- Page 1 IP NETWORK PA SYSTEM ■ T-S708/ -S715/ T-S725/T-S735 ■ NETWORK AUDIO ADAPTER OWNER'S MANUAL Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference.
- Page 2 C o n t e n t s S A F E T Y P R E C A U T I O N S ..............3 P R O D U C T A P P L I C AT I O N .
- Page 3 1. SAFETY PRECAUTIONS Be sure to read the instructions in this section carefully before use. Make sure to observe the instructions in this manual as the conventions of safety symbols and messages regarded as very important precautions are included. We also recommend you keep this instruction manual handy for future reference. Safety Symbol and Message Conventions Safety symbols and messages described below are used in this manual to prevent bodily injury and property damage which could result from mishandling.
- Page 4 SAFETY PRECAUTIONS When the Unit is in Use When Installing the Unit Do not place heavy objects on the unit as this may Never plug in nor remove the power supply plug cause it to fall or break which may result in with wet hands, as doing so may cause electric personal injury and/or...
- Page 5 2. PRODUCT APPLICATION Professional Integration ceiling speakers equip with network audio decoding function, built-in digital resistance power amplifier and high-fidelity speakers, installed in the designated control room, office, room, etc. 3. FUNCTION FEATURES 1. Embed PC technology, built-in DSP Audio processing technology design and high speed industrial chip.
- Page 6 4. NAME AND UNCTION BATT SUPPLY POE/LAN STATE IP:192.168.169.169 1. The status indicator. 2. External 24V power supply. 3. POE power supply. ■ Indicator status description: 1. Power off: red and green light off. 2. Powering on, light green on, red light off. 3.
- Page 7 5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS The terminal needs to be configured before installation, before installation, need make a installation plan including terminal name, terminal IP address, gateway IP address, server IP address, location of terminal installation, and label the information on the terminal to ensure the convenient use of the device.
- Page 8 5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS The configuration steps: Step 1: Connect the terminal and the computer installed with the terminal configuration tool program by the network wire, Plug in the power until the termianl power indicator is on. Step 2: double-click to open the shortcut icon of “terminal configuration tool”, select the network card first, and left-click the “query”...
- Page 9 5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS Step 5: If multiple terminals are in the same network segment, you only need to modify the IP address of one terminal, it is needed to click on the terminal in the queried terminals list, then cancel the choice of broadcast on the left interface, modify the IP address and click for configuration.
- Page 10 6. CONNECTION DIAGRAM Speaker 01 POE Switch Speaker 02 Server Speaker N 7. BLOCK DIAGRAM RJ 45 100M network port +12V power supply Motherboard Network board +24V external +24V power supply power supply Speakers PA3123D2...
- Page 11 8. TECHNICAL PARAMETERS Mode T-S708 T-S715 T-S725 T-S735 Rated power output 8W/8W 8W/15W 8W/24W 8W/32W Network Input RJ45 TCP/IP,UDP Protocol Support Audio Format MP 3 Sampling Rate 8K~48K 8K~512Kbps Bit rate Transmit Speed Mbps /100Mbps Audo Mode 16 digit stereo CD tone...
- Page 12 VersionV0.1...
