- Page 1 NGDP POWER SUPPLY GOLD FULL-MODULAR Feature: Full Japanese Capacitors 80 PLUS Gold certified 0 RPM fan ATX 3.1 and PCIe 5.1 ready Test report download via MES ID FULL ZERO JAPANESE CAPACITORS MODE POWER SUPPLY NGDP...
-
Page 2: Safety And Protection
SAFETY AND PROTECTION Your new power supply unit comes equipped with multiple protective features to ensure safe and reliable operation: Under-Voltage Protection (UVP) shuts the PSU off if the voltage the PSU is providing to the PC drops below accepted values. Over-Voltage Protection (OVP) Monitors 12V, 5V, and 3.3V outputs. - Page 3 SPECIFICATIONS HA-750BA4 NGDP GOLD 750W MODEL HA-750BA4 POWER OUTPUT 750 W INPUT VOLTAGE 100 - 240V INPUT CURRENT 10 - 5 A INPUT FREQUENCY 50/60 Hz EFFICIENCY 88.66% at full load DIMENSIONS (L x W x H) 140 x 150 x 86 mm MODULAR Full-modular CERTIFICATIONS...
- Page 4 SPECIFICATIONS HA-850BA4 NGDP GOLD 850W MODEL HA-850BA4 POWER OUTPUT 850 W INPUT VOLTAGE 100 - 240V INPUT CURRENT 10 - 5 A INPUT FREQUENCY 50/60 Hz EFFICIENCY 88.39% at full load DIMENSIONS (L x W x H) 140 x 150 x 86 mm MODULAR Full-modular CERTIFICATIONS...
- Page 5 SPECIFICATIONS HA-1000BA4 NGDP GOLD 1000W MODEL HA-1000BA4 POWER OUTPUT 1000 W INPUT VOLTAGE 100 - 240V INPUT CURRENT 12 - 6 A INPUT FREQUENCY 50/60 Hz EFFICIENCY 88.7% at full load DIMENSIONS (L x W x H) 140 x 150 x 86 mm MODULAR Full-modular CERTIFICATIONS...
-
Page 6: Cable Information
CABLE INFORMATION CONNECTORS TOTAL LENGTH QUANTITY ATX Cable 24-pin (MB) 610 mm ATX12V Cable 8-pin ( CPU 4+4) 650 mm PCI-E Cable 12V-2x6 (GPU 12+4) 720 mm PCI-E Cable 8-pin ( GPU 6+2) 600 mm SATA Cable (SSD/HDD) 465 mm MOLEX Cable (4 PATA) 465 mm POWER SUPPLY... - Page 7 INSTALLATION GUIDE Before You Begin, ensure your system is powered off and unplugged from any power source. Step 1: Removing the Existing PSU (Skip if building a new system) 1. Unplug the AC power cord from both the wall outlet and the current PSU. 2.
- Page 8 INSTALLATION GUIDE For proper installation, match each cable connector to the same color port on the power supply unit and PC components. POWER SUPPLY NGDP GOLD...
