DEMO MANUAL DC1497A
pArts list
ITEM QTY REFERENCE
Required Circuit Components
1 3 C1, C2, C3
2 3 C4, C5, C6
3 2 C7, C10
4 1 C8
5 3 D1, D2, D3
6 3 L1, L2, L3
7 3 R1, R2, R3
8 3 R4, R5, R6
9 1 R16
10 1 R19
11 1 R20
12 1 R22
13 3 R23, R24, R25
14 1 U1
Additional Demo Board Circuit Components
1 1 C9
2 0 D4
3 1 R7
4 1 R9
5 7 R10-R14, R17, R18
6 1 R15
7 1 R21
Hardware – For Demo Board Only
1 8 E1-E5, E12-E14
2 10 E6-E11, E15-E18
3 1 JP1
4 1 SHUNT FOR PJ1
5 4
4
PART DESCRIPTION
Capacitor, X7R, 4.7µF , 50V, 10%,1206
Capacitor, X7R, 0.22µF , 25V, 10%, 0603
Capacitor, X7R, 2.2µF , 100V, 10%, 1210
Capacitor, X5R, 4.7µF , 25V, 10%, 0805
Diode, Schottky, Power DI-123
Inductor, 100µH
Resistor, Chip, 93.1k, 1/16W, 1%, 0402
Resistor, Chip, 3.01kΩ, 1/16W, 1%, 0402
Resistor, Chip, 82.5kΩ, 1/16W, 1%, 0402
Resistor, Chip, 49.9kΩ, 1/16W, 1%, 0402
Resistor, Chip,10kΩ, 1/16W, 1%, 0402
Resistor, Chip, 33.2kΩ, 1/16W,1%, 0402
Resistor, Chip, 20kΩ, 1/16W, 1%, 0402
I.C. LT3597EUHG, 52-Pin QFN-5mm × 8mm
Capacitor, Aluminum 4.7µF , 63V
Diode, OPT, SOD-323
Resistor, Chip, 270kΩ, 1/16W, 1%, 0603
Resistor, Chip, 91kΩ, 1/16W, 1%, 0402
Resistor, Chip, 100kΩ,1/16W,1%, 0402
Resistor, Chip, 8.87kΩ,1/16W, 1%, 0402
Thermistor, Chip, 100k,1%, 0603
Turret, Testpoint, 091"
Turret, Testpoint, 063"
Jumper, 3-Pin 1 Row .079CC
Shunt, .079" Center
Stand-Off, Nylon 0.5" Tall
MANUFACTURER/PART NUMBER
Murata, GRM31CR71H475KA12L
Murata, GRM188R71E224KA88L
Murata, GRM32ER72A225KA35L
Taiyo Yuden, TMK212BJ475KG-T
Diodes/Zetex, DFLS160-7
Sumida, CDR6D28MNNP-101NC
Vishay, CRCW040293K1FKED
Vishay, CRCW04023K01FKED
Vishay, CRCW040282K5FKED
Vishay, CRCW040249K9FKED
Vishay, CRCW040210K0FKED
Vishay, CRCW040233K2FKED
Vishay, CRCW040220K0FKED
Linear Technology, LT3597EUHG
Sun Electric, 63CE4R7BS
Vishay, CRCW0603270KFKEA
Vishay, CRCW040291K0FKED
Vishay, CRCW0402100KFKED
Vishay, CRCW04028K87FKED
Murata, NCP18WF104F12RB
Mill Max 2501-2-00-80-00-00-07-0
Mill Max 2308-2-00-80-00-00-07-0
Samtec, TMM-103-02-L-S
Samtec, 2SN-BK-G
Keystone, 8833 (Snap On)
