- Page 1 IP NETWORK PA SYSTEM ■ T-7703 ■ NETWORK AUDIO ADAPTER ★ ● OWNER'S MANUAL Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS ..................3 APPLICATION ......................5 FEATURES ......................5 NOMENCLATURE AND FUNCTIONS ...............6 4.1 Front panel......................6 4.2 Wiring diagram....................6 5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS ........7 6. OPERATION ......................10 BLOCK DIAGRAM ....................11 8. SPECIFICATIONS ....................12 9. BOTTOM CASE INSTALLATION DIMENSION FIGURE ..........13... -
Page 3: Safety Precautions
AC outlet and as doing so may result in fire or electric shock. contact your nearest ITC dealer. Make no further attempt to operate the unit in this condition as this Use the unit only with the voltage specified on the may cause fire or electric shock. - Page 4 When removing the power cord, be sure to hold its plug to pull. Contact your ITC dealer as to the cleaning. If dust is allowed to accumulate in the unit over a long Do not block the ventilation slots in the unit's cover.
-
Page 5: Application
2. APPLICATION 1. Professional one key for help network intercom terminal. 2. It fits indoor-outdoor environment installation, anti-explosive and waterproof; it can be launched one key intercom communication to duty room. 3. FEATURES 1. Simple appearance, graceful line, high-grade alumina brushed aluminum foil panel, strong and durable, can be embedded installation or surface installation (with bottom box). -
Page 6: Nomenclature And Functions
NOMENCLATURE AND FUCTIONS 4.1 Front panel 1. Mic port audio input, it can call or intercom. 2. Call button and call status indicator light, when press this button, it can be one key quickly call or ask for help. 1) The light is red when the machine switch on normally 2) The light is green when network connection is normal, 3) When intercom call waiting, light A is available (flashing green light, 500 ms/each),... -
Page 7: Terminal Configuration Operating Instructions
5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS The terminal needs to be configured before installation, before installation, need make a installation plan including terminal name, terminal IP address, gateway IP address, server IP address, location of terminal installation, and label the information on the terminal to ensure the convenient use of the device. - Page 8 5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS The configuration steps: Step 1: Connect the terminal and the computer installed with the terminal configuration tool program by the network wire, Plug in the power until the termianl power indicator is on. Step 2: double-click to open the shortcut icon of “ terminal configuration tool”, select the network card first, and left-click the “query”...
- Page 9 5. TERMINAL CONFIGURATION OPERATING INSTRUCTIONS Step 5: If multiple terminals are in the same network segment, you only need to modify the IP address of one terminal, it is needed to click on the terminal in the queried terminals list, then cancel the choice of broadcast on the left interface, modify the IP address and click for configuration.
-
Page 10: Operation
6. OPERATION 1) When network connection is normal, the panel indicator light is green, press the "CALL" the call button, can call to the CALL center, after the CALL center answering, intercom can be achieved between the two terminals, if unanswered or when more than 120s unanswered, it will prompt each other . Promised to talk on the phone, the speakers will be each other's voice. -
Page 11: Block Diagram
7. BLOCK DIAGRAM... -
Page 12: Specifications
8. SPECIFICATIONS Model T-7703 Network Interface Standard RJ45 input TCP/IP, UDP Supportive protocol MP3/MP2 Audio Format 8K~48KHz Sampling Rate 100Mbps Transmission rate Audio mode 16 bit stereo CD tone quality ≤ THD 1% 317Hz~3.4KHz Frequency Response >65dB LINE OUT output level... -
Page 13: Bottom Case Installation Dimension Figure
9. BOTTOM CASE INSTALLATION DIMENSION FIGURE Directly above... - Page 14 VersionV0.1...
