1StPLAYER NGDP Quick Start Manual

Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
NGDP
POWER SUPPLY
PLATINUM
FULL-MODULAR
Feature:
Full Japanese Capacitors
80 PLUS Platinum certified
Zero RPM fan
ATX 3.1 and PCIe 5 ready
Test report download via MES ID
FULL
ZERO
JAPANESE
RPM
CAPACITORS
MODE
REVISED HISTORY
Version 1.0 Edited
by Shu 2024.7

Advertisement

loading
Need help?

Need help?

Do you have a question about the NGDP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 1StPLAYER NGDP

Summary of Contents for 1StPLAYER NGDP

  • Page 1 NGDP POWER SUPPLY PLATINUM FULL-MODULAR Feature: Full Japanese Capacitors 80 PLUS Platinum certified Zero RPM fan ATX 3.1 and PCIe 5 ready Test report download via MES ID FULL ZERO JAPANESE CAPACITORS MODE REVISED HISTORY Version 1.0 Edited by Shu 2024.7...

  • Page 2: Safety And Protection

    These safety mechanisms work together to protect your computer system and the power supply itself from potential electrical hazards. For optimal performance and longevity, always operate your PSU within its rated specifications. POWER SUPPLY NGDP...

  • Page 3: Specifications

    120 mm FDB PROTECTIONS UVP, OVP, OPP, SCP, OCP, OTP REGULATORY CE/FCC/C-Tik/RoHS/CCC/cTUVus/IEC/EAC MTBF 100,000 hours CIRCUIT STRUCTURE LLC + DC - DC WARRANTY 10 years DC OUTPUT MAX LOAD (A) MAX OUTPUT (W) +3.3V +12V +5VSb -12V POWER SUPPLY NGDP...
  • Page 4 120 mm FDB PROTECTIONS UVP, OVP, OPP, SCP, OCP, OTP REGULATORY CE/FCC/C-Tik/RoHS/CCC/cTUVus/IEC/EAC MTBF 100,000 hours CIRCUIT STRUCTURE LLC + DC - DC WARRANTY 10 years DC OUTPUT MAX LOAD (A) MAX OUTPUT (W) +3.3V +12V 1296 +5VSb -12V POWER SUPPLY NGDP...

  • Page 5: Cable Information

    TOTAL LENGTH QUANTITY ATX Cable 24-pin 610 mm ATX12V Cable 8-pin (4+4) 650 mm PCI-E Cable 12V-2x6 (GPU) 720 mm PCI-E Cable 8-pin (6+2) 600 mm SATA Cable (SSD/HDD) 465 mm MOLEX Cable (4 PATA) 465 mm POWER SUPPLY NGDP...
  • Page 6 Use only the cables provided with your new PSU to ensure compatibility and safety. Refer to your motherboard and GPU manuals for specific power requirements. Store unused modular cables safely for future upgrades. After installation, ensure all components are properly connected before powering on your system. POWER SUPPLY NGDP...
  • Page 7 INSTALLATION GUIDE For proper installation, match each cable connector to the same color port on the power supply unit and PC components. POWER SUPPLY NGDP...
