ACK
SERIES
80 PLUS
SILVER
Features:
ATX3.1 AND PCIe 5.1 ready
12V-2x6 DC cable
DC-DC converter
Embossed DC cable
Cybenetics and 80 PLUS Silver certified
Teapo electrolyte capacitor
7-year warranty
Multiple protections: OVP/OPP/SCP/OCP/UVP/OTP
14 CM
TEAPO
HYDRAULIC
ELECTROLYTE
BEARING FAN
CAPACITORS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for 1StPLAYER ACK Series
Summary of Contents for 1StPLAYER ACK Series
- Page 1 SERIES 80 PLUS SILVER Features: ATX3.1 AND PCIe 5.1 ready 12V-2x6 DC cable DC-DC converter Embossed DC cable Cybenetics and 80 PLUS Silver certified Teapo electrolyte capacitor 7-year warranty Multiple protections: OVP/OPP/SCP/OCP/UVP/OTP 14 CM TEAPO HYDRAULIC ELECTROLYTE BEARING FAN CAPACITORS...
- Page 2 SAFETY AND PROTECTION Your new power supply unit comes equipped with multiple protective features to ensure safe and reliable operation: Under-Voltage Protection (UVP) shuts the PSU off if the voltage the PSU is providing to the PC drops below accepted values. Over-Voltage Protection (OVP) Monitors 12V, 5V, and 3.3V outputs.
- Page 3 ACK 750W SPECIFICATIONS MODEL PS-750AA7 POWER OUTPUT 750 W INPUT VOLTAGE 200 - 240 V~ INPUT CURRENT 5 A MAX INPUT FREQUENCY 50-60 Hz EFFICIENCY 90.33% at typical load DIMENSIONS (L x W x H) 145 x 150 x 86 mm PACKAGE DIMENSION 280 x 190x 120 mm MODULAR...
- Page 4 ACK 850W SPECIFICATIONS MODEL PS-850AA7 POWER OUTPUT 850 W INPUT VOLTAGE 200 - 240 V~ INPUT CURRENT 5 A MAX INPUT FREQUENCY 50-60 Hz EFFICIENCY 90.47% at typical load DIMENSIONS (L x W x H) 145 x 150 x 86 mm PACKAGE DIMENSION 280 x 190x 120 mm MODULAR...
- Page 5 ACK SILVER CABLE INFORMATION CABLE LENGTH (± 10 mm) QUANTITY ATX Cable 24-pin ATX12V Cable 8-pin (4+4) 560 + 150 12V-2X6 PCI-E Cable 8-pin (6+2) SATA Cable + MOLEX (4 pin) 340 +150 + 150 POWER SUPPLY ACK SILVER...
- Page 6 INSTALLATION GUIDE Before you begin, ensure your system is powered off and unplugged from any power source. Step 1: Removing the Existing PSU (Skip if building a new system) 1. Unplug the AC power cord from both the wall outlet and the current PSU. 2.
