- Page 1 PREMIUM 1STPLAYER PC POWER SUPPLY Feature: 12 cm FDB low noise fan EFF. high as 90% under full load Active PFC Multi protections: OVP, OPP, UVP, SCP Japanese main capacitors POWER SUPPLY DK SERIES...
-
Page 2: Safety And Protection
Protects against shorts between rails or to ground, preventing damage to the PSU and system components. These safety mechanisms work together to protect your computer system and the power supply itself from potential electrical hazards. For optimal performance and longevity, always operate your PSU within its rated specifications. POWER SUPPLY DK SERIES... - Page 3 SPECIFICATIONS PS-500AX DK 5.0 BRONZE 500W MODEL PS-500AX POWER OUTPUT 500 W INPUT VOLTAGE 100 - 240V INPUT CURRENT 10 A INPUT FREQUENCY 50 - 60 Hz EFFICIENCY 90% at full load CERTIFICATION 80 PLUS Bronze DIMENSIONS (L x W x H) 140 x 150 x 86 mm MODULAR Non-modular...
- Page 4 SPECIFICATIONS PS-600AX DK 6.0 BRONZE 600W MODEL PS-600AX POWER OUTPUT 600 W INPUT VOLTAGE 100 - 240V INPUT CURRENT 10 A INPUT FREQUENCY 50 - 60 Hz EFFICIENCY 90% at full load CERTIFICATION 80 PLUS Bronze DIMENSIONS (L x W x H) 140 x 150 x 86 mm MODULAR Non-modular...
- Page 5 SPECIFICATIONS PS-700AX DK 7.0 BRONZE 700W MODEL PS-700AX POWER OUTPUT 700 W INPUT VOLTAGE 100 - 240V INPUT CURRENT 10 A INPUT FREQUENCY 50 - 60 Hz EFFICIENCY 90% at full load CERTIFICATION 80 PLUS Bronze DIMENSIONS (L x W x H) 140 x 150 x 86 mm MODULAR Non-modular...
- Page 6 SPECIFICATIONS PS-800AX DK 8.0 BRONZE 800W MODEL PS-800AX POWER OUTPUT 800 W INPUT VOLTAGE 100 - 240V INPUT CURRENT 10 A INPUT FREQUENCY 50 - 60 Hz EFFICIENCY 90% at full load CERTIFICATION 80 PLUS Bronze DIMENSIONS (L x W x H) 140 x 150 x 86 mm MODULAR Non-modular...
- Page 7 DK 5.0 500W / DK 6.0 600W CONNECTORS TOTAL LENGTH QUANTITY ATX Cable 24-pin (Motherboard) 500 mm ATX12V Cable 8-pin (4+4 CPU) 800 mm PCI-E Cable (6+2 GPU) 700 mm SATA IDE Cable (SSD/HDD/Fan) 900 mm POWER SUPPLY DK SERIES...
- Page 8 DK 7.0 700W / DK 8.0 800W CONNECTORS TOTAL LENGTH QUANTITY ATX Cable 24-pin (Motherboard) 500 mm ATX12V Cable 8-pin (4+4 CPU) 800 mm PCI-E Cable (6+2 GPU) 700 mm SATA IDE Cable (SSD/HDD/Fan) 750 mm POWER SUPPLY DK SERIES...
- Page 9 Use only the cables provided with your new PSU to ensure compatibility and safety. Refer to your motherboard and GPU manuals for specific power requirements. After installation, ensure all components are properly connected before powering on your system. POWER SUPPLY DK SERIES...
