- Page 1 IP NETWORK PA SYSTEM ■ T-7732 ■ NETWORK AUDIO ADAPTER ★ ● OWNER'S MANUAL Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS ..................3 APPLICATION ......................5 FEATURES ......................5 NOMENCLATURE AND FUNCTIONS .................6 TERMINAL CONFIGURATION OPERATING INSTRUCTIONS ........7 6. OPERATION ......................10 . BLOCK DIAGRAM ....................11 8. SPECIFICATIONS ....................12 . INSTALLATION METHOD ..................13... -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS Be sure to read the instructions in this section carefully before use. Make sure to observe the instructions in this manual as the conventions of safety symbols and messages regarded as very important precautions are included. We also recommend you keep this instruction manual handy for future reference. Safety Symbol and Message Conventions Safety symbols and messages described below are used in this manual to prevent bodily injury and property damage which could result from mishandling. - Page 4 SAFETY PRECAUTIONS When the Unit is in Use When Installing the Unit Do not place heavy objects on the unit as this may Never plug in nor remove the power supply plug cause it to fall or break which may result in with wet hands, as doing so may cause electric personal injury and/or...
-
Page 5: Application
2. APPLICATION Professional outdoor one-key-for-help network intercom terminal is designed for safe city, large parks, tunnels, mines and other places. It can also be used to broadcast and play background music. 3. FEATURES 1. All-metal shell piano paint technology, with anti-explosion and waterproof shell, it’s durable and can be fixed in the outdoor vertical bar or wall mounted. -
Page 6: Name And Function Of Parts
4. NAME AND FUNCTION OF PARTS 1. Monitoring speaker is used for the audio sign output of the call center 2. Call button, press the button, the machine turn into the emergency call state for calling; and then press the button again to cancel the emergency call state; 3. -
Page 7: Terminal Configuration Operating Instructions
5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS The terminal needs to be configured before installation, before installation, need make a installation plan including terminal name, terminal IP address, gateway IP address, server IP address, location of terminal installation, and label the information on the terminal to ensure the convenient use of the device. - Page 8 5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS The configuration steps: Step 1: Connect the terminal and the computer installed with the terminal configuration tool program by the network wire, Plug in the power until the termianl power indicator is on. Step 2: double-click to open the shortcut icon of “ terminal configuration tool”, select the network card first, and left-click the “query”...
- Page 9 5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS Step 5: If multiple terminals are in the same network segment, you only need to modify the IP address of one terminal, it is needed to click on the terminal in the queried terminals list, then cancel the choice of broadcast on the left interface, modify the IP address and click for configuration.
-
Page 10: Operation
6. OPERATION Instructions: 1. Before connecting the power supply, check whether the local power grid matches the power supply specified in the manual or not. 2. Complete IP address code settings of terminal according to the operation instruction by using cable;... -
Page 11: Block Diagram
7. BLOCK DIAGRAM... -
Page 12: Specifications
8. SPECIFICATIONS Model T-7732 Network Interface Standard RJ45 input TCP/IP, UDP, IGMP (Multicast) Support protocol MP 3 Audio Format 8K~48KHz Sampling Rate 100Mbps Transmission rate Audio mode 16 bit CD tone quality ≤1% Frequency response 80Hz~16KHz +1dB/-3dB >65dB IP 55... -
Page 13: Installation Method
9. INSTALLATION METHOD Make installation hole on wall. Put the terminal wall mount accessory at a proper height of the wall,and make 4 installation holes which distance size is 377*200mm. Fixing product. Place the expansion 4 wall mount accessories and wall fixing expansion bolts bolts into the wall openings, and fix the product with the four bolts to the... - Page 14 VersionV0.1...
