- Page 1 I N S TA L L AT I O N MA N UA L Novus Single Lever Vessel Fauce KEF-15400 www.kraususa.com I toll free: 1.800.775.0703 I © 2013-2014 Kraus USA Inc.
- Page 2 Thank you for purchasing Kraus We would like to take this opportunity to thank you for your business with Kraus USA. It is our sincere hope that you are completely satisfied with your experience. We welcome any questions or comments you may have, and will be glad to assist you in the future.
- Page 3 Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement • Turn off the hot and cold water lines at the angle stops and turn on the old faucet to release any built-up pressure •...
- Page 4 Replacement Parts 1. (A) Index Button (B) Set Screw 2. Metal Handle 3. Cartridge Cover 4. Locking Nut 5. Cartridge 6. Faucet Body 7. Rubber Washer 8. Mounting Hardware (A) Rubber Washer (B) Metal Washer (C) Mounting Nut (D) Mounting Screws 9.
- Page 5 Faucet Installation Procedure 83mm (3.27”) 160mm (6.30”) Ø35 (1.37”) Installer Tip: Shut off main water supply before installing new faucet...
- Page 6 Step 1: Remove mounting hardware Step 1 Step 2 Remove the mounting screws (8D), mounting nut (8C), metal washer (8B), and rubber washer (8A) from the mounting pipe Step 2: Install hot & cold waterlines Step 2 Step5 ep 3 Place faucet on a soft cloth, spout facing up.
- Page 7 Step 3: Install faucet Install faucet through 1-3/8” predrilled hole in countertop. Attach rubber washer (8A), metal washer (8B), mounting nut (8C), and mounting screws (8D) on the threaded mounting pipe. Tighten mounting nut (8C) until snug. Tighten screws (8D) on mounting nut (8C) with Phillips head screwdriver until snug Step4...
- Page 8 Step 4: Connect waterlines to main valve Connect flex water supply lines to angle stops and tighten with adjustable wrench. Turn on both hot and cold main valve Apply pipe tape (optional) Step 5: Flush faucet After installing faucet, remove aerator (9) with included aerator key (10).
- Page 9 Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under the Locking nut (4) has Remove handle index...
- Page 10 If Kraus is unable to provide a replacement and repair is not practical or cannot be made in timely fashion, Kraus may elect to refund the purchase price in exchange for the return of the product.
- Page 11 NON-APPLICABILITY OF THIS WARRANTY By the purchase and use of our products, you agree that Kraus is not liable for incidental, consequential or special damages associated with the return, replacement, installation or use of your product. This includes freight costs,...
- Page 12 www.kraususa.com...
