burner-to-valve engagement. Secure burner to pan using two #10-24x3/8” screws, 5mm lock washers, and 5mm flat washers (B). 5mm flat washer Sideburner burner...
  • Page 21 Place burner cap onto sideburner. Attach sideburner cap clip and sideburner cooking grate into holes in drip pan. Next, place griddle onto shelf. Sideburner griddle Sideburner cooking grate Sideburner cap clip Burner cap Inside of cart, insert rear shield tabs into two left slots between upper and lower back panels. Attach left and center front shield tabs under front brace with #8x3/8”...
  • Page 22 Insert end of tank wire (without hole) into back of lower back panel. Attach other end to bottom of front brace with a #8x3/8” self-tapping screw. Tank Wire Insert wire ends into lower back panel (A). Attach front right side of wire shelf to the right side panel with one #8-32x3/8” screw, 4mm flat washer and 4mm lock washer (B).
  • Page 23 Attach both doors using four #8-32x3/8” flat head screws and one #8x3/8” self-tapping screw. Self-tapping Screw In This Location Left door Right door Install flame tamers by sliding one end of each flame tamer into slots at front of firebox and resting opposite end on pins in back of firebox.
  • Page 24 Place cooking grates onto the firebox as shown. Insert the three wire ends at rear of warming rack into holes in back of firebox. Front wires of warming rack rest on sides of firebox. Note: Some parts not shown for illustration purpose Warming rack Cooking grate Assembled...
  • Page 25 On back of grill, slide grease tray into opening in upper back panel. CAUTION Failure to install grease tray will cause hot grease to drip from bottom of grill with risk of fire or property damage. Grease tray 466248208 • 25...
  • Page 26 EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from • Damaged hose. • Turn off gas at LP cylinder or at source on natural gas systems. If cracked/cut/burned anything but burned, replace valve/hose/regulator.
  • Page 27 Troubleshooting (continued) Problem Possible Cause Prevention/Solution ELECTRONIC IGNITION: Burner(s) will not light using ignitor. • No spark, no ignition noise. • See Section I of Electronic Ignition System. (See Electronic Ignition Troubleshooting also) • No spark, some ignition noise. • See Section II of Electronic Ignition System. •...
  • Page 28 Bradley Company. Thermos® is a registered trademark of the Thermos Company and its affiliates. Artisan Collection by Char-Broil ™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™, The Minute Grill™, The Edge™, The Tuscan Collection™, and The Urban Grill™...
  • Page 29 Please register your product online at: www.grillregistration.com (If you register online, you do not need to send in this registration card.) PLEASE FILL OUT THIS CARD AND RETURN IT WITHIN 10 DAYS OF PURCHASE. FAILURE TO RETURN MAY AFFECT YOUR WARRANTY COVERAGE. FOR WARRANTY SERVICE PROOF OF PURCHASE WILL BE REQUIRED.
  • Page 30 In addition, in the state of California only, you may take the product to the retail establishment selling this product in order to obtain performance under this limited warranty. If you wish to obtain performance of any obligation under this limited warranty, you should write to: Char-Broil Consumer Relations P. O. Box 1240 Columbus, GA 31902-1240 Consumer returns will not be accepted unless a valid Return Authorization is first acquired by calling 1-888-430-7870 and then clearly marked on the outside of the package and the package is shipped freight/postage pre-paid to the address above.
  • Page 31 This Page Intentionally Blank. 31 • 466248208...
  • Page 32 Always ensure control knobs are in OFF position and regulator is attached to tank BEFORE opening tank valve to avoid low flames. Perform leak test regularly. Thank You for Your Purchase! Char-Broil, LLC • Columbus, GA 31902 • Printed in China...
