- Page 1 NT10-103 РУССКИЙ v.2.0 MANUAL GRAVITY SPRAY GUN MANUAL INSTRUCTION NT10-103-GP12 NT10-103-GP13 NT10-103-GP14 NT10-103-GP15 NT10-103-GP16 NT10-103-GP18 NT10-103-GP20 NT10-103-GP25...
- Page 2 NT10-103 ENGLISH v.2.0 ATTENTION! PLEASE READ THIS MANUAL BEFORE USING THE SPRAY GUN (TOOL). IMPROPER USE OF TOOL MAY CAUSE INJURY AND/OR PROPERTY DAMAGE! ONLY QUALIFIED AND SPECIALLY TRAINED PERSONNEL FAMILIED WITH THESE INSTRUCTIONS IS ALLOWED TO USE AND MAINTENANCE OF THE TOOL. This manual contains description, safety rules and all the information necessary for the correct use of the spray gun.
- Page 3 If there is any doubt regarding the suitability of a specific material, contact your ONETECH Distributor or ONETECH direct. OPERATING PRINCIPLE ✓...
- Page 4 Spray width, Nozzle size, Air Pressure, Air Consumption, Fluid Output, Weight, Model Air Cap ml/min ± 20 mm NT10-103-GP12 230 – 250 NT10-103-GP13 240 – 260 NT10-103-GP14 250 – 275 NT10-103-GP15 2.0 – 3.0 260 – 280 NT10-103-GP16 300 – 340 NT10-103-GP18 330 –...
- Page 5 NT10-103 ENGLISH v.2.0 TROUBLESHOOTING GUIDE FLUTTERING Possible Cause Solution Insufficient material in cap Refill material Dry or worn fluid needle packing set or loose fluid needle Lubricate or replace fluid needle packing set or tighten fluid packing screw needle packing screw Loose or damaged fluid nozzle Tighten or replace fluid nozzle CRESCENT...
- Page 6 NT10-103 v.2.0...
- Page 7 NT10-103 v.2.0 Description Part No. Description Part No. Air cap set (LV2) Air adjusting set NT10S-072 NT10S-031 Air cap set (W2) Locking ring NT10S-073 NT10S-032 Fluid nozzle (1.2) Trigger stud NT10S-074 NT10S-033 Fluid nozzle (1.3) Trigger NT10S-075 17-1 NT10S-034 Fluid nozzle (1.4) Trigger guide NT10S-076 17-2...
- Page 8 NT10-103 v.2.0...
