- Page 1 POWER SUPPLY 80 PLUS NON-MODULAR Feature: Active PFC Embossed cable 80 PLUS certified Dual forward topology 5-year warranty Multiple protections: OPP, OVP, SCP 14 CM PREMIUM HYDRAULIC QUALITY BEARING FAN CAPACITORS...
-
Page 2: Safety And Protection
SAFETY AND PROTECTION Your new power supply unit comes equipped with multiple protective features to ensure safe and reliable operation: Over-Voltage Protection (OVP) Monitors 12V, 5V, and 3.3V outputs. Automatically shuts down the PSU if voltage exceeds safe levels. Over-Power Protection (OPP) Turns off the PSU if power draw reaches preset percentage of the rated capacity. - Page 3 ACK 550W SPECIFICATIONS MODEL HA-550AC1 POWER OUTPUT 550 W INPUT VOLTAGE 200- 240V INPUT CURRENT 6 A MAX INPUT FREQUENCY 47-63 Hz EFFICIENCY 87% at typical load DIMENSIONS (L x W x H) 145 x 150 x 86 mm MODULAR Non-modular CERTIFICATIONS 80 PLUS...
- Page 4 ACK 650W SPECIFICATIONS MODEL HA-650AC1 POWER OUTPUT 650 W INPUT VOLTAGE 200- 240V INPUT CURRENT 6 A MAX INPUT FREQUENCY 47-63 Hz EFFICIENCY 87.5% at typical load DIMENSIONS (L x W x H) 145 x 150 x 86 mm MODULAR Non-modular CERTIFICATIONS 80 PLUS...
- Page 5 ACK 750W SPECIFICATIONS MODEL HA-750AC2 POWER OUTPUT 750 W INPUT VOLTAGE 200- 240V INPUT CURRENT 10 A MAX INPUT FREQUENCY 50-60 Hz EFFICIENCY 88.5% at typical load DIMENSIONS (L x W x H) 145 x 150 x 86 mm MODULAR Non-modular CERTIFICATIONS 80 PLUS...
- Page 6 ACK 550W CABLE INFORMATION CONNECTORS TOTAL LENGTH QUANTITY ATX Cable 24-pin 600 mm ATX12V Cable 8-pin (4+4) 650 mm PCI-E Cable 8-pin (6+2) 600 mm SATA Cable + MOLEX (4 pin) 800 mm POWER SUPPLY ACK 550W...
- Page 7 ACK 650W CABLE INFORMATION CONNECTORS TOTAL LENGTH QUANTITY ATX Cable 24-pin 600 mm ATX12V Cable 8-pin (4+4) 650 mm PCI-E Cable 8-pin (6+2) 600 + 150 mm SATA Cable + MOLEX (4 pin) 800 mm POWER SUPPLY ACK 650W...
- Page 8 ACK 750W CABLE INFORMATION CONNECTORS TOTAL LENGTH QUANTITY ATX Cable 24-pin 600 mm ATX12V Cable 8-pin (4+4) 650 + 150 mm PCI-E Cable 8-pin (6+2) 600 + 150 mm SATA Cable + MOLEX (4 pin) 800 mm POWER SUPPLY ACK 750W...
- Page 9 INSTALLATION GUIDE Before you begin, ensure your system is powered off and unplugged from any power source. Step 1: Removing the Existing PSU (Skip if building a new system) 1. Unplug the AC power cord from both the wall outlet and the current PSU. 2.
